1995-2004 Yamaha YFM 350 FX Wolverine Workshop Service Repair Manual

$16.99
$16.99
The YFM 350 FX Wolverine, also known as the Wolverine, is a robust 4x4 utility All-Terrain Vehicle (ATV) produced from 1995 to 2004. Renowned for its reliability and versatility, this...
22 people are viewing this right now
Taper: Atv
Distributeur:
Yamaha
UGS: 56860
Mots clés: 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 ATV Featured Powersports Wolverine Models Yamaha YFM 350 FX Wolverine
1995-2004 Yamaha YFM 350 FX Wolverine Workshop Service Repair Manual1995-2004 Yamaha YFM 350 FX Wolverine Workshop Service Repair Manual1995-2004 Yamaha YFM 350 FX Wolverine Workshop Service Repair Manual1995-2004 Yamaha YFM 350 FX Wolverine Workshop Service Repair Manual
The YFM 350 FX Wolverine, also known as the Wolverine, is a robust 4x4 utility All-Terrain Vehicle (ATV) produced from 1995 to 2004. Renowned for its reliability and versatility, this model features a proven air-cooled 348cc engine, independent front suspension for enhanced comfort and handling, and a rugged On-Command 4WD system. Its design prioritizes durability and practical application, making it a capable choice for recreational trail riding and light utility tasks. The strong heritage in powersports engineering is evident in the Wolverine's balanced performance and enduring build quality. This comprehensive Workshop Service Repair Manual provides detailed guidance for the maintenance, troubleshooting, and repair of the YFM 350 FX Wolverine (4x4) models from 1995 through 2004. Covering all major systems, including the engine, transmission, chassis, brakes, and electrical components, this manual offers factory-level detail with step-by-step instructions and numerous illustrations. It is an essential resource for both DIY enthusiasts and professional technicians seeking to ensure the optimal performance and longevity of their vehicle, facilitating everything from routine service to complete component overhauls.
🏷️ Basic Information
Identification
Make:
Yamaha
Model:
YFM 350 FX Wolverine
Model Nickname:
Wolverine
Codes
Product Id:
YAM-YFM350FX-9504-WSRM-PDF
👋 Introduction
Market Position
Vehicle Segment:
Utility All-Terrain Vehicle (ATV)
Key Market Appeal:
Reliability, 4x4 capability, versatility for recreational and light utility use
Competitive Analysis
Competitors:
Honda FourTrax 300/350, Kawasaki Bayou 300/360, Suzuki QuadSport 250/300, Polaris Sportsman 300/335
Key Features
Vehicle Selling Points:
Rugged 4x4 system, proven air-cooled engine, independent front suspension (IFS), comfortable ride, durability
Manual Value Proposition
Benefit Statement:
Inexpensive way to keep your vehicle working properly, empowering owners for self-maintenance and repair
Content Value:
Detailed illustrations and step-by-step instructions for efficient and accurate service
📋 Manual Details
Coverage Areas
Vehicle Years:
1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
Vehicle Models Covered:
YFM350FX Wolverine (4x4)
Page Count
Estimated Pages:
Hundreds (specific count not provided, but described as '100 percents complete and intact' with 'hundreds of photos and illustrations')
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF Download
📖 Manual Coverage
Systems Covered
Engine:
Complete engine overhaul, disassembly, inspection, assembly, troubleshooting, tuning
Transmission:
Clutch, gearbox, drive shafts, differentials (front and rear), operation, maintenance, repair
Chassis And Suspension:
Frame, front and rear suspension, shock absorbers, steering system, wheel alignment
Brakes:
Hydraulic system, calipers, master cylinder, brake lines, parking brake, bleeding procedures
Electrical System:
Ignition system, charging system (stator, regulator/rectifier), starter motor, battery, lighting, wiring diagrams, switches, fuses
Fuel System:
Carburetor (Mikuni), fuel pump, fuel lines, fuel tank, air filter maintenance
Cooling System:
Air cooling system design and maintenance
Body And Plastics:
Body panels, fenders, seat, handlebars, storage compartment
Drive Train:
Axles, CV joints, drive system for 4x4 engagement
Procedures Included
Maintenance:
Regular scheduled maintenance, oil changes, filter replacements, lubrication, brake checks, tire pressure
Troubleshooting:
Diagnostic procedures for common problems, symptom analysis, step-by-step fault finding
Repair:
Detailed instructions for component disassembly, repair, and reassembly
Rebuilds:
Complete engine, transmission, and carburetor rebuild procedures
Adjustment:
Carburetor tuning, valve clearance adjustments, brake lever and cable adjustments
Installation:
Guidance for replacing major components and accessories
