Vehicle Segment:
Compact SUV / Crossover
Target Audience:
Families, individuals seeking versatile transportation with moderate off-road capability and towing potential.
Key Competitors:
Ford Escape (platform sibling), Honda CR-V, Toyota RAV4, Nissan Xterra, Chevrolet Tracker.
Platform Sharing:
Developed in conjunction with Ford, sharing the CD2 platform with the first-generation Ford Escape.
Engine Options:
Offered with a choice of two Mazda-engineered engines: a 2.3L inline-four and a 3.0L V6.
Drivetrain Options:
Available in Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) configurations.
Primary Coverage:
Full Service Repair and Maintenance
Secondary Coverage:
Diagnostics, Electrical Service, Wiring Diagrams
Estimated Page Count:
Varies by specific manual edition, typically 1500-2500+ pages for a comprehensive factory-level manual.
Type:
Full Service & Repair Manual
Powertrain:
Engine mechanical (2.3L I4, 3.0L V6), fuel system, ignition system, exhaust system, engine management, cooling system.
Transmission:
Automatic transmission (4-speed), clutch system (if manual option existed), transfer case, driveline.
Chassis:
Suspension (front & rear), steering system, braking system (front disc, rear drum/disc), wheels, tires.
Electrical:
Battery, charging system, starting system, lighting system, instrument cluster, body electrical, power accessories, diagnostics, wiring diagrams.
Body:
Body panels, doors, windows, interior trim, HVAC system, exterior trim, collision repair information.
Maintenance:
Oil change, filter replacement, fluid checks and changes, tire rotation, battery maintenance, spark plug replacement, belt inspection/replacement.
Repair:
Engine overhaul, transmission rebuild, brake caliper replacement, suspension component replacement, electrical component diagnosis and repair, body panel repair.
Diagnostics:
OBD-II diagnostic procedures, trouble code interpretation, component testing, circuit analysis.
Troubleshooting:
System-specific troubleshooting guides, symptom-based diagnostics, common problems and solutions.
Depth:
Comprehensive, covering basic maintenance to complete engine and transmission rebuilds, including detailed electrical diagnostics and wiring diagrams.
Searchable:
Likely, typical of professionally produced PDF manuals.
Printability:
Full Printable
Binding:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Delivery Method:
Instant Download
Software Requirements:
Adobe PDF Reader, WinRAR (for potential archive extraction)
Operating System Compatibility:
All Versions of Windows & Mac
Engine 2 3L I4 Type:
Mazda MZR L3-VE
Engine 2 3L I4 Displacement:
2.3 Liters (2261 cc)
Engine 2 3L I4 Horsepower:
145 hp @ 5200 rpm
Engine 2 3L I4 Torque:
150 lb-ft @ 3500 rpm
Engine 2 3L I4 Configuration:
Inline-4 Cylinder
Engine 2 3L I4 Valvetrain:
DOHC, 16 Valves
Engine 3 0L V6 Type:
Mazda AJ-DE / AJ-VE (Ford Duratec 30 based)
Engine 3 0L V6 Displacement:
3.0 Liters (2967 cc)
Engine 3 0L V6 Horsepower:
190 hp @ 6200 rpm
Engine 3 0L V6 Torque:
200 lb-ft @ 4700 rpm
Engine 3 0L V6 Configuration:
V-6 Cylinder
Engine 3 0L V6 Valvetrain:
DOHC, 24 Valves
Fuel Induction:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Regular (87 Octane Recommended)
Standard Transmission:
4-speed Automatic Transmission
Optional Transmission:
5-speed Manual Transmission (Less common, primarily with 2.3L engine)
Drivetrain Options:
Front-Wheel Drive (FWD), All-Wheel Drive (AWD)
AWD System Description:
Electronically controlled all-wheel drive system.
Length:
Approx. 173.4 inches (4404 mm)
Width:
Approx. 70.3 inches (1786 mm)
Height:
Approx. 66.7 inches (1694 mm)
Wheelbase:
Approx. 103.1 inches (2619 mm)
Curb Weight 2 3L FWD:
Approx. 3350 lbs (1519 kg)
Curb Weight 3 0L AWD:
Approx. 3650 lbs (1656 kg)
Towing Capacity:
Up to 3500 lbs (1588 kg) when properly equipped (typically with 3.0L V6 and towing package)
Cargo Volume Behind Second Row:
Approx. 29.2 cubic feet (827 liters)
Cargo Volume With Second Row Folded:
Approx. 66.2 cubic feet (1875 liters)
NHTSA Rollover Resistance Rating:
4/5 Stars (for AWD models)
Braking System:
Front ventilated disc brakes, Rear drum brakes (standard) or disc brakes (optional on some trims).
ABS:
Anti-lock Braking System (ABS) standard on most models.
Airbags:
Front dual-stage airbags for driver and front passenger, optional front-seat side-impact airbags.
Seat Belts:
3-point seat belts with pretensioners and load limiters for all seating positions.
Rollover Protection:
Designed with a focus on rollover mitigation, particularly in AWD configurations.
Audio System:
AM/FM stereo with CD player, optional cassette player, and available premium audio systems (e.g., Bose).
Navigation:
Optional factory navigation system was available on higher trims.
Cruise Control:
Standard on most models.
Auxiliary Input:
Not typically standard; aftermarket solutions may be available.
Oil Change Interval:
Every 5,000 miles or 6 months, whichever comes first (or as per specific oil type and driving conditions).
Engine Coolant Change:
Refer to manual; typically around 60,000 - 100,000 miles or specific time interval.
Transmission Fluid Change:
Refer to manual; often around 30,000 - 60,000 miles for severe use.
Engine Oil 2 3L:
SAE 5W-20, API Certified (refer to manual for exact specification)
Engine Oil 3 0L:
SAE 5W-30, API Certified (refer to manual for exact specification)
Transmission Fluid:
MERCON V or equivalent (for automatic transmissions, consult manual for exact type)
Coolant:
For 2.3L: Mazda FL22 Long Life Coolant or equivalent; For 3.0L: Motorcraft Premium Engine Coolant (Orange) or equivalent.
Common Issues 2 3L Engine:
Variable: Catalytic converter issues, occasional oil consumption, intake manifold runner problems.
Common Issues 3 0L V6 Engine:
Variable: Ignition coil failures, occasional rear main seal leaks, intake manifold gasket leaks.
Common Issues AWD System:
Variable: Rear differential seal leaks, potential issues with the power transfer unit (PTU).
Mazda Heritage:
Mazda is a Japanese automaker known for its distinctive 'Zoom-Zoom' driving dynamics and innovative engineering.
Tribute Introduction:
The Mazda Tribute was introduced for the 2001 model year as Mazda's first compact SUV.
First Generation Timeline:
2001-2006
Manufacturing Location:
Ford's Claycomo, Missouri assembly plant (shared with Ford Escape).
