2003 Harley Davidson DYNA GLIDE Workshop Service Repair MANU

Prix habituel: $16.99
Prix soldé: $16.99
Prix habituel
Prix unitaire: par

26 people are viewing this right now

Taper: Motorcycle

Distributeur:

UGS: 146350

Mots clés: 2003 DYNA GLIDE Harley Davidson Motorcycle Motorcycles Super Glide

Variantes de produits

Description

The 2003 Dyna Glide, including the FXDX Super Glide Sport and FXDX-T Super Glide T-Sport variants, represents a significant offering in the cruiser segment, appealing to riders who value performance and customization. Built upon the robust Dyna platform, known for its capable chassis, these models are powered by the iconic Twin Cam 88 engine, displacing 1450cc. The FXDX models further distinguish themselves with enhanced suspension systems and superior braking capabilities, featuring triple disc brakes, while the FXDX-T adds touring-oriented fairings and saddlebags for increased versatility. These motorcycles are engineered for riders seeking a blend of classic American V-twin power and dynamic handling. This comprehensive Factory Workshop Service Repair Manual provides detailed, English-language guidance for the 2003 Dyna Glide. It covers all essential aspects of maintenance and repair, from routine procedures like oil changes and brake inspections to in-depth engine and transmission rebuilds. The manual includes extensive information on the electrical system, fuel injection, chassis, suspension, and bodywork, along with troubleshooting guides, diagnostic charts, and specifications for specialized tools. This resource is an invaluable tool for owners, technicians, and mechanics to ensure the optimal performance, reliability, and longevity of their Dyna Glide motorcycles.

🏷️ Basic Information

Identification

Make:

Harley-Davidson

Model:

Dyna Glide

Year:

Sub Model:

FXDX Super Glide Sport, FXDX-T Super Glide T-Sport

Codes

Engine Family:

Twin Cam 88

👋 Introduction

Market Position

Model Segment:

Cruiser/Power Cruiser

Target Audience:

Riders seeking performance-oriented, customizable Harley-Davidson motorcycles.

Competitive Analysis

Competitors:

Other V-twin cruisers from American and Japanese manufacturers, e.g., Indian Chief, Victory Cruiser, select Yamaha, Suzuki, and Kawasaki models.

Key Features

Dyna Platform:

Known for its robust chassis and performance capabilities within the Harley-Davidson lineup.

Fxdx Enhancements:

The FXDX Super Glide Sport featured upgraded suspension (dual adjustable front forks, dual rear shocks) and triple disc brakes, differentiating it from standard Dyna models.

Fxdx T Enhancements:

The FXDX-T Super Glide T-Sport added a fork-mounted fairing and detachable saddlebags for increased touring capability and wind protection.

📋 Manual Details

Coverage Areas

Primary Coverage:

2003 Harley-Davidson Dyna Glide models

Secondary Coverage:

Related Dyna Glide variants from previous years may have applicable information due to platform similarities.

Page Count

Estimated Page Count:

Likely 500+ pages (typical for comprehensive factory workshop manuals).

Manual Type

Manual Type:

Factory Workshop Service Repair Manual

Language

Language:

English

Format

File Format:

Digital Delivery:

Instant Download

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine teardown, assembly, inspection, tuning, lubrication, cooling system.

Fuel System:

Carburetor (if applicable) or Fuel Injection system, fuel pump, fuel lines, filters.

Ignition System:

Ignition timing, spark plugs, coils, ignition module.

Transmission Drivetrain:

Clutch, primary drive, transmission gears, shifting mechanism, final drive belt.

Chassis Frame:

Frame inspection, alignment, steering head, swingarm, suspension components.

Suspension System:

Front fork (including cartridge types), rear shock absorbers, adjustments.

Braking System:

Hydraulic brake system, calipers, master cylinders, brake lines, bleeding procedures, disc brake maintenance.

Electrical System:

Wiring diagrams, battery, charging system (stator, regulator/rectifier), starter motor, lighting, instrumentation, ignition switch, horn.

Fuel Injection:

ECM, sensors (MAP, TPS, IAT, O2), fuel injectors, throttle body, diagnostic codes.

Bodywork Fittings:

Fairings, saddlebags, fenders, seat, controls, handlebars, mirrors.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, chain/belt adjustment, tire pressure, brake inspection, battery checks.

Troubleshooting:

Diagnostic procedures for common issues, fault code interpretation.

Repair Procedures:

Step-by-step instructions for component removal, installation, and overhaul.

Rebuild Procedures:

Engine, transmission, and suspension component rebuild instructions.

Diagnostic Charts:

Flowcharts and tables to identify and resolve problems.

Technical Depth

Depth Of Coverage:

Comprehensive; covers routine maintenance to full engine and transmission rebuilds.

Diagnostic Capabilities:

Detailed electrical diagnostics, including wiring diagrams and component testing.

Special Tools:

Identification of specialized tools required for specific procedures.

📊 Manual Specifications

File Format

File Type:

PDF (Portable Document Format)

Searchability:

Likely text-searchable if properly created from original digital source.

Print Quality

Printability:

All pages are printable.

Binding Type

Binding Type:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

Compatibility

Operating Systems:

Compatible with all versions of Windows & Mac.

