2011 Honda Ridgeline Service & Repair Manual

Prix habituel: $17.99
Prix soldé: $17.99
Prix habituel
Prix unitaire: par

🏷️ Basic Information Identification Make: Honda Model: Ridgeline Year: 2011 Vehicle Type: Mid-size Crossover SUV (unibody truck) Generation Generation Designation: First Generation (YS) Generation Years: 2006-2014 Codes Chassis Code: YS...

19 people are viewing this right now

Taper: Truck

Distributeur:

UGS: 203302

Mots clés: 2011 Cars Featured Honda Ridgeline Truck

Variantes de produits

Description

🏷️ Basic Information

Identification

Make:

Honda

Model:

Ridgeline

Year:

Vehicle Type:

Mid-size Crossover SUV (unibody truck)

Generation

Generation Designation:

First Generation (YS)

Generation Years:

2006-2014

Codes

Chassis Code:

👋 Introduction

Market Position

Positioning:

Unique offering in the mid-size truck/SUV segment, blending SUV comfort with truck utility.

Target Audience:

DIY enthusiasts, independent repair shops, Honda owners seeking to maintain their vehicle.

Competitive Analysis

Competitors:

Ford Explorer Sport Trac, Toyota Tacoma (though mechanically different).

Key Features

Unibody Construction:

Contributes to a more car-like ride and handling compared to traditional body-on-frame trucks.

Integrated Dent:

The patented 'Integrated Dent' in the bed floor for secure cargo placement.

Vtm-4:

Standard on all 2011 Ridgelines, offering capable all-wheel-drive performance.

Waterproof Storage:

Lockable, waterproof storage compartment under the bed floor.

📋 Manual Details

Coverage Areas

Coverage Scope:

Comprehensive service and repair

Page Count

Estimated Page Count:

Extensive (specific page count not provided, but described as comprehensive and derived from OE materials)

Manual Type

Type:

Online Service and Repair Manual Software

Language

Language:

English

Format

Format:

Web-based, accessible via browser

Access Duration:

1 Year (with discount for renewal)

📖 Manual Coverage

Systems Covered

Engine:

Complete diagnosis, repair, and overhaul procedures for the 3.5L V6 engine.

Drivetrain:

Front-Wheel Drive (FWD) and VTM-4 (Variable Torque Management 4-Wheel Drive) system service, including differential and transfer case.

Suspension:

Front independent multi-link, rear independent multi-link suspension, steering system, wheel alignment.

Brakes:

Front and rear disc brake system service, ABS, VSA (Vehicle Stability Assist) system components.

Electrical:

Complete wiring diagrams, diagnostic procedures for all electrical components, lighting, power accessories.

HVAC:

Heating, Ventilation, and Air Conditioning system diagnosis and repair, including refrigerant handling.

Body:

Body panel repair, interior trim removal and installation, door mechanisms, glass replacement.

Chassis:

Frame inspection, reinforcement, and related components.

Procedures Included

Maintenance:

Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement.

Troubleshooting:

Diagnostic flowcharts, symptom-based troubleshooting for various systems.

Repair:

Step-by-step repair instructions for all major and minor components, including engine, transmission, brakes, suspension, and electrical.

Diagnostics:

OBD-II diagnostic trouble codes (DTCs), sensor testing, actuator testing, use of diagnostic tools.

Component Replacement:

Detailed instructions for replacing components like alternator, starter motor, fuel pump, radiators, and more.

Technical Depth

Depth:

Factory-level technical information, suitable for professional technicians and experienced DIYers.

Diagnostics Level:

Advanced diagnostic procedures, including component testing and circuit analysis.

Rebuild Procedures:

Procedures for engine and transmission disassembly, inspection, and reassembly.

📊 Manual Specifications

File Format

Format Type:

Web Application

Accessibility:

Cross-platform compatible (PC, laptop, smartphone, tablet)

Connectivity Requirement:

Internet Connection required

Print Quality

Printability:

Designed for online viewing; printing capabilities depend on browser and platform.

