AUDI AVANT RS2 CAR Service & Repair Manual (1994 1995)-PDF
Prix habituel
$16.99
Prix soldé
$16.99
Prix habituel
Prix unitaire
/ par
Vente
Épuisé
The Audi Avant RS2, produced between 1994 and 1995, represents a significant chapter in Audi's performance heritage. This high-performance luxury estate car, based on the Audi S2 Avant (Typ 8C)...
The Audi Avant RS2, produced between 1994 and 1995, represents a significant chapter in Audi's performance heritage. This high-performance luxury estate car, based on the Audi S2 Avant (Typ 8C) and co-developed with Porsche, is a limited-production homologation special. It features a potent 2.2-liter inline 5-cylinder turbocharged engine, delivering 315 PS and 354 lb-ft of torque, paired with a 6-speed manual transmission and Audi's renowned quattro all-wheel-drive system. Its unique selling proposition lies in its exclusive nature, combining motorsport-derived engineering with practicality, making it a highly desirable modern classic.
This comprehensive service and repair manual provides detailed instructions for maintaining and repairing the Audi Avant RS2 (Typ 8C) for the 1994-1995 model years. It covers all essential systems, including engine overhaul, brakes, suspension, steering, transmission, electrical diagnostics, bodywork, and climate control. The manual offers factory maintenance schedules, step-by-step repair procedures, and troubleshooting guides, making it an invaluable resource for owners and technicians alike. Its detailed illustrations, diagrams, and searchable text ensure accurate diagnosis and efficient repair, enabling owners to preserve the performance and integrity of this rare vehicle.
🏷️ Basic Information
Identification
Make:
Audi
Model:
Avant RS2
Model Years Covered:
1994-1995
Vehicle Type:
Station Wagon / Estate
Codes
Chassis Code:
Typ 8C
👋 Introduction
Market Position
Segment:
High-performance luxury estate car.
Competitive Analysis
Key Competitors Era:
BMW M5 Touring (E34), Mercedes-Benz E36 AMG Estate (S124), potentially other limited-production performance estates.
Key Features
Unique Selling Proposition:
Exclusive, limited-production homologation special based on the Audi 80/S2 Avant, co-developed with Porsche, featuring a potent 5-cylinder engine and quattro all-wheel drive.
Value Proposition:
Enables owners to perform maintenance and repairs themselves, saving significant costs compared to specialist workshops for this rare vehicle.
📋 Manual Details
Coverage Areas
General Coverage:
Complete official service and repair manual for the Audi Avant RS2, covering all models and engines for the 1994-1995 model years.
Page Count
Estimated Page Count:
Hundreds (implied by detailed illustrations, diagrams, and step-by-step instructions)
Manual Type
Manual Type:
Service and Repair Manual
Language
Language:
English
Format
File Format:
PDF
📖 Manual Coverage
Systems Covered
Engine:
Engine overhaul and rebuilding, engine performance, firing orders, serpentine belt routings, timing belt service procedures.
Repair procedures, complete disassembly based instructions, refurbishment, restoration.
Diagnostics:
Troubleshooting and diagnostics, computer diagnostic trouble tree charts.
Timing Belt:
Timing belt replacement, timing belt service procedures.
Drivetrain:
U-joint and CV-joint service procedures.
Technical Depth
Depth Of Information:
Comprehensive, covering every single detail. Suitable for do-it-yourselfers and experienced mechanics. Includes step-by-step instructions based on complete disassembly.
📊 Manual Specifications
File Format
File Type:
PDF
Searchability:
Searchable text
Bookmarking:
Bookmarked
Print Quality
Printable:
Fully printable pages
Zoom Capability:
Zoom in/out capability
Binding Type
Binding:
Digital (PDF) - allows for burning to CD-ROM
Paper Type
Paper Type:
N/A (Digital Format)
Delivery
Delivery Method:
Instant Download
Compatibility
Operating Systems:
All versions of Windows & Mac
Software Requirements
Required Software:
Adobe PDF Reader & WinZip
⚙️ Engine Specifications
Primary Engine
Engine Code:
ABY
Configuration:
Inline 5-cylinder, 20-valve, turbocharged and intercooled.
