🏷️ Basic Information

Make:

Holden

Model:

Astra G

Model Years Covered:

1998-2004

Platform Code:

GM T-body (Vauxhall/Opel Astra Mk IV)

👋 Introduction

Vehicle Segment:

Compact/Small family car

Key Competitors:

Ford Focus, Toyota Corolla, Mazda 323/Familia, Hyundai Elantra, Mitsubishi Lancer.

Manual Benefits:

Digital format with zoom capability for clarity, comprehensive coverage, easy part identification via page numbers. Directly based on original factory data.

📋 Manual Details

Primary Coverage:

Service, Maintenance, Repair

Specific Systems Listed:

Gearbox & Clutch, Electric Starter, Crankshaft/Transmission/Balancer, Wheels & Tyres, Electrical System, Braking System, Suspension, Engine Lubrication and Cooling, Ignition System, Transmission System, Rear Wheel System, Cylinder Head/Valves, Cooling system, Engine Removal and Installation, Battery/Charging System, Chassis, Lights/Meters/Switches, Frame/Body Panels/Exhaust System, Alternator/Starter Clutch, Fenders and Exhaust Pipe, Front Wheel and Steering System, Engine Fuel System, Crankcase/Piston/Cylinder, Engine Combustion System, Fuel Injection System, Body & Fixtures

Estimated Page Count:

Not specified, but extensive coverage implied by listed topics.

Type:

Factory Service Manual / Repair Manual

Language:

Likely English, based on product description and typical Holden market.

Format:

PDF Download

📖 Manual Coverage

Powertrain:

Engine (lubrication, cooling, ignition, fuel system, combustion, fuel injection, cylinder head, valves, crankcase, piston, cylinder), Transmission (gearbox, clutch, transmission system, rear wheel system, front wheel system), Starter, Alternator/Starter Clutch, Battery/Charging System

Chassis And Suspension:

Braking system, Suspension, Wheels & Tyres, Chassis, Frame, Steering System

Electrical And Body:

Electrical System, Wiring Diagrams, Lights/Meters/Switches, Body & Fixtures, Frame/Body Panels/Exhaust System, Fenders and Exhaust Pipe

Maintenance And Checks:

Periodic checks & Adjustments, Maintenance, Lubrication System

Repair And Rebuild:

Engine Removal and Installation, Gearbox & Clutch repair, Transmission repair, Brake system repair, Suspension repair, Steering system repair, Electrical component repair, Body panel repair, Exhaust system repair

Diagnostics And Troubleshooting:

Troubleshooting (general and system-specific)

Depth:

Comprehensive, covering diagnostics, repair, and maintenance procedures for all major vehicle systems. Likely includes detailed schematics, specifications, and step-by-step instructions suitable for professional technicians and advanced DIY enthusiasts.

📊 Manual Specifications

Digital Format:

PDF

Clarity And Usability:

High clarity due to zoom capability on computer. Presented as an electronic version of original factory documentation.

Binding:

N/A (Digital PDF)

Paper Quality:

N/A (Digital PDF)

Operating Systems:

Windows 2000 Pro SP3/SP4 (32-bit), Windows XP Pro SP2 (32-bit). Not compatible with 64-bit operating systems.

Hardware:

Pentium 166 MHz (Win 2000) / Pentium II 300 MHz (Win XP), 48 MB RAM (Win 2000) / 64 MB RAM (Win XP), 3 GB Free Hard Disk Space.

Method:

Extract ISO, Burn to DVD (Image Mode) or Mount to Virtual Drive, Run AUTORUN.EXE. Select STANDALONE installation mode. User Name: TIS, Password: (BLANK/NONE).

⚙️ Engine Specifications

Engine Options:

Likely includes a range of 4-cylinder petrol engines (e.g., 1.4L, 1.6L, 1.8L, 2.0L) and potentially diesel variants common in the Astra G/Mk IV platform. Specific engine codes not provided in product info.

Horsepower And Torque:

Varies by engine. e.g., 1.6L Ecotec (X16XEL) typically around 100 PS (99 hp), 1.8L Ecotec (X18XE1) around 115 PS (114 hp). Manual would detail specific figures per engine variant.

