🏷️ Basic Information

Make:

Kawasaki

Model:

Teryx 750 FI 4x4 LE Sport

Model Codes Covered:

KRF750NA, KRF750PA, KRF750RA, KRF750SA, KRF750TA (2010); KRF750NB, KRF750PB, KRF750RB, KRF750SB, KRF750VB (2011); KRF750NC, KRF750PC, KRF750RC, KRF750SC, KRF750VC (2012)

Product Name:

2010-2012 Kawasaki Teryx 750 FI 4x4 LE Sport KRF750RAF ATV Workshop Service Repair Manual Download PDF

Product Identifier:

KRF750RAF

👋 Introduction

Target Audience:

Owners and maintenance personnel seeking detailed guidance for servicing and repairing their 2010-2012 Kawasaki Teryx 750 FI 4x4 LE Sport ATV. Ideal for the 'Do-It-Yourselfer'.

Value Proposition:

Offers practical, factory-level repair information, enabling users to perform maintenance and repairs effectively, saving on labor costs and improving vehicle longevity. Described as 'most practical' and a 'must' for owners.

Delivery Method:

Instant Download, saving on postage and packaging.

Content Quality:

Contains high-quality diagrams and detailed instructions.

📋 Manual Details

Vehicle Years Covered:

2010, 2011, 2012

Vehicle Models Covered:

Kawasaki Teryx 750 FI 4x4 LE Sport (KRF750)

Estimated Page Count:

Comprehensive (Specific count not provided, but typical for workshop manuals of this era covers several hundred pages)

Type:

Workshop Service Repair Manual

Language:

English

Format:

PDF Download

📖 Manual Coverage

Engine Systems:

General Information, Fuel System (DFI - Digital Fuel Injection), Cooling System, Engine Top End, Engine Lubrication System, Crankshaft/Transmission

Drivetrain Systems:

Converter System, Crankshaft/Transmission

Chassis Systems:

Wheels/Tires, Brakes, Suspension, Steering, Frame

Electrical Systems:

Electrical System

Additional Systems:

Periodic Maintenance, Appendix

Maintenance Procedures:

Periodic maintenance schedules, fluid level checks, lubrication, filter replacements, tune-ups

Repair Procedures:

Engine disassembly and reassembly (top end, crankshaft, transmission), fuel system servicing (DFI), cooling system repair, brake system repair, suspension component replacement, steering system repair, electrical component diagnosis and repair, converter system servicing

Diagnostic Procedures:

Troubleshooting guides for common issues, DFI system diagnostics, electrical system troubleshooting

Installation Procedures:

Engine removal and installation, component installation

Depth:

Comprehensive workshop-level detail, suitable for DIY enthusiasts and professional technicians. Includes high-quality diagrams and step-by-step instructions for intricate repairs.

📊 Manual Specifications

File Type:

PDF

Compatibility:

All Versions of Windows & Mac

Software Requirements:

Adobe PDF Reader

Printability:

All pages are printable

Binding:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Type:

Liquid-cooled, V-twin, 4-stroke, SOHC, 4-valve cylinder head

Displacement:

749 cc (45.7 cu. in.)

Bore X Stroke:

85.0 x 66.0 mm (3.35 x 2.60 in.)

Fuel System:

Digital Fuel Injection (DFI) with two Keihin 36mm throttle bodies

Horsepower:

Approximately 50-55 HP (Figures vary slightly by year and source, detailed specs are in the manual)

Torque:

Approximately 45-50 lb-ft (Figures vary slightly by year and source, detailed specs are in the manual)

Compression Ratio:

9.3:1 (Typical for this engine)

🔧 Transmission

Transmission Type:

CVT (Continuously Variable Transmission) with high and low range, plus reverse

Drive System:

Selectable 4-wheel drive with limited-slip front differential, 2-wheel drive

Final Drive:

Shaft drive

📐 Dimensions

Overall Length:

Approx. 106.7 inches (2710 mm)

Overall Width:

Approx. 58.1 inches (1475 mm)

Overall Height:

Approx. 75.6 inches (1920 mm)

Wheelbase:

Approx. 80.5 inches (2045 mm)

Dry Weight:

Approx. 644 lbs (292 kg) (Varies slightly by configuration)

Curb Weight:

Approx. 670.3 lbs (304 kg) (for 2010 LE model)

Ground Clearance:

Approx. 11.6 inches (295 mm)

🛡️ Safety Features

Braking System:

Dual front hydraulic discs, sealed rear drum brake (later models may have rear discs, manual will specify)

Parking Brake:

Mechanical drum brake

Rollover Protection:

Integrated Roll-Over Protective Structure (ROPS)

Seat Belts:

3-point seat belts

💡 Technology Features

Display Features:

Digital instrument cluster featuring speedometer, odometer, trip meter, fuel gauge, clock, 2WD/4WD indicator, and engine warning lights.

Selectable 4Wd:

Electronically selectable 2WD/4WD system with limited-slip front differential for enhanced traction.

Charging System:

12V accessory outlet (typically)

🔧 Maintenance

Oil Change Interval:

Recommended every 1,000 miles or 12 months, whichever comes first (refer to manual for specific conditions)

Spark Plug Replacement:

Refer to manual for mileage or time interval, typically around 4,000-6,000 miles

Air Filter Cleaning Replacement:

Regular inspection recommended, cleaning/replacement based on operating conditions and mileage

Engine Oil Type:

SAE 10W-40 API SG or higher (Specific recommendations in manual)

Engine Oil Capacity:

Approximately 2.0 US qt (1.9 L) with filter change (refer to manual)

Coolant Type:

Kawasaki specified coolant or equivalent (ethylene glycol-based, 50/50 mix with distilled water)

Transmission Oil Type:

CVT belt lubricant / Specific Kawasaki lubricant or equivalent (refer to manual for exact type and quantity)

Brake Fluid Type:

DOT 3 or DOT 4 (refer to manual)

Common Wear Items:

CVT belt wear, suspension bushings, brake pads, wheel bearings (typical for utility ATVs)

Potential Problems:

DFI sensor issues, exhaust system leaks, front differential wear under heavy load (detailed troubleshooting in manual)

📚 Vehicle History

Manufacturer Focus:

Kawasaki Heavy Industries is a well-established Japanese multinational corporation with a strong reputation for engineering excellence across various sectors, including motorcycles, ATVs, powersports vehicles, and industrial equipment.

Teryx Lineage:

The Teryx line, introduced in 2008, was Kawasaki's entry into the side-by-side utility vehicle market. The 750 FI 4x4 models represent the core of this lineup, known for their robust V-twin engines and capable off-road performance.

Manufacturing Location:

Primarily manufactured in Japan.

🏆 Awards & Recognition

Industry Standing:

While specific awards for this exact model year are not widely publicized, the Kawasaki Teryx line has consistently been recognized for its robust V-twin engine, strong towing capacity, and reliable performance in the utility ATV segment.
