🏷️ Basic Information

Make:

Fiat

Model:

Coupé

Model Generation:

Type 175

Production Years Covered:

1993-2000

Chassis Code:

Type 175

👋 Introduction

Segment:

Compact Sports Coupe

Design Philosophy:

Distinctive Italian styling, performance-oriented focus, and accessible pricing.

Key Competitors:

Toyota Celica, Honda Prelude, Mazda MX-6, Mitsubishi Eclipse, Ford Probe, Volkswagen Corrado.

Styling:

Unique angular design by Chris Bangle, prominent 'coupe' line, often praised for its unconventional aesthetics.

Performance Options:

Wide range of engines, including potent naturally aspirated and turbocharged variants, offering spirited performance.

Handling:

Front-wheel drive platform with well-balanced chassis, particularly praised in higher-performance turbo models.

📋 Manual Details

Engine Variants Covered:

1.6L 16V (175A1.000), 1.8L 16V (175A3.000), 2.0L 16V (175A4.000), 2.0L 20V (175BC.000), 1.9L JTD (175A8.000), 2.0L Turbo 16V (175A1.048 - 155PS & 175A1.046 - 192PS), 2.0L Turbo Plus 20V (175BB.000 - 220PS)

Transmission Variants Covered:

5-speed manual, 6-speed manual

Trim Levels Covered:

All trims, including base, Plus, Limited Edition, and Turbo variants

Estimated Page Count:

500+

Type:

Service and Repair Manual

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Engine:

Detailed diagnostics, repair, overhaul, and component specifications for all listed engine variants.

Transmission:

Service and repair procedures for 5-speed and 6-speed manual transmissions, clutch system, and gearbox components.

Brakes:

Hydraulic brake system, ABS (Anti-lock Braking System) components, brake fluid, disc and pad replacement, and caliper servicing.

Suspension:

Front and rear suspension geometry, shock absorbers, springs, bushings, control arms, and wheel alignment.

Steering:

Power steering system, steering rack, tie rods, and steering column components.

Electrical System:

Complete wiring diagrams, fuse box layouts, starter, alternator, battery, lighting systems, ignition system, and ancillary electrical components.

Fuel System:

Fuel pump, injectors, fuel filter, fuel pressure regulator, and fuel tank servicing.

Cooling System:

Radiator, thermostat, water pump, cooling fan, hoses, and coolant specifications.

Exhaust System:

Exhaust manifold, catalytic converter, mufflers, pipes, and mounting hardware.

Body And Chassis:

Body panel removal and installation, doors, hood, trunk, interior trim, and chassis structural components.

HVAC:

Heating, Ventilation, and Air Conditioning system components, refrigerant, and servicing.

Safety Systems:

Airbag system (SRS) diagnostics and replacement, seatbelts.

Maintenance:

Oil and filter changes, spark plug replacement, air filter replacement, brake fluid flush, coolant flush, timing belt replacement (critical for many engines), accessory belt replacement.

Troubleshooting:

Diagnostic charts and step-by-step troubleshooting guides for common electrical and mechanical issues.

Repair:

Detailed instructions for component replacement, overhaul, and adjustment across all major vehicle systems.

Diagnostics:

Engine codes (OBD-I/OBD-II where applicable), sensor testing, and electrical component testing procedures.

Rebuild:

Engine and transmission overhaul procedures with specifications.

Depth:

Comprehensive, suitable for both DIY enthusiasts and professional technicians. Covers everything from basic maintenance to advanced engine and transmission rebuilds.

📊 Manual Specifications

Quality:

High-resolution, searchable PDF with clear diagrams and text.

Searchability:

Full text search enabled for quick access to specific topics.

Printability:

Printable pages for in-depth workshop use.

Output Type:

Digital PDF

Binding:

N/A (Digital Format)

Paper:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Code Example:

175A4.000 (2.0L 16V)

Configuration:

Inline-4, DOHC, 16-valve

Displacement:

1995 cc

Horsepower Example:

139 hp (103 kW) @ 6300 rpm (2.0L 16V)

Torque Example:

180 Nm (133 lb-ft) @ 4300 rpm (2.0L 16V)

Turbocharged Performance:

2.0L Turbo (155PS): 155 hp (115 kW); 2.0L Turbo (192PS): 192 hp (143 kW); 2.0L Turbo Plus (220PS): 220 hp (164 kW)

Induction:

Multi-point fuel injection (MPI) for naturally aspirated, Turbocharged with intercooler for turbo variants.

Fuel Type:

Unleaded Gasoline (Octane rating as per regional requirements)

Timing Belt:

Crucial maintenance item, replacement recommended every 50,000-75,000 miles or 5 years due to potential for catastrophic engine damage if it fails.

