Vehicle Segment:
Full-size Luxury SUV
Key Competitors 2011-2013:
Ford Explorer, Toyota Highlander, Chevrolet Traverse, Honda Pilot, Land Rover LR4, BMW X5, Mercedes-Benz ML-Class
Wk2 Platform Highlights:
New unibody platform (WK2) replaced the older WK body-on-frame; significant advancements in ride quality, handling, interior luxury, and technology.
Manual Utility:
Provides in-depth technical knowledge enabling DIY repairs, proactive maintenance, and efficient troubleshooting, saving on labor costs.
Manual Coverage Scope:
All repairs, servicing, and troubleshooting procedures
Estimated Page Count:
Hundreds of pages (specific count not provided, but described as comprehensive)
Manual Type:
Factory Service & Repair Workshop Manual
Language:
English (implied by standard workshop manual content)
Digital Format:
PDF Download
Powertrain Systems:
Engine mechanical, engine electrical, fuel system, exhaust system, cooling system, lubrication system
Drivetrain Systems:
Transmission (automatic), transfer case, differentials (front and rear), drive shafts, axles
Chassis Systems:
Suspension (front and rear), steering system, brake system (hydraulic and parking), wheels and tires
Electrical Systems:
Body control modules, power distribution, lighting, instrument cluster, infotainment system, comfort controls, charging system, starting system
Body And Interior Systems:
Body panels, doors, windows, seats, HVAC system, airbags, safety restraints
Maintenance Procedures:
Scheduled maintenance, oil changes, filter replacements, fluid level checks and top-offs, inspections
Repair Procedures:
Component removal and installation, system diagnostics, component replacement, major overhauls
Troubleshooting Procedures:
Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides, electrical schematics interpretation
Technical Specifications Data:
Torque specifications, clearances, fluid capacities, electrical values, dimensions
Depth Of Information:
Detailed step-by-step instructions with detailed photos and diagrams, suitable for professional mechanics
Searchability:
Searchable text (typical for professional PDF manuals)
Print Capability:
Printable (single page or entire manual)
Binding:
Not applicable (digital download)
Paper Quality:
Not applicable (digital download)
Usage Rights:
Lifetime use on unlimited computers, no expiry, no renewal fees
Operating Systems:
Windows and macOS
Engine Options Wk2 2011-2013:
3.6L Pentastar V6, 5.7L HEMI V8
3.6L Pentastar V6 Hp:
290 hp @ 6400 rpm
3.6L Pentastar V6 Torque:
260 lb-ft @ 4800 rpm
5.7L Hemi V8 Hp:
360 hp @ 5150 rpm
5.7L Hemi V8 Torque:
390 lb-ft @ 4250 rpm
Fuel Delivery System:
Multi-point fuel injection (MPI)
Engine Code Examples:
Pentastar V6: ERB, LFX; HEMI V8: TMD
Standard Transmission:
8-speed automatic (845RE/ZF 8HP45) for 3.6L V6 and 5.7L V8 models
Optional Transmission:
Not applicable for this generation (8-speed was standard across most powertrains).
Transmission Features:
Electronic Shifter, Tow/Haul Mode, Selec-Terrain compatibility
Transmission Fluid Type:
ATF+4 (MS-9602) or equivalent (check specific manual for exact Mopar spec)
Wheelbase:
114.8 inches (2916 mm)
Length:
189.8 inches (4821 mm)
Width:
76.5 inches (1943 mm)
Height:
69.3 - 70.5 inches (1760 - 1791 mm) depending on configuration
Cargo Volume Behind 3Rd Row:
N/A (Standard 2-row seating configuration for WK2 initially)
Cargo Volume Behind 2Nd Row:
35.1 cubic feet (994 L)
Max Cargo Volume:
68.3 cubic feet (1934 L)
Curb Weight:
Approx. 4,700 - 5,000 lbs (2130 - 2268 kg) depending on engine and drivetrain
Max Towing Capacity:
Up to 7,400 lbs (3356 kg) with appropriate packages
NHTSA Overall Safety Rating:
5-Star (for most 2011-2013 models)
Active Safety Features:
Electronic Stability Control (ESC), Traction Control, Anti-lock Braking System (ABS), Hill Start Assist, Hill Descent Control, Trailer Sway Control
Passive Safety Features:
Multiple airbags (front, side, curtain), Seatbelt pretensioners, Crumple zones
Infotainment System Options:
Uconnect infotainment system with touchscreens (e.g., 6.5-inch or 8.4-inch), navigation, SiriusXM satellite radio, Bluetooth connectivity.
Driver Assistance Features:
Available: Blind Spot Monitoring, Rear Cross-Path Detection, Adaptive Cruise Control, Forward Collision Warning, ParkView Rear Back-Up Camera.
Connectivity Features:
USB ports, Auxiliary audio input, Bluetooth streaming and hands-free calling.
Oil Change Interval:
Every 6,000-8,000 miles (9,600-12,800 km) or 6-12 months, depending on driving conditions (refer to manual for exact schedule)
Engine Air Filter Replacement:
Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection
Cabin Air Filter Replacement:
Every 12,000 - 20,000 miles (19,000 - 32,000 km) or annually
Spark Plug Replacement:
3.6L V6: ~100,000 miles (160,000 km); 5.7L V8: ~100,000 miles (160,000 km) (Platinum-tipped spark plugs)
Engine Oil Specification 3.6L:
SAE 0W-20 synthetic oil, API SN certified (Chrysler MS-6395)
Engine Oil Specification 5.7L:
SAE 5W-20 synthetic oil, API SN certified (Chrysler MS-10850)
Coolant Type:
OAT (Organic Additive Technology) HOAT coolant, Mopar P/N 68048553AA (or equivalent pink coolant)
Common Wk2 Issues 2011-2013:
Potential for water pump leaks (Pentastar V6), HVAC blower motor resistor failure, electronic parking brake issues, transmission solenoid issues, and occasional electronic module glitches. Some models may experience minor interior rattles.
Jeep Legacy:
Jeep has a long-standing reputation for off-road capability and ruggedness, tracing its roots back to World War II.
Wk2 Generation Launch:
The WK2 Grand Cherokee debuted for the 2011 model year, marking a significant departure with its unibody construction and focus on premium refinement alongside off-road prowess.
Manufacturing Plant:
Jefferson North Assembly Plant, Detroit, Michigan, USA
Awards And Accolades 2011:
Motor Trend SUV of the Year (2011), Consumers Digest Best Buy Award
Awards And Accolades 2012:
Kelley Blue Book Best Redesign
