Manual Coverage
|
|
Systems Covered
|
|
Engine Mechanical:
|
Full engine overhaul, component replacement, timing, lubrication, cooling.
|
|
Fuel System:
|
Fuel injection, fuel pump, injectors, fuel pressure, evaporative emissions.
|
|
Ignition System:
|
Spark plugs, ignition coils, timing, diagnostics.
|
|
Exhaust System:
|
Catalytic converter, mufflers, pipes, lambda sensors.
|
|
Transmission Manual:
|
Clutch operation, gearbox overhaul, component replacement.
|
|
Transmission Automatic:
|
Service, fluid changes, common faults, solenoid operation (if applicable to 1.6L).
|
|
Drivetrain:
|
Axles, CV joints, drive shafts, differential service.
|
|
Suspension Front:
|
Struts, control arms, ball joints, bushings, alignment.
|
|
Suspension Rear:
|
Shock absorbers, trailing arms, bushings, alignment.
|
|
Steering System:
|
Power steering pump, rack and pinion, tie rod ends, steering column.
|
|
Braking System:
|
Brake pads, discs, calipers, master cylinder, ABS system, brake fluid.
|
|
Cooling System:
|
Radiator, water pump, thermostat, coolant, hoses, fan.
|
|
Electrical System Charging:
|
Alternator, battery, starter motor, wiring.
|
|
Electrical System Lighting:
|
Headlights, taillights, interior lights, bulb replacement.
|
|
Electrical System Instruments:
|
Dashboard gauges, warning lights, sensors.
|
|
Body Exterior:
|
Body panel removal/installation, doors, hood, trunk, bumpers.
|
|
Body Interior:
|
Trim panels, seats, carpets, headliner, dashboard removal.
|
|
HVAC System:
|
Air conditioning, heating, ventilation, blower motor, cabin filter.
|
|
Airbags Srs:
|
Airbag system operation, component replacement, safety precautions.
|
|
Procedures Included
|
|
Routine Maintenance:
|
Oil changes, filter replacements, fluid checks, tire rotation, spark plug replacement.
|
|
Troubleshooting Diagnostics:
|
Step-by-step diagnostic procedures for common and uncommon faults, symptom-based troubleshooting.
|
|
Component Replacement:
|
Detailed instructions for replacing major and minor components across all systems.
|
|
Rebuilding Overhaul:
|
Procedures for engine and transmission rebuilding/overhaul.
|
|
Wiring Diagrams:
|
Comprehensive electrical wiring diagrams for all vehicle systems.
|
|
Torque Specifications:
|
Exact torque values for all critical fasteners.
|
|
Special Tools:
|
Identification and use of specialized tools required for specific procedures.
|
|
Technical Depth
|
|
Depth:
|
Comprehensive, from basic maintenance to in-depth engine and transmission overhauls. Suitable for professional mechanics and advanced DIY enthusiasts.
|
|
Maintenance
|
|
Service Intervals
|
|
Oil Change Interval:
|
15,000 km or 12 months, whichever comes first (typically, consult manual for exact Holden recommendation).
|
|
Air Filter Replacement:
|
30,000 km or 24 months (typically, consult manual).
|
|
Spark Plug Replacement:
|
60,000 km (for standard spark plugs, iridium may be longer, consult manual).
|
|
Brake Fluid Replacement:
|
24 months or 40,000 km (typically, consult manual).
|
|
Fluid Specifications
|
|
Engine Oil:
|
API SN/SP, ACEA A3/B4, SAE 5W-30 or 10W-40 (refer to manual for precise specification and capacity).
|
|
Coolant:
|
Ethylene Glycol based, silicate-free, P-HOAT type, typically a pink or red coolant (refer to manual for specific Holden coolant part number).
|
|
Known Issues
|
|
Common Faults:
|
Potential for ABS sensor failure, minor electrical gremlins, wear on suspension bushings, occasional transmission shifting issues (automatic).
|