Requirements

Software Requirements:

Adobe PDF Reader & WinZip (or equivalent unzipping software).

⚙️ Engine Specifications

Primary Engine

Engine Type:

Air-cooled, 45-degree V-twin, OHV 2-valve per cylinder

Engine Displacement:

1450cc (88 cubic inches)

Engine Codes:

Twin Cam 88

Performance

Horsepower Est:

~60-65 HP (at crankshaft, estimate based on model)

Torque Est:

~70-75 ft-lbs (at crankshaft, estimate based on model)

Fuel System

Fuel Delivery:

Electronic Sequential Port Fuel Injection (ESPFI)

Fuel Type:

Unleaded gasoline, 91 octane (Research Octane Number) or higher recommended.

Lubrication

Oil Type:

Harley-Davidson SYN3 Synthetic Motorcycle Oil (or equivalent V-twin specific synthetic) 20W-50.

Oil Capacity:

~3.5 US quarts (3.3 liters) with filter change.

🔧 Transmission

Standard

Transmission Type:

5-speed constant mesh

Primary Drive:

4-speed, enclosed, wet multi-plate clutch, hydraulic actuation.

Final Drive:

Carbon fiber belt drive, 1.25 inch wide.

Features

Gear Ratios:

Specific ratios will be detailed in the manual (e.g., 1st: 9.375, 2nd: 6.516, 3rd: 4.774, 4th: 3.750, 5th: 3.172).

Fluid Specifications

Transmission Oil Type:

Harley-Davidson Formula+ (or equivalent performance transmission fluid) or SAE 50 motorcycle oil.

Fluid Capacities

Transmission Oil Capacity:

~2.1 US quarts (2.0 liters).

📐 Dimensions

Exterior

Wheelbase:

~64.0 inches (1625.6 mm)

Length:

~90.7 inches (2303.8 mm)

Seat Height:

~27.7 inches (703.6 mm)

Weights

Dry Weight Est:

~645 lbs (293 kg)

Gross Vehicle Weight Rating Est:

~1000 lbs (454 kg)

Capacities

Fuel Tank Capacity:

4.9 US gallons (18.5 liters)

🛡️ Safety Features

Ratings

Crash Safety:

Motorcycles are not rated by traditional automotive safety organizations (NHTSA, IIHS).

Active Features

Braking:

Dual front disc brakes with four-piston calipers, single rear disc brake with four-piston caliper (FXDX models feature triple discs).

Suspension:

Performance-oriented suspension for improved handling and stability.

Passive Features

Lighting:

Halogen headlamp, tail lamp, brake lamp, turn signals.

Ergonomics:

Rider-centric controls and seating position.

💡 Technology Features

Infotainment

Audio System:

Optional factory-installed audio systems might be present on some models, but generally not a primary feature. Manual will cover its integration.

Driver Assistance

Anti-lock Braking System (ABS) was typically an optional feature for this model year, manual will cover its operation and servicing if equipped.

Connectivity

Diagnostics:

On-board diagnostics (OBD) for fuel injection system faults, accessible via diagnostic ports and potentially requiring specialized Harley-Davidson tools or procedures.

🔧 Maintenance

Service Intervals

First Service:

Typically 1,000 miles (1,600 km) or 1 month, whichever comes first.

Subsequent Service:

Every 5,000 miles (8,000 km) or 6 months for routine checks and fluid changes.

Major Service:

Details for spark plug replacement, belt inspection/replacement, and other component servicing at higher mileages will be in the manual.

Fluid Specifications

Primary Chain Case Fluid:

Harley-Davidson Formula+ or SAE 50 motorcycle oil.

Transmission Fluid:

Harley-Davidson Formula+ or SAE 50 motorcycle oil.

Brake Fluid:

DOT 4 Synthetic Brake Fluid.

Fork Oil:

Specific viscosity and type (e.g., Harley-Davidson Type E or 10W) will be detailed for front fork service.

Known Issues

Twin Cam 88 Considerations:

Potential for oil leaks, cam chain tensioner wear (later models addressed this with hydraulic tensioners), and vibration at idle.

Electrical Connectors:

Corrosion or loose connections in the wiring harness can sometimes lead to intermittent electrical issues.

Rear Belt Tension:

Improper belt tension can lead to premature wear of the belt and sprockets.

📚 Vehicle History

Brand Heritage

Harley Davidson Legacy:

Founded in 1903, Harley-Davidson is an iconic American motorcycle manufacturer with a rich history of V-twin engines and custom culture.

Model Evolution

Dyna Introduction:

The Dyna platform was introduced in 1991, evolving from earlier Harley-Davidson chassis designs.

Fxdx Introduction:

The FXDX Super Glide Sport was launched in 1999 as a sportier, more performance-oriented version of the Dyna.

Fxdx T Introduction:

The FXDX-T Super Glide T-Sport replaced the FXDS-Conv Dyna Convertible in 2001, offering touring amenities.

Production

Production Period:

2003 model year.

Manufacturing Location:

Milwaukee, Wisconsin, USA (primary assembly).

🏆 Awards & Recognition

Recognitions

Motorcycle Reviews:

The Dyna platform, particularly the FXDX variants, was generally well-received for its handling and performance relative to other Harley-Davidson models of the era.