🔧 Transmission

Transmission Type Standard:

5-speed Manual Transmission

Transmission Type Optional:

6-speed Manual Transmission (typically on higher performance models like 20V and Turbo Plus)

Clutch Type:

Hydraulic Clutch Actuation

Transmission Fluid Type:

Refer to manual for specific Fiat/API GL-4/GL-5 gear oil specifications. Typically SAE 75W-90.

📐 Dimensions

Length:

Approx. 4293 mm (169.0 in)

Width:

Approx. 1770 mm (69.7 in)

Height:

Approx. 1350 mm (53.1 in)

Wheelbase:

Approx. 2540 mm (100.0 in)

Curb Weight:

Approx. 1300-1450 kg (2866-3197 lbs), varies by engine and trim.

Gross Vehicle Weight Rating:

Refer to vehicle's specific VIN plate.

Trunk Capacity:

Approx. 295 liters (10.4 cu ft)

🛡️ Safety Features

Crash Test Results:

Euro NCAP ratings were not widely standardized or published for this specific era and model. Consult contemporary automotive reviews for available safety assessments.

ABS:

Available on most models, standard on higher trims and turbocharged variants.

Traction Control:

Limited slip differential (LSD) available on some performance models.

Airbags:

Driver and passenger front airbags standard on most models from mid-production onwards.

Seatbelts:

Three-point seatbelts with pre-tensioners (front).

Body Structure:

Designed with crumple zones and reinforced passenger cell for crash energy management.

💡 Technology Features

Audio System:

Factory fitted radio/cassette or CD player, with basic speaker setup. Aftermarket upgrades are common.

Displays:

Digital odometer, trip computer (on some models), climate control display.

ABS:

Anti-lock Braking System (ABS) available, a significant safety feature for its time.

Traction Control:

Traction Control System (TCS) was an option on some later models, particularly with more powerful engines.

Connectivity Options:

Basic connectivity for audio systems; no advanced Bluetooth or smartphone integration from factory.

🔧 Maintenance

Oil Change Interval:

Every 15,000 km (9,000 miles) or 12 months, whichever comes first. Check manual for specific engine types.

Timing Belt Replacement:

Critical: 60,000 km (37,000 miles) or 5 years for 16V engines, 70,000 km (43,000 miles) or 5 years for 20V engines. Always replace water pump and tensioners with the belt.

Spark Plug Replacement:

Typically every 40,000 - 60,000 km (25,000 - 37,000 miles), depending on plug type. Check manual for specific recommendations.

Engine Oil:

API SG/SH or higher, viscosity typically SAE 10W-40 or SAE 15W-40. Consult manual for specific engine requirements and oil capacity (approx. 4.5-5.5 liters).

Coolant:

Ethylene glycol based antifreeze. Fiat specification or equivalent. Capacity approx. 7.5-8.5 liters. Mix ratio 50/50 with distilled water.

Brake Fluid:

DOT 3 or DOT 4, depending on original specification. Capacity approx. 0.7 liters.

Power Steering Fluid:

ATF Dexron II or equivalent. Capacity approx. 1.0 liter.

Common Faults:

Timing belt failure (if not replaced on schedule), electrical gremlins (particularly minor sensor issues or connectors), suspension wear (bushings, ball joints), turbocharger issues on high-mileage turbo models, rust (especially wheel arches, sills, and rear chassis legs), minor interior trim rattles.

Turbo Specific Concerns:

Turbocharger seal wear leading to oil consumption or smoke, intercooler hose leaks, wastegate issues.

Engine Performance:

Idle control valve issues, MAF sensor faults, ignition coil failures.

📚 Vehicle History

Brand Focus:

Fiat has a long history of producing stylish and sporty vehicles, often with innovative designs.

Launch Year:

1993

Design Evolution:

Initial design by Chris Bangle, later models received minor styling tweaks and interior updates. The 20-valve engine and more powerful turbo variants marked significant performance upgrades.

Engine Updates:

Introduction of the 5-cylinder 20-valve engine and more powerful turbo engines in later years.

Production Period:

1993 - 2000

Manufacturing Location:

Turin, Italy

🏆 Awards & Recognition

Design Awards:

While specific awards are not prominently documented for the Fiat Coupé, its distinctive design by Chris Bangle was a significant talking point and contributed to its unique market appeal.

Performance Ratings:

Consistently praised in automotive press for its strong performance, especially the Turbo models, offering excellent value for money in the sports coupe segment.

Production Standards:

Manufactured to European automotive production standards of the period.