Binding Type

Binding:

N/A (Digital Format)

Paper Type

Paper:

N/A (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Code:

J35Z2

Engine Configuration:

3.5L SOHC V6 (24-valve) i-VTEC

Displacement:

3471 cc (211.8 cubic inches)

Performance

Horsepower:

250 hp @ 5700 rpm (SAE net)

Torque:

247 lb-ft @ 4300 rpm (SAE net)

Fuel System

Induction:

Programmed Fuel Injection (PGM-FI)

Fuel Type:

Unleaded Regular 87 Octane

Other

Bore X Stroke:

93.0 mm x 83.0 mm (3.66 in x 3.27 in)

Compression Ratio:

10.0:1

Engine Mounting:

Transverse

🔧 Transmission

Standard

Type:

5-speed automatic transmission with Grade Logic Control

Optional

Optional Transmission:

N/A for 2011 model year

Features

Drive System:

Standard VTM-4 (Variable Torque Management 4-Wheel Drive)

Transfer Case Fluid:

Honda VTM-4 Fluid (Part No. 08294-99903 or equivalent)

📐 Dimensions

Exterior

Length:

197.9 in (5027 mm)

Width:

78.5 in (1994 mm)

Height:

70.4 in (1788 mm)

Wheelbase:

118.1 in (3000 mm)

Ground Clearance:

8.0 in (203 mm)

Cargo

Bed Length:

60.0 in (1524 mm)

Bed Width At Wheelwells:

43.2 in (1097 mm)

Weights

Curb Weight:

4,534 - 4,630 lbs (2057 - 2100 kg)

Gross Vehicle Weight Rating:

6,000 lbs (2722 kg)

Payload Capacity:

1,450 lbs (658 kg) (approx.)

Towing Capacity:

3,500 lbs (1588 kg)

🛡️ Safety Features

Ratings

NHTSA Frontal Crash:

5-Star (Driver and Passenger)

NHTSA Side Impact:

5-Star (Front and Rear Passenger)

IIHS Moderate Overlap Frontal:

IIHS Side Impact:

IIHS Roof Strength:

Active Features

4-wheel Anti-lock Braking System (ABS) with Electronic Brake Distribution (EBD)

Traction Control:

Traction Control System (TCS)

Stability Control:

Vehicle Stability Assist (VSA)

Passive Features

Airbags:

Dual-stage, dual-threshold front airbags, front side airbags, side curtain airbags.

Seatbelts:

3-point front and rear seatbelts with pre-tensioners and load limiters.

Child Seats:

LATCH (Lower Anchors and Tethers for CHildren) system.

💡 Technology Features

Infotainment

Audio System:

Available premium audio system with subwoofer, USB audio interface, and Bluetooth HandsFreeLink.

Navigation:

Optional Honda Satellite-Linked Navigation System with voice recognition.

Driver Assistance

Camera:

Multi-angle rearview camera (standard on RTL trim, optional on others).

Connectivity

Bluetooth:

Bluetooth HandsFreeLink for hands-free calling and audio streaming.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 to 10,000 miles or 12 months, based on oil life monitoring system.

Engine Oil Type Capacity:

5W-20 Synthetic Blend, 4.5 US quarts (4.3 L) with filter change.

Air Filter Replacement:

Every 15,000 to 30,000 miles, or as needed based on driving conditions.

Spark Plug Replacement:

Platinum-tipped spark plugs, typically every 100,000 miles.

Transmission Fluid Change:

Every 60,000 to 100,000 miles (check Honda maintenance minder or severe service schedule).

Fluid Specifications

Coolant Type:

Honda Type 2 Coolant (Blue) - requires a 50/50 mix with distilled water.

Brake Fluid Type:

DOT 3 or DOT 4

Power Steering Fluid Type:

Honda Genuine Power Steering Fluid (or equivalent Dexron II/III)

Known Issues

Timing Belt Tensioner:

Some early models experienced issues with timing belt tensioners, though less common on the 3.5L V6 in the 2011 Ridgeline.

ECM/PCM Software:

Occasional issues with Engine Control Module (ECM) or Powertrain Control Module (PCM) software requiring updates.

Rear Differential Noise:

Some instances of noise from the VTM-4 rear differential, often related to fluid change intervals or initial engagement.

Drive Shaft Boots:

Premature wear or cracking of drive shaft boots, particularly in climates with extreme temperatures or road salt.

📚 Vehicle History

Brand Heritage

Honda Truck History:

Honda's second attempt at a pickup truck after the short-lived SUT (Sport Utility Truck) concept.

Model Evolution

First Gen Introduction:

Launched for the 2006 model year, based on Honda's Global Advanced Platform (shared with Odyssey, Pilot).

2011 Model Year Updates:

Minor styling updates, improved interior materials, standard VTM-4 AWD.

Production

Assembly Location:

Lincoln, Alabama, USA

🏆 Awards & Recognition

Recognitions

Truck Of The Year:

Often lauded for its refined ride and unique features, though not typically competing for 'Truck of the Year' in traditional truck categories.

Safety Awards:

Consistently received high safety ratings from NHTSA and IIHS.
