FIAT 124 SPIDER 1975-1982 Service Repair Manual

Prix habituel: $17.99
Prix soldé: $17.99
Prix habituel
Prix unitaire: par

🏷️ Basic Information Identification Make: FIAT Model: 124 Spider Generation: First Generation (BC) Codes Chassis Codes: BC 👋 Introduction Market Position Target Audience: Owners with basic mechanical skills and independent...

19 people are viewing this right now

Taper: Car

Distributeur:

UGS: 561144

Mots clés: 124 SPIDER 1975 1976 1977 1978 1979 1980 1981 1982 Car Cars Featured Fiat

Variantes de produits

Description

🏷️ Basic Information

Identification

Make:

Model:

124 Spider

Generation:

First Generation (BC)

Codes

Chassis Codes:

👋 Introduction

Market Position

Target Audience:

Owners with basic mechanical skills and independent auto service professionals.

Competitive Analysis

Value Proposition:

Provides dealership-level specifications and procedures for owners to be better informed and to discuss repairs knowledgeably with technicians.

Key Features

Instant Access:

Instant download upon payment, no shipping costs or waiting for physical media.

Practical Solutions:

Offers common fixes, troubleshooting techniques, and practical advice for common issues like no-starts and hesitations.

📋 Manual Details

Coverage Areas

Applicable Years:

1975-1982

Page Count

Estimated Pages:

Varies by edition, typically 500+ pages for comprehensive service manuals.

Manual Type

Type:

Service and Repair Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Engine:

Engine Service and Overhauling, Induction, Fuel System, Emission Control, Mechanical components, Control System

Transmission Drivetrain:

Transmission, Transmission and Differentials

Chassis Suspension Steering:

Chassis, Steering and Suspension

Brakes:

Brakes, ABS

Bodywork Electrical:

Body, Wiring

Procedures Included

Maintenance:

Routine maintenance, fluid changes, filter replacements, tune-ups

Diagnostics Troubleshooting:

Troubleshooting and Diagnostics, diagnosing engine fault symptoms, electrical system checks

Repairs Rebuilds:

Engine overhauling, transmission repair, suspension component replacement, brake system servicing, body repair procedures

Electrical Wiring:

Tracing and verifying wiring diagrams, specific terminal pin connections, expected readings

Technical Depth

Depth:

Comprehensive; covers basic mechanical skills to advanced repair procedures, suitable for owners and independent professionals.

📊 Manual Specifications

File Format

Compatibility:

Viewable on PC, Mac, and compatible devices (phones, ebook readers like Kindle).

Print Quality

Printability:

Individual pages can be printed, preserving the original digital file.

Binding Type

Binding:

N/A (Digital PDF)

Paper Type

Paper:

N/A (Digital PDF)

⚙️ Engine Specifications

Primary Engine

Displacement 1:

1.8 Liters (1756 cc)

Engine Code 1:

124 AC

Configuration 1:

Inline-4 Cylinder, DOHC (Derived from Fiat Twin Cam)

Fuel System 1:

Carbureted (e.g., Weber DCNF or Solex twin-choke carburetors)

Performance Estimate 1:

Approx. 90-100 hp (depending on year and emissions regulations)

Secondary Engine

Displacement 2:

2.0 Liters (1995 cc)

Engine Code 2:

132 AC

Configuration 2:

Inline-4 Cylinder, DOHC (Fiat Twin Cam)

Fuel System 2:

Fuel Injection (Bosch L-Jetronic for later models) or Carbureted

Performance Estimate 2:

Approx. 100-120 hp (depending on fuel system and tuning)

🔧 Transmission

Standard

Type:

5-speed Manual Transaxle

Optional

Type:

3-speed Automatic (less common)

Features

Differential:

Integrated into transaxle housing

📐 Dimensions

Exterior

Length:

Approx. 3,970 mm (156.3 in)

Width:

Approx. 1,620 mm (63.8 in)

Height:

Approx. 1,265 mm (49.8 in)

Weights

Curb Weight:

Approx. 980 - 1050 kg (2160 - 2315 lbs)

Wheelbase:

Approx. 2,235 mm (88.0 in)

🛡️ Safety Features

Ratings

Crash Test Era:

Pre-modern safety standards, limited official crash test data available.

Active Features

Brakes:

Disc brakes front, Drum brakes rear (standard for early models); Optional 4-wheel discs on some later variants.

Passive Features

Seatbelts:

Standard lap and shoulder belts.

Body Construction:

Unibody construction with crumple zones.

💡 Technology Features

Infotainment

Features:

Basic analog gauges, AM/FM radio (optional), heater/defroster.

Driver Assistance

Features:

N/A (Focus on driver engagement, not electronic aids).

🔧 Maintenance

Service Intervals

Oil Change:

Recommended every 5,000-7,500 km (3,000-5,000 miles) or 6-12 months.

Tune Up:

Recommended annually or every 10,000-15,000 km (6,000-10,000 miles).

Fluid Specifications

Engine Oil:

API SG or higher, SAE 10W-40 or 20W-50 (depending on climate). Check manual for specific viscosity grades.

Coolant:

Ethylene glycol-based antifreeze, mixed 50/50 with distilled water. Check manual for specific types.

Transmission Fluid:

GL-4 gear oil, SAE 75W-90 or 80W-90. Check manual for specific type and capacity.

Known Issues

Rust:

Susceptible to rust in common areas: sills, wheel arches, floor pans, and chassis rails.

Electrical Gremlins:

Older wiring harnesses can degrade, leading to intermittent electrical faults.

Carburetor Tuning:

Carburetors require regular adjustment and maintenance for optimal performance and fuel economy.

Suspension Wear:

Bushings, ball joints, and tie rod ends can wear over time, affecting handling.

📚 Vehicle History

Brand Heritage

Manufacturer:

FIAT (Fabbrica Italiana Automobili Torino), Italy

Model Evolution

Design Origin:

Market Introduction:

Originally launched in 1966, this manual covers the later models incorporating revisions and updated engines.

Production

Production Years:

1966-1985 (Global production)

Assembly Locations:

Italy, Poland, Australia, and South Africa (for CKD kits).

🏆 Awards & Recognition

Recognitions

Historical Acclaim:

Praised for its stylish Italian design, engaging driving dynamics, and lively Fiat Twin Cam engine.

Classic Status:

Considered a classic sports car, popular in vintage racing and collector circles.
