1989-2004 Yamaha Breeze 125 Repair Manual

$17.99
$17.99
🏷️ Basic Information Identification Make: Yamaha Model: Breeze 125 Model Codes: YFA1D, YFA1B, YFA1F, YFA1G, YFA1H, YFA1J, YFA1K, YFA1L, YFA1MC, YFA1M, YFA1NC, YFA1N, YFA1P, YFA1PC, YFA1R, YFA1RC, YFA1S, YFA1SC Generation...
23 people are viewing this right now
Taper: Atv
Distributeur:
Yamaha
UGS: 144378
Mots clés: 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 ATV Breeze 125 Breeze Models Powersports Yamaha
1989-2004 Yamaha Breeze 125 Repair Manual
🏷️ Basic Information
Identification
Make:
Yamaha
Model:
Breeze 125
Model Codes:
YFA1D, YFA1B, YFA1F, YFA1G, YFA1H, YFA1J, YFA1K, YFA1L, YFA1MC, YFA1M, YFA1NC, YFA1N, YFA1P, YFA1PC, YFA1R, YFA1RC, YFA1S, YFA1SC
Generation
Production Years:
1989-2004
Codes
Vin Code:
First character typically 'J' for Japan
👋 Introduction
Market Position
Segment:
Lightweight Recreational ATV
Competitive Analysis
Competitors:
Honda FourTrax 90/110/125, Suzuki LT-Z50/LT-80, Polaris Scrambler 50/90
Key Features
Manual Value:
Provides essential factory-level information for maintenance and repair, crucial for DIY enthusiasts and independent shops.
Vehicle Attributes:
Designed as an entry-level, user-friendly recreational ATV, suitable for youth riders and trail use.
📋 Manual Details
Coverage Areas
Vehicle Range:
1989 through 2004 Yamaha Breeze 125 (all variants listed)
Page Count
Estimated Page Count:
High (typical for factory service manuals, likely 300+ pages)
Manual Type
Type:
Factory Service Manual / Repair Manual
Language
Language:
English (presumed based on product description)
Format
Delivery Method:
Digital Download (PDF)
📖 Manual Coverage
Systems Covered
Mechanical:
Engine, Fuel System, Cooling System, Transmission, Clutching, Final Drive, Body and Frame
Electrical And Diagnostic:
Electrical System, Wiring Diagrams, Troubleshooting
Procedures Included
Maintenance:
Routine maintenance, service schedules, fluid checks and changes
Repair:
Component removal, installation, adjustment, and overhaul procedures
Troubleshooting:
Diagnostic flowcharts, common problems, and their solutions
Technical Depth
Depth:
Comprehensive (covers all aspects of repair, from basic maintenance to detailed component overhaul)
📊 Manual Specifications
File Format
Format:
PDF (Portable Document Format)
Print Quality
Quality:
Identical to printed retail version, includes high-quality diagrams and images
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Type:
N/A (Digital Download)
Software Requirement
Software:
No special software required; viewable on any standard computer, tablet, or smartphone with PDF reader
⚙️ Engine Specifications
Primary Engine
Engine Type:
Air-cooled, SOHC, 4-stroke
Displacement:
124cc
Bore X Stroke:
54.0 x 54.5 mm
Compression Ratio:
9.0:1 (typical, may vary slightly by year)
Performance
Horsepower:
Approx. 8.5 HP @ 7500 RPM (estimated, manufacturer data not readily available for all years)
Torque:
Approx. 7.0 lb-ft @ 6000 RPM (estimated)
Fuel System
Carburetor:
Teikei Y24P (or similar 24mm constant velocity type)
Fuel Type:
Unleaded gasoline
Fuel Capacity:
2.5 L (0.7 gal)
Ignition
Ignition System:
CDI (Capacitor Discharge Ignition)
Cooling System
Cooling Method:
Forced air cooling
🔧 Transmission
Standard
Transmission Type:
Automatic (CVT - Continuously Variable Transmission)
Gear Selection:
Forward, Neutral, Reverse
Features
Drive System:
Shaft drive
Clutch Type:
Automatic centrifugal clutch
📐 Dimensions
Exterior
Length:
Approx. 1560 mm (61.4 in)
Width:
Approx. 970 mm (38.2 in)
Height:
Approx. 940 mm (37.0 in)
Wheelbase:
Approx. 1030 mm (40.6 in)
Weights
Dry Weight:
Approx. 116 kg (255.7 lbs)
Ground Clearance:
Approx. 120 mm (4.7 in)
🛡️ Safety Features
Ratings
Safety Standards:
Designed for recreational use, not for road use; adherence to ATV safety guidelines recommended.
Active Features
Braking System:
Front: Dual hydraulic disc brakes; Rear: Single hydraulic disc brake.
Passive Features
Lighting:
Headlight, taillight/stoplight.
💡 Technology Features
Infotainment
Features:
Minimalist design focused on core ATV function; no complex infotainment systems.
Driver Assistance
Features:
Basic lighting; no electronic driver aids.
Connectivity
Features:
None.
🔧 Maintenance
Service Intervals
Oil Change:
Every 100 hours or 6 months (refer to manual for specific Yamaha recommended intervals).
Air Filter Cleaning:
Every 30 hours or as needed, depending on operating conditions.
Spark Plug Replacement:
Refer to manual for recommended mileage/hour intervals, typically around 1000-2000 miles or annually.
Fluid Specifications
Engine Oil Type:
Yamalube 4W or equivalent SAE 10W-30 API SG or higher.
Engine Oil Capacity:
Approx. 1.1 L (1.2 US qt) without filter change; 1.2 L (1.3 US qt) with filter change.
Brake Fluid Type:
DOT 3 or DOT 4 hydraulic brake fluid.
Known Issues
Common Problems:
CVT belt wear, carburetor gumming due to infrequent use, electrical connection corrosion, aging fuel lines.
Recommended Practices:
Regular fuel stabilizer use, proper storage procedures, regular inspection of moving parts and electrical connections.
📚 Vehicle History
Brand Heritage
Manufacturer:
Yamaha Motor Company, renowned for its broad range of powersports vehicles and musical instruments.
Model Evolution
Development:
The Breeze 125 was Yamaha's offering in the growing youth and entry-level ATV market, emphasizing ease of use and reliability.
Production
Manufacturing Location:
Likely manufactured in Japan by Yamaha.
🏆 Awards & Recognition
Recognitions
Industry Acclaim:
While specific awards for the Breeze 125 are not widely documented, it was a popular and reliable choice in its segment during its production run.
