🏷️ Basic Information

Make:

Mazda

Model:

MX-6

Year:

1994

Chassis Code:

GE

👋 Introduction

Target Audience:

DIY enthusiasts, independent repair shops, Mazda MX-6 owners seeking to perform maintenance and repairs.

Advantage Over Print:

Instant access, searchability, interactive diagrams, up-to-date information (depending on software updates), cost-effectiveness compared to some print versions.

Licensing:

Officially licensed, derived from OE (Original Equipment) materials.

User Interface:

User-friendly interface, easy navigation, push-button access to information.

Cost Savings:

Enables significant cost savings by performing repairs and maintenance independently.

📋 Manual Details

Primary Coverage:

1994 Mazda MX-6 Service and Repair

Secondary Coverage:

Official OE licensed information

Estimated Page Count:

Varies by software version, typically thousands of pages equivalent in digital format

Type:

Digital Service and Repair Manual Software

Language:

English

Format:

Online Software/Web-based Access

Access Duration:

1 Year (with options for renewal)

📖 Manual Coverage

Engine Mechanical:

Engine removal/installation, cylinder head, crankshaft, pistons, connecting rods, lubrication system, cooling system, timing belt/chain.

Engine Management:

Fuel system, ignition system, emission control systems, engine control unit (ECU) diagnostics and parameters, sensor and actuator testing.

Transmission:

Manual transmission (M/T) and Automatic transmission (A/T) overhaul, removal/installation, operation, and diagnostics.

Drivetrain:

Front-wheel drive (FWD) system, driveshafts, constant velocity (CV) joints, differential, transaxle.

Brakes:

Hydraulic system, brake fluid, master cylinder, brake boosters, front and rear brake components (discs, calipers, pads), parking brake, ABS system.

Steering:

Power steering system, steering gear, steering column, tie rods, wheel alignment specifications.

Suspension:

Front and rear suspension components, shock absorbers, struts, springs, control arms, sway bars, bushings, wheel bearing replacement.

Electrical System:

Battery, charging system (alternator), starting system (starter motor), lighting system, horn, wipers, power accessories.

Body And Chassis:

Body panels, doors, hood, trunk, interior trim, glass, bumpers, structural components.

HVAC:

Heating, ventilation, and air conditioning (HVAC) system diagnosis, component replacement, refrigerant handling (where applicable and legally permissible).

Wiring Diagrams:

Complete electrical schematic diagrams for various systems.

Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotation, spark plug replacement, brake pad inspection.

Diagnostics:

Step-by-step troubleshooting guides for common and complex issues, diagnostic trouble codes (DTCs) interpretation, component testing procedures.

Repair:

Detailed instructions for component removal, disassembly, inspection, repair, reassembly, and installation.

Adjustment:

Torque specifications for all fasteners, idle speed adjustments, brake adjustments, clutch adjustments.

Rebuilds:

Complete overhaul procedures for major components like engines and transmissions.

Depth:

Comprehensive, covering routine maintenance to complete engine and transmission rebuilds, including electrical system diagnostics.

📊 Manual Specifications

File Type:

Proprietary software/web access

Compatibility:

PC, Laptop, Smartphone, Tablet with internet connection and web browser.

Printability:

Information is accessible for printing specific sections.

Binding:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Code:

FS-DE (2.0L DOHC)

Engine Type:

Naturally Aspirated Inline 4-Cylinder, DOHC, 16 Valves

Displacement:

1998 cc (2.0 Liters)

Bore X Stroke:

83.0 mm x 92.0 mm

Compression Ratio:

9.4:1

Horsepower:

120 HP @ 5500 RPM (approximate, may vary slightly by market)

Torque:

125 lb-ft @ 4500 RPM (approximate, may vary slightly by market)

Fuel Delivery:

Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline (Octane rating as specified by manufacturer, typically 87 or higher)

Fuel Pump Type:

In-tank electric

🔧 Transmission

Type:

5-Speed Manual Transmission (M/T)

Type:

4-Speed Automatic Transmission (A/T)

Fluid Type Mt:

API GL-4 or GL-5 Gear Oil (viscosity as per manual, e.g., 75W-90)

Fluid Type At:

Dexron III or equivalent ATF (Automatic Transmission Fluid)

Clutch Type:

Hydraulically operated dry single-plate clutch

📐 Dimensions

Length:

Approximately 4620 mm (181.9 inches)

Width:

Approximately 1730 mm (68.1 inches)

Height:

Approximately 1315 mm (51.8 inches)

Wheelbase:

Approximately 2615 mm (103.0 inches)

Front Track:

Approximately 1475 mm (58.1 inches)

Rear Track:

Approximately 1460 mm (57.5 inches)

Curb Weight:

Approximately 1300-1400 kg (2866-3086 lbs), depending on transmission and options.

Gross Vehicle Weight Rating:

Refer to vehicle's VIN plate or owner's manual for specific GVWR.

🛡️ Safety Features

NHTSA Frontal Impact:

Not explicitly rated or data unavailable for this specific model year and market.

IIHS Crash Test:

Data for this specific model year and market may be limited or unavailable.

ABS:

Anti-lock Braking System (ABS) available as an option on some trims.

Airbags:

Driver-side airbag standard; Passenger airbag typically optional or not available for 1994 model.

Seatbelts:

3-point front and rear seatbelts.

Crumple Zones:

Designed with front and rear crumple zones for energy absorption.

💡 Technology Features

Audio System:

Factory AM/FM cassette player, optional CD player. Speaker configurations varied by trim level.

Cruise Control:

Standard on most higher trim levels.

Power Windows Locks:

Power windows and door locks were common options or standard on higher trims.

Phone Integration:

N/A (No factory integration for mobile phones or smart devices).

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions).

Engine Oil Filter:

Replace with every oil change.

Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km).

Spark Plugs:

Replace approximately every 30,000 miles (48,000 km) with NGK or Denso plugs (e.g., NGK BKR5E-11).

Coolant Flush:

Every 30,000 miles (48,000 km) or 2 years.

Timing Belt:

Crucial interval: Replace every 60,000 miles (96,000 km) or 4 years, as it is an interference engine. Failure can cause catastrophic engine damage.

Engine Oil:

SAE 5W-30 or 5W-40 API SG or higher classification. Check owner's manual for specific recommendations.

Engine Oil Capacity:

Approximately 4.0 Liters (4.2 US Quarts) with filter change.

Coolant Type:

Ethylene glycol-based antifreeze, typically a 50/50 mix with distilled water. Use Mazda Genuine Long Life Coolant or equivalent.

Brake Fluid:

DOT 3 or DOT 4 automotive brake fluid.

Power Steering Fluid:

Dexron III ATF or specific power steering fluid as per manual.

Timing Belt Failure:

High risk if not replaced at recommended intervals due to interference design.

Suspension Wear:

Common wear items include bushings, ball joints, and tie rod ends leading to clunks or poor handling.

Power Steering Leaks:

Potential for leaks from hoses or the power steering pump.

HVAC Blower Motor:

Blower motor resistor or the motor itself can fail over time.

Window Regulators:

Manual or power window regulators can become stiff or break.

Cv Joint Boots:

Torn CV joint boots can lead to premature wear and failure of the joints.

📚 Vehicle History

Mazda Philosophy:

Mazda's focus on 'Zoom-Zoom' driving dynamics, driver engagement, and distinctive styling.

Mx 6 Lineage:

The MX-6 nameplate has a history dating back to the original 1980s coupe, known for its sporty styling and front-wheel-drive performance. The 1994 model represents the second generation of the MX-6.

Second Generation Platform:

Based on the Mazda Capella/Cronos platform, sharing mechanicals with the Ford Probe.

Production Years:

Second generation (GE): 1991-1997

Manufacturing Location:

Japan (primarily Hiroshima)

🏆 Awards & Recognition

Model Specific Awards:

While the 1994 MX-6 itself may not have garnered specific, widely publicized awards, Mazda as a brand was recognized for its engineering and sporty vehicles during this era.