Technical Depth
Depth:
Comprehensive, from basic maintenance to complete engine rebuilds and advanced diagnostics
Detail Level:
Factory-level detail with step-by-step instructions and photographic guidance
Target Audience:
Both DIY enthusiasts and professional mechanics
📊 Manual Specifications
File Format
Format Details:
Adobe PDF, compatible with all PC-based Windows operating systems and Mac
Searchability:
Likely text-searchable (standard for good quality PDF manuals)
Print Quality
Printability:
All pages are printable
Binding Type
Binding:
N/A (Digital PDF format)
Paper Type
Paper Type:
N/A (Digital PDF format)
Completeness
Completeness Statement:
100% complete and intact
⚙️ Engine Specifications
Primary Engine
Engine Type:
4-stroke, SOHC, air-cooled
Displacement:
348cc
Bore X Stroke:
83.0 mm x 64.5 mm
Compression Ratio:
9.2:1
Valve Clearance Intake:
0.08 - 0.12 mm (cold)
Valve Clearance Exhaust:
0.13 - 0.17 mm (cold)
Performance
Horsepower:
Approximately 18-20 HP (estimated, specific figures not in product description)
Torque:
Not specified in product description
Fuel System
Carburetor Type:
Mikuni BSR33 (single)
Fuel Type:
Unleaded gasoline
Fuel Tank Capacity:
Approx. 3.2 US gal (12 Liters)
Oil Specifications
Engine Oil Type:
Yamalube 4, SAE 20W-40 (or equivalent API SE, SF or SG service classification)
Engine Oil Capacity:
1.80 L (1.9 US qt), 2.00 L (2.1 US qt) with filter change
🔧 Transmission
Standard
Transmission Type:
5-speed manual with automatic clutch and reverse
Optional
Optional Transmission:
N/A
Features
Drive System:
On-Command 4WD (selectable 2WD/4WD)
Final Drive:
Shaft drive (front and rear)
Oil Specifications
Transmission Oil Type:
Yamalube SAE 80 API GL-4
Transmission Oil Capacity:
0.75 L (0.79 US qt)
📐 Dimensions
Exterior
Length:
Approx. 77.4 in (1965 mm)
Width:
Approx. 43.5 in (1105 mm)
Height:
Approx. 43.1 in (1095 mm)
Wheelbase:
Approx. 49.2 in (1250 mm)
Ground Clearance:
Approx. 6.3 in (160 mm)
Weights
Dry Weight:
Approx. 538 lbs (244 kg)
Curb Weight:
Not specified in product description
Cargo
Front Rack Capacity:
Approx. 88 lbs (40 kg)
Rear Rack Capacity:
Approx. 176 lbs (80 kg)
🛡️ Safety Features
Ratings
Safety Ratings:
N/A (ATVs are not typically rated by government safety bodies like NHTSA for passenger vehicles)
Active Features
Braking System:
Hydraulic disc brakes front and rear, sealed drum brake (rear parking)
Tire Specifications Front:
AT25x8-12
Tire Specifications Rear:
AT25x10-12
Passive Features
Lighting:
Dual halogen headlights, taillight/brake light
Handlebars:
Contoured handlebars with padded center
💡 Technology Features
Infotainment
Infotainment System:
N/A (Basic utility ATV, no onboard infotainment system)
Driver Assistance
Driver Assistance Features:
N/A
Connectivity
Connectivity Features:
N/A
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 3000 km or 12 months (whichever comes first), or more frequently under severe use.
Spark Plug Replacement:
Every 6000 km or 24 months.
Air Filter Cleaning:
Every 1000 km (more often in dusty conditions).
Valve Clearance Check:
Every 6000 km or 24 months.
Transmission Oil Change:
Every 6000 km or 24 months.
Fluid Specifications
Brake Fluid:
DOT 3 or DOT 4 brake fluid
Coolant:
N/A (Air-cooled engine)
Known Issues
Common Wear Items:
CV joint boots, wheel bearings, brake pads, starter motor brushes
Carburetor Issues:
Potential for jetting issues with aftermarket exhaust/air filter modifications, pilot jet clogging if fuel is left sitting for extended periods.
4X4 System:
Proper maintenance of the 4x4 engagement mechanism is crucial; occasional issues with the actuator or linkage can occur if not serviced.
📚 Vehicle History
Brand Heritage
Manufacturer Specialty:
Yamaha Motor Company is renowned for its high-performance motorcycles, marine products, and powersports vehicles, known for engineering innovation and reliability.
Model Evolution
Wolverine Lineage:
The YFM350FX Wolverine was a popular mid-size utility ATV in Yamaha's lineup, offering a balance of performance, 4x4 capability, and comfort.
Key Innovations For Era:
Independent Front Suspension (IFS) offered a significant improvement in ride quality and handling over solid-axle designs prevalent at the time.
Production
Production Period:
1995-2004
Manufacturing Location:
Primarily Japan (Yamaha facilities)
🏆 Awards & Recognition
Recognitions
Awards:
Specific awards not mentioned in product description, but the model was generally well-regarded for its class during its production run.
Ratings
Owner Satisfaction:
High owner satisfaction generally attributed to Yamaha's reputation for reliability and the Wolverine's practical capabilities.
Sale