Fuel Delivery:

Electronic Fuel Injection (EFI), likely multi-point injection (MPI) for most variants.

🔧 Transmission

Gearbox Type:

Likely a 5-speed manual transmission as standard across many variants.

Automatic Transmission:

Optional 4-speed automatic transmission was available on many Astra G models.

Clutch Type:

Hydraulically operated dry single-plate clutch for manual variants.

📐 Dimensions

Body Styles:

Hatchback (3-door and 5-door), Saloon (4-door), Estate/Wagon (5-door), Coupe (2-door).

Length Width Height:

Varies by body style and specific model. e.g., 5-door hatchback ~4250 mm (L) x ~1700 mm (W) x ~1460 mm (H). Manual would contain precise figures.

Curb Weight:

Typically ranges from 1150 kg to 1350 kg depending on body style and engine. Manual will provide specific weight figures.

🛡️ Safety Features

Crash Test Results:

Euro NCAP ratings for the Astra G (Mk IV) varied by year and equipment, but generally achieved 3-4 stars for adult occupant protection. Manual will not detail specific crash ratings but covers safety systems.

Braking Systems:

Front ventilated discs, rear drums standard. Higher trims or performance variants may have rear discs. ABS (Anti-lock Braking System) was often an option or standard on higher trims. Manual covers ABS operation and components.

Restraints:

Front airbags standard on most models from 1999 onwards. Side airbags were optional. Seatbelt pre-tensioners. Manual details airbag system and seatbelt maintenance.

💡 Technology Features

Audio System:

Factory fitted radios with CD or cassette players. Speakers in doors and rear. Manual covers removal, installation, and wiring of the audio system.

ABS System:

Optional ABS system. Manual provides detailed diagnostics and component testing for the ABS control module, sensors, and hydraulic unit.

Cruise Control:

Optional cruise control system on some higher-spec models. Manual includes wiring diagrams and troubleshooting for the cruise control system.

🔧 Maintenance

Oil Change Recommendations:

Typically 10,000 - 15,000 km or 12 months, whichever comes first, depending on driving conditions and oil type used. Manual provides precise schedules.

Engine Oil:

Likely specifies GM-LL-A-025 or ACEA A3/B3/B4 compliant synthetic or semi-synthetic oil, viscosity grade 5W-30 or 10W-40. Manual will list exact specifications for each engine.

Coolant:

GM-specified OAT (Organic Acid Technology) coolant, typically purple or pink (e.g., Dex-Cool equivalent). Manual will specify part numbers and capacity.

Transmission Fluid Manual:

Manual Gearbox Oil, typically GL-4 rated, viscosity grade 75W-90 or 80W-90. Manual will specify correct type and capacity.

Transmission Fluid Automatic:

GM DEXRON-III (or compatible) ATF. Manual will specify correct type and capacity.

Common Wear Items:

Ignition coils (especially on early Ecotec engines), lambda sensors, suspension bushes, exhaust system corrosion, window regulators, heater control valves. Manual provides diagnostic steps for these.

Common Mechanical Faults:

Timing belt replacement intervals are critical (typically 60,000 miles / 100,000 km, though manual will confirm). Head gasket issues on some higher mileage engines. Manual details engine rebuild procedures.

📚 Vehicle History

Holden Context:

Holden, an Australian automotive manufacturer, often rebadged and locally manufactured vehicles from its parent company, General Motors (GM), including Opel models. The Astra G was Holden's version of the European Opel/Vauxhall Astra Mk IV.

Platform Origin:

The Holden Astra G is a rebadged version of the third generation Opel/Vauxhall Astra (internally codenamed Astra G, and referred to as Astra Mk IV in the UK). It replaced the Holden Nova and was a significant step forward in design and technology for Holden's small car offering.

Manufacturing Locations:

Primarily manufactured in Europe by Opel/Vauxhall. Holden imported and sold these vehicles in Australia and New Zealand.

🏆 Awards & Recognition

Model Reception:

The Astra G platform was generally well-received for its improved refinement, ride comfort, and handling compared to its predecessor. While specific awards for the Holden Astra G in Australia may be limited, the European models often received praise in their respective markets.
