Motorcycle Segment:
The Ducati Hypermotard 796 is positioned as a lightweight, agile supermoto-style motorcycle known for its blend of urban usability and track-day excitement. It appeals to riders seeking a fun, engaging riding experience with a distinct Ducati character.
Competitors:
Competitors in this segment during its production years often included models like the KTM 690 SMC R, Aprilia Dorsoduro 750, and other performance-oriented naked bikes or motards.
Distinctive Attributes:
Compact and potent L-twin engine, lightweight chassis, upright riding position, sharp handling, distinctive Ducati styling, and the characteristic 'Ducati sound'.
Benefit To Owner:
Empowers owners to perform routine maintenance and complex repairs themselves, saving significant costs on dealership labor. Provides the knowledge to understand and maintain their Hypermotard 796 effectively, ensuring longevity and optimal performance.
General Coverage:
Comprehensive service and repair procedures for the Ducati Hypermotard 796 (2010-2012).
Specific Coverage:
Engine, transmission, chassis, electrical system, suspension, brakes, bodywork, diagnostics, and maintenance.
Estimated Page Count:
Detailed page count not provided, but described as 'Complete Workshop Service Repair Manual' indicating extensive content.
Type:
Workshop Service Repair Manual
Language:
English (implied by product description and typical for this market).
Format:
Downloadable Digital Format (PDF compatible)
Powertrain:
Engine assembly, disassembly, tuning, fuel system (injection, fuel pump, injectors), ignition system, lubrication system, cooling system (air-cooled), exhaust system.
Drivetrain:
Clutch operation and maintenance, gearbox components, final drive (chain and sprockets), oil change procedures.
Chassis And Suspension:
Frame inspection and repair, front suspension (forks, steering head), rear suspension (shock absorber, linkage), wheel bearing maintenance, swingarm servicing.
Brakes:
Front and rear brake system, hydraulic components (master cylinders, calipers, brake lines), brake fluid replacement and bleeding, rotor and pad maintenance, ABS system (if equipped).
Electrical:
Wiring diagrams, battery maintenance, charging system (alternator, regulator/rectifier), starter motor, lighting system, ignition switch, dashboard instrumentation, fault finding and diagnostics for electrical components.
Bodywork And Accessories:
Fairings, seat removal and installation, fuel tank servicing, fenders, exhaust system components, handlebar and control adjustments.
Routine Maintenance:
Oil and filter changes, air filter replacement, spark plug service, chain adjustment and lubrication, brake fluid checks, tire pressure and condition checks.
Troubleshooting:
Step-by-step diagnostic guides for common problems, fault code identification, electrical system troubleshooting flowcharts.
Repair And Rebuild:
Detailed instructions for component removal, disassembly, inspection, repair, and reassembly of all major motorcycle systems.
Calibration And Adjustment:
Throttle cable adjustment, clutch lever adjustment, suspension pre-load and damping adjustments, ignition timing checks (if applicable).
Depth:
Comprehensive, covering everything from basic maintenance to full engine and transmission rebuilds. Includes detailed torque specifications and clearance measurements.
Format:
PDF (Portable Document Format), ensuring compatibility with a wide range of devices.
Software Requirement:
Adobe Acrobat Reader (free, widely available).
Quality:
High-quality, designed for clear reproduction of text and images, allowing users to print specific sections or the entire manual.
Binding:
N/A (Downloadable digital format, user prints and binds as desired).
Paper Type:
N/A (Downloadable digital format, user chooses paper type for printing).
Engine Type:
L-Twin, four-stroke, Desmodromic 2 valves per cylinder
Displacement:
803 cc (actual displacement is closer to 796 cc)
Bore X Stroke:
94 mm x 61.8 mm
Cooling System:
Air-cooled
Peak Horsepower:
Approximately 81 hp (60 kW) @ 9,000 rpm
Peak Torque:
Approximately 57.5 lb-ft (78 Nm) @ 6,250 rpm
Fuel Delivery:
Marelli 7SM electronic fuel injection, throttle body diameter 45 mm
Fuel Type:
Unleaded gasoline, minimum 95 RON
Ignition System:
Digital electronic ignition with spark advance, Magneti Marelli
Braking System:
Dual 305 mm discs with 4-piston radial calipers (front), 245 mm disc with 2-piston caliper (rear). Optional ABS available on some models.
Frame Construction:
Lightweight Trellis frame, contributing to agility and rider feedback.
Suspension Design:
Front: Marzocchi 43mm USD forks; Rear: Progressive, Sachs monoshock with adjustable preload and rebound damping. Designed for precise control and feedback.
Dashboard:
Digital LCD display providing speed, RPM, odometer, trip meters, coolant temperature (if applicable), clock, and warning lights.
ABS:
Optional Anti-lock Braking System (ABS) available on some variants of the 796 model.
Connectivity Features:
No advanced connectivity features like Bluetooth or smartphone integration; focus is on core motorcycle performance and rider engagement.
Oil And Filter Change:
Typically every 7,500 miles (12,000 km) or 12 months, whichever comes first.
Desmo Service:
Desmodromic valve clearance checks and adjustment are critical and typically required every 7,500 miles (12,000 km).
Air Filter Replacement:
Recommended every 7,500 miles (12,000 km) or sooner if riding in dusty conditions.
Spark Plug Replacement:
Typically every 7,500 miles (12,000 km), though iridium plugs may last longer.
Engine Oil:
SAE 15W-50, API SG/SH/SJ, JASO MA, synthetic or semi-synthetic recommended. Capacity: Approximately 3.4 liters (3.6 US qt) with filter change.
Brake Fluid:
DOT 4 synthetic hydraulic fluid for clutch and brake systems.
Coolant:
N/A (Air-cooled engine)
Gearbox Oil:
SAE 75W-90, API GL-4 or GL-5 gear oil. Capacity: Approximately 0.8 liters (0.85 US qt).
Common Wear Items:
Clutch plates (especially if ridden aggressively), brake pads and rotors, chain and sprockets, fork seals.
Electrical Concerns:
Occasional issues with regulator/rectifier or stator due to heat management, though generally reliable.
Engine Performance:
Desmodromic valve adjustment is crucial for maintaining optimal performance and engine health. Incorrect adjustment can lead to poor running or valve damage.
Ducati Legacy:
Ducati, an Italian manufacturer, has a rich heritage in motorcycle racing and performance-oriented road bikes, known for its L-twin engines and Desmodromic valve technology.
Hypermotard Lineage:
The Hypermotard concept, originally introduced in 2007, blended supermoto styling with Ducati's sportbike DNA. The 796 model introduced a more accessible and user-friendly iteration of the platform, with a slightly detuned but characterful engine compared to earlier models like the 1100.
Manufacturing Location:
Ducati motorcycles are traditionally manufactured in Bologna, Italy.
Industry Reviews:
The Hypermotard 796 was generally well-received by motorcycle journalists for its playful handling, torquey engine, and unique styling, often praised for its accessibility within the Hypermotard family.
Performance Rating:
Consistently rated high for agility, braking performance, and engine character in its class.
