1988-2005 KAWASAKI GPX250 Service Repair Manual Supplement

$16.99
$16.99
The Kawasaki GPX250, also known as the Ninja 250 in certain markets, is a versatile motorcycle produced from 1988 to 2005. This model is recognized for its entry-level sportbike appeal,...
25 people are viewing this right now
Taper: Motorcycle
Distributeur:
Kawasaki
UGS: 128818
Mots clés: 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 GPX Models GPX250 Kawasaki Motorcycle Motorcycles
1988-2005 KAWASAKI GPX250 Service Repair Manual Supplement
The Kawasaki GPX250, also known as the Ninja 250 in certain markets, is a versatile motorcycle produced from 1988 to 2005. This model is recognized for its entry-level sportbike appeal, offering a blend of manageable power, sporty styling, and efficient performance, making it an excellent choice for both new riders and those seeking a reliable commuter. Built with Kawasaki's reputation for engineering quality and reliability, the GPX250 provides an engaging riding experience characterized by its liquid-cooled, parallel-twin engine and agile chassis. Its design prioritizes affordability and ease of maintenance, contributing to its enduring popularity in the lightweight motorcycle segment. This Service Repair Manual Supplement provides comprehensive guidance for the Kawasaki GPX250 models (EX250-F through EX250-M) produced between 1988 and 2005. It covers essential maintenance procedures, detailed engine overhaul and repair, fuel and ignition system servicing, transmission, electrical systems, chassis, suspension, and braking systems. The manual includes troubleshooting guides, diagnostic procedures, and technical specifications to assist owners, mechanics, and technicians in maintaining and repairing the motorcycle effectively. Its scope ensures that users can confidently perform routine servicing, address common issues, and undertake more complex repairs, thereby preserving the motorcycle's performance and longevity.