Displacement:
2226 cc (2.2 Liters)
Performance
Horsepower:
315 PS (310 hp; 232 kW) at 6500 rpm
Torque:
480 Nm (354 lb-ft) at 3000 rpm
Fuel System
Fuel Delivery:
Bosch Motronic M2.3.2 Fuel Injection
Turbocharger:
Porsche K24 Turbocharger
Engine Management
ECU Type:
Bosch Motronic M2.3.2
Engine Internals
Bore X Stroke:
81.0 mm x 86.4 mm
Compression Ratio:
8.5:1
🔧 Transmission
Standard
Transmission Type:
6-speed manual transmission
Drive Type:
All-wheel drive (Quattro)
Features
Differential Lock:
Viscous coupling center differential, potentially with rear limited-slip differential (check manual for specifics).
📐 Dimensions
Exterior
Length:
4407 mm (173.5 in)
Width:
1770 mm (69.7 in)
Height:
1418 mm (55.8 in)
Weights
Curb Weight:
Approx. 1560 kg (3439 lbs)
Gross Vehicle Weight:
Approx. 2100 kg (4630 lbs)
🛡️ Safety Features
Passive Features
Airbags:
Driver and front passenger airbags (standard).
Seatbelts:
Three-point inertia-reel seatbelts with front belt tensioners.
Active Features
ABS:
Anti-lock Braking System (ABS) - standard.
Traction Control:
Traction Control System (ASR - Anti-Slip Regulation) may be present, check manual for exact specification.
💡 Technology Features
Infotainment
Audio System:
Likely offered with Audi's premium sound systems of the era, possibly with CD player integration or upgraded units.
Driver Assistance
Cruise Control:
Standard feature on RS models for comfortable long-distance driving.
Connectivity
Phone Integration:
Limited by era; potential for dealer-installed car phone or aftermarket solutions.
Performance Monitoring
Gauges:
Additional performance gauges likely integrated into the dashboard (e.g., boost gauge).
🔧 Maintenance
Service Intervals
Oil Change Interval:
Refer to factory maintenance schedule in manual (typically 7,500-10,000 miles or 12,000-15,000 km).
Timing Belt Replacement Interval:
Refer to factory schedule in manual (critical for this engine, typically 60,000-80,000 miles or 96,000-128,000 km).
Fluid Specifications
Engine Oil Type:
Synthetic 5W-40 or 5W-50 is recommended for high-performance applications. Consult manual for exact OEM specification.
Coolant:
G12 or equivalent ethylene glycol-based coolant with corrosion inhibitors. Consult manual for specific Audi standard.
Transmission Fluid:
Refer to manual for specific gear oil specification for the 6-speed manual transmission.
Brake Fluid:
DOT 4 recommended. Consult manual for specific Audi standard.
Known Issues
Common Wear Items:
Turbocharger wear, ignition coil packs, fuel injectors, suspension bushings, CV joints, potential for oil leaks from seals and gaskets due to age.
Maintenance Criticality:
Strict adherence to timing belt replacement intervals is crucial to prevent catastrophic engine damage.
📚 Vehicle History
Brand Heritage
Audi Performance Division:
Traces lineage to Audi Sport GmbH (now Audi Sport), known for motorsport success and high-performance road cars.
Model Evolution
Based On:
Audi S2 Avant (Type 8C).
Development Collaboration:
Co-developed and built by Porsche in their Rossle-Bann factory in Germany.
Production
Production Period:
1994-1996
Production Numbers:
Limited production, approximately 1,821 units built in total.
🏆 Awards & Recognition
Recognitions
Automotive Journalism:
Received high praise from automotive journalists of the era for its unique blend of performance, practicality, and exclusivity.
Collectible Status:
Considered a modern classic and a highly desirable collector's car among Audi enthusiasts.
