Market Segment:
Luxury Mid-size Sedan
Key Competitors:
BMW 5 Series, Mercedes-Benz E-Class, Audi A6, Lexus GS
Vehicle Platform:
Ford DEW98 platform (shared with Jaguar S-Type and Lincoln LS, but heavily revised)
Design Philosophy:
Elegant styling, refined interior, strong emphasis on comfort and performance.
Coverage Scope:
Full Service, Repair, and Workshop Procedures
Included Engines:
2.7L TDV6, 3.0L V6, 4.2L V8, 4.2L SC V8
Included Systems:
Engine Mechanical, Engine Management, Fuel System, Exhaust System, Cooling System, Lubrication System, Transmission (Automatic), Drivetrain, Suspension, Steering, Brakes (Front & Rear), ABS, Traction Control, Electrical System (Wiring Diagrams Included), Body & Chassis, Interior Trim, HVAC, Body Control Modules (BCM), Powertrain Control Modules (PCM), Infotainment, Safety Systems, Diagnostic Procedures, Troubleshooting
Estimated Page Count:
Hundreds of pages
Manual Type:
Factory Service Repair Workshop Manual
Engine Mechanical:
Detailed disassembly, inspection, assembly, and torque specifications for all engine variants.
Engine Management:
Fuel injection systems, ignition systems, emissions control, ECU functions, sensor data, and diagnostic trouble codes (DTCs).
Drivetrain:
Automatic transmission overhaul, fluid change intervals, torque converter operation, differential maintenance, and driveshaft procedures.
Brakes:
Brake system diagnostics, pad and rotor replacement, caliper overhaul, fluid flush procedures, ABS component testing, and parking brake adjustment.
Electrical:
Comprehensive color wiring diagrams, component locations, troubleshooting guides for electrical faults, battery service, and starter/alternator testing.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, spark plug replacement, belt replacement, fluid checks and top-offs.
Repair:
Component replacement, system overhauls, body panel repair, interior trim removal and installation, suspension component renewal.
Troubleshooting:
Systematic diagnostic approaches for common and uncommon issues, fault code interpretation, and symptom-based troubleshooting guides.
Depth Level:
Professional Mechanic Level
Diagrams:
Hundreds of detailed photos and exploded view diagrams for precise assembly and disassembly.
Diagnostic Tools:
Guidance on using diagnostic scan tools for accessing live data, performing actuator tests, and module programming.
2.7L Tdv6:
Type: V6 Diesel, Displacement: 2720 cc, Bore x Stroke: 81.0 mm x 88.0 mm, Compression Ratio: 17.3:1, Power: ~207 PS (204 hp; 152 kW), Torque: ~435 Nm (321 lb-ft)
3.0L V6:
Type: V6 Gasoline (Naturally Aspirated), Displacement: 2967 cc, Bore x Stroke: 89.0 mm x 79.5 mm, Compression Ratio: 11.5:1, Power: ~240 PS (237 hp; 177 kW), Torque: ~293 Nm (216 lb-ft)
4.2L V8:
Type: V8 Gasoline (Naturally Aspirated), Displacement: 4196 cc, Bore x Stroke: 86.0 mm x 90.3 mm, Compression Ratio: 11.0:1, Power: ~300 PS (296 hp; 221 kW), Torque: ~420 Nm (310 lb-ft)
4.2L Sc V8:
Type: V8 Gasoline (Supercharged), Displacement: 4196 cc, Bore x Stroke: 86.0 mm x 90.3 mm, Compression Ratio: 9.1:1, Power: ~400 PS (395 hp; 294 kW), Torque: ~541 Nm (399 lb-ft)
Fuel Induction:
Direct Injection (TDV6), Port Injection (V6/V8), Supercharger (SC V8)
Emission Controls:
Catalytic converters, EGR (TDV6), variable valve timing (on some petrol engines).
Transmission Type:
6-speed ZF 'SelectShift' Automatic
Transmission Options:
N/A (All models in this range used the 6-speed automatic)
Transmission Features:
Adaptive shift logic, Sport mode, Manual override (SelectShift)
Transmission Fluid Type:
Mercon SP (or equivalent specified by ZF)
Length:
Approx. 4961 mm (195.3 in)
Width:
Approx. 1877 mm (73.9 in) (excluding mirrors)
Height:
Approx. 1461 mm (57.5 in)
Curb Weight:
Varies by engine, approx. 1700-1900 kg (3750-4190 lbs)
Gross Vehicle Weight Rating:
Varies by engine and configuration.
Euro Ncap Rating:
Likely 5 Stars (based on similar vehicles of the era, specific test data for all variants may vary)
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Emergency Brake Assist (EBA), Dynamic Stability Control (DSC), Traction Control System (TCS)
Passive Safety Features:
Front airbags, Side airbags, Curtain airbags, Active front head restraints, Seatbelt pretensioners
Infotainment System:
Jaguar premium sound systems, optional touchscreen navigation, Bluetooth connectivity, CD changer.
Driver Assistance Features:
Adaptive Cruise Control (optional), front and rear parking sensors, rearview camera (optional on later models within this range).
Connectivity Options:
Auxiliary audio input, USB connectivity (on later models), Bluetooth for hands-free calling and audio streaming.
Oil Change Interval Petrol:
Typically 10,000 miles (16,000 km) or 12 months, whichever comes first.
Oil Change Interval Diesel:
Typically 15,000 miles (24,000 km) or 12 months, whichever comes first, depending on driving conditions.
Transmission Fluid Change Interval:
Often recommended at 60,000 miles (96,000 km) or every 4-5 years, though sealed for life in some interpretations, checking manual is crucial.
Engine Oil Specification:
Refer to specific engine requirements: e.g., 5W-30 or 5W-20 meeting Ford WSS-M2C913-C (TDV6), or API SN/ACEA A5/B5 for petrol variants.
Coolant Type:
Jaguar specified OAT (Organic Acid Technology) coolant, typically pink or orange.
Brake Fluid Type:
DOT 4 (or DOT 4 LV for systems requiring lower viscosity)
Tdv6 Issues:
Potential for swirl flap issues, carbon build-up, turbocharger problems, and EGR cooler leaks.
Petrol V6 V8 Issues:
Timing chain guides (especially on earlier V8s), water pump failures, and occasional coolant leaks from the thermostat housing.
General Issues:
Air suspension compressor failures (if equipped), electronic control module (ECM) issues, and interior trim creaks.
Brand Positioning:
Jaguar has a long-standing reputation for luxury, performance, and elegant design in the automotive industry.
Predecessor:
Jaguar S-Type
Design Influence:
Designed by Ian Callum, the XF represented a significant departure from the S-Type, adopting a more modern and aggressive aesthetic.
Production Period:
2007-2015 (first generation X250)
Manufacturing Location:
Castle Bromwich Assembly Plant, Birmingham, England
