The CX-7, produced from 2007 to 2009, represents a foray into the sporty crossover SUV segment, slotting between the Mazda3 and Mazda5. This First Generation (ER) model is characterized by its dynamic styling and a focus on driver engagement, embodying a 'Zoom-Zoom' philosophy. The CX-7 typically features a powerful 2.3L L3-VDT Turbocharged MZR I4 engine, delivering approximately 244 horsepower and 258 lb-ft of torque, paired with a 6-speed automatic transmission and available Intelligent All-Wheel Drive (i-ACTIV AWD). Its engineering prioritizes responsive handling, making it a compelling choice for those seeking performance in a practical package.
This comprehensive Factory Service Repair Manual provides detailed information for all styles of the CX-7 from 2007-2009. It covers a wide array of systems, including powertrain components such as the engine, transmission, fuel, cooling, and emission systems, as well as chassis and suspension elements like brakes, steering, and axles. The manual also delves into electrical and body systems, wiring diagrams, HVAC, and restraint systems. It offers step-by-step repair procedures, diagnostic guidance, general maintenance schedules, and troubleshooting tips, empowering owners, DIY enthusiasts, and independent repair shops to effectively maintain, diagnose, and repair their vehicles.
Generation:
First Generation (ER)
Target Audience:
Mazda CX-7 owners, DIY enthusiasts, independent repair shops
Manual Source:
Actual Genuine Repair Service Factory Manuals (Not 3rd party)
Content Scope:
Complete official full factory service repair manual
User Experience:
Easy to use, search functionality, print desired pages
Cost Savings:
Potential savings of $50-$60 per hour on shop labor costs by performing servicing independently.
Instructional Quality:
Detailed substeps, numbered instructions, notes, cautions, and warnings.
Illustrations:
Detailed illustrations, drawings, photos, enlarged insets for detailed part examination.
Navigation:
Numbered table of contents, search function for quick information retrieval.
Years Covered:
2007, 2008, 2009
Trims Covered:
All styles
Estimated Pages:
Hundreds
Type:
Factory Service Repair Manual
Powertrain:
Engine Service/Repair, Transmission Service/Repair, Fuel Injection/Fuel System, Cooling System, Emission System, Engine Control System
Chassis And Suspension:
Brake System, Suspension, Steering, Differential/Drive, Axle
Electrical And Body:
Wiring Diagram, Electrical System, Chassis/Body, Heater/Air Conditioning, Restraint System, Interior
Maintenance:
General Maintenance, Periodic Lubrication
Diagnostics And Repair:
Troubleshooting, Step-by-step repair procedures, Diagnostic procedures
Depth:
Comprehensive: Covers fundamentals to advanced diagnostics and repairs. Similar to information provided to factory-trained technicians.
Readability:
High Resolution
Printability:
Fully Printable (individual pages, chapters, or entire manual)
Binding:
Not Applicable (Digital Download)
Paper Quality:
Not Applicable (Digital Download)
Reader Software:
Adobe PDF Reader
Operating Systems:
All PC based Windows operating systems and Mac
Engine Type 2007-2008:
2.3L L3-VDT Turbocharged MZR I4
Engine Type 2009:
2.5L JY-VE I4 (Optional in some markets, but 2.3L Turbo remains primary)
Horsepower 2.3L Turbo:
Approximately 244 hp @ 5500 rpm
Torque 2.3L Turbo:
Approximately 258 lb-ft @ 3000 rpm
Fuel Delivery 2.3L Turbo:
Direct Injection (DI) with Electronic Port Fuel Injection (PFI) backup
Fuel Requirement:
Premium Unleaded Gasoline (91 octane or higher recommended for 2.3L Turbo)
Timing Drive 2.3L:
Timing Chain
ECU System:
Engine Control System details covered extensively
Transmission Type 2.3L Turbo:
6-speed automatic (Active Adaptive Sport Shift)
Transmission Type 2.5L:
5-speed manual (available on select models, primarily in certain markets)
AWD Availability:
Intelligent All-Wheel Drive (i-ACTIV AWD) available on most configurations
Atf Type:
Mazda Genuine ATF JWS3309 (or equivalent)
Length:
Approximately 179.7 inches
Width:
Approximately 71.7 inches
Height:
Approximately 64.6 inches
Wheelbase:
Approximately 106.3 inches
Curb Weight:
Varies by drivetrain, approximately 3700-3900 lbs for AWD Turbo models
Cargo Volume:
Approximately 19.7 cu ft (behind rear seats), 45.7 cu ft (with rear seats folded)
NHTSA Front Impact:
5-Star (for driver and front passenger)
ABS:
Anti-lock Braking System (ABS)
Traction Control:
Traction Control System (TCS)
Stability Control:
Dynamic Stability Control (DSC)
Airbags:
Front, Side, and Side Curtain Airbags
Seatbelts:
Pretensioner seatbelts with force limiters
Audio System:
Bose premium audio system available on higher trims, CD player, AM/FM stereo.
Navigation:
Optional GPS Navigation system
Key Features:
Cruise control, Tire Pressure Monitoring System (TPMS).
Auxiliary Input:
Auxiliary audio input jack common on audio systems.
Headlights:
Halogen projector headlights, Xenon HID headlights available on higher trims.
Oil Change Interval:
Refer to manual for specific mileage/time intervals based on driving conditions (typically 5,000-7,500 miles).
Air Filter Replacement:
Refer to manual for specific intervals (e.g., every 15,000-30,000 miles).
Spark Plug Replacement 2.3L:
Refer to manual for specific intervals (e.g., every 30,000-50,000 miles for iridium plugs).
Engine Oil Type:
SAE 5W-30 (API SN or ILSAC GF-5 compatible)
Coolant Type:
Mazda Genuine Super Long Life Coolant (FL22) or equivalent HOAT coolant.
Brake Fluid Type:
DOT 3 or DOT 4
Turbocharger Issues:
Potential for turbocharger lag, oil consumption, or premature failure if not maintained properly (especially oil changes).
Fuel Injector Clogging:
Direct injection systems can be susceptible to carbon buildup on intake valves and injectors.
Timing Chain Stretch:
While generally robust, timing chain wear can occur over high mileage.
Suspension Wear:
Normal wear items like ball joints, control arm bushings, and tie rod ends may require replacement.
Brand Focus:
Mazda's commitment to sporty handling and driver engagement ('Zoom-Zoom' philosophy).
Introduction Year:
2006 (as a 2007 model year)
Positioning:
Sporty crossover SUV slotting between the Mazda3 and Mazda5/Tribute.
Manufacturing Plant:
Hofu Plant, Yamaguchi Prefecture, Japan
Initial Reception:
Generally positive reviews for performance and handling, criticized for fuel economy.
