Market Position:
The 2015-2017 Ford Mustang (S550 generation) represented a significant leap forward, blending classic Mustang heritage with modern technology, performance, and a global platform design. It competed with a range of sporty coupes and convertibles, including the Chevrolet Camaro, Dodge Challenger, and entry-level luxury performance vehicles.
Competitive Analysis:
The S550 Mustang was lauded for its independent rear suspension (IRS) across all models, a first for the Mustang, significantly improving ride quality and handling dynamics compared to previous generations. The introduction of the 2.3L EcoBoost engine provided a more fuel-efficient, yet still potent, entry point into the Mustang lineup.
Key Features Of Vehicles:
Independent Rear Suspension (IRS) for all models, advanced SYNC infotainment, modern styling, available performance packages (e.g., Performance Pack for EcoBoost and GT), powerful engine options.
Manual Usefulness:
This manual is invaluable for owners and technicians alike, offering comprehensive, factory-authorized procedures to maintain, diagnose, and repair the 2015-2017 Ford Mustang across its diverse engine and transmission offerings. Its detailed diagrams and step-by-step instructions empower users to tackle complex tasks efficiently and correctly.
Engine Mechanical:
Engine assembly, disassembly, cylinder head, block, pistons, crankshaft, camshafts, lubrication system, cooling system, fuel system, ignition system, exhaust system, turbocharger (2.3L EcoBoost).
Engine Performance:
Engine tuning, diagnostics, emission control systems, powertrain control module (PCM) diagnostics and reprogramming.
Transmission Manual:
Clutch system, transmission assembly, disassembly, gear selection, linkages, service.
Transmission Automatic:
Automatic transmission assembly, disassembly, torque converter, valve body, electronic control, service.
Drivetrain:
Driveshafts, axles, differential (rear), wheel bearings, hub assemblies.
Suspension:
Front suspension (MacPherson strut, independent double ball joint), rear suspension (integral link independent), shock absorbers, springs, control arms, bushings, alignment procedures.
Steering:
Electric Power Assisted Steering (EPAS) system, steering column, steering rack, tie rods, diagnosis and repair.
Brakes:
Front and rear brake systems, calipers, rotors, pads, hydraulic system, Anti-lock Braking System (ABS), Electronic Stability Control (ESC), parking brake, brake fluid specifications.
Electrical System:
Battery, charging system, starting system, lighting system (headlights, taillights, interior), fuses, relays, wiring diagrams, connectors.
Body And Frame:
Body panels, doors, hood, trunk, glass, interior trim, exterior trim, chassis components, corrosion protection.
HVAC:
Heating, ventilation, and air conditioning (HVAC) system, refrigerant, components, diagnosis and repair.
Infotainment And Electronics:
Audio system, SYNC infotainment system, navigation system, instrument cluster, driver information system, sensors, control modules.
Safety Systems:
Airbag system, seat belts, restraint systems, safety sensor diagnostics.
Maintenance:
Scheduled maintenance, oil changes, fluid checks and top-offs, filter replacements, spark plug replacement, belt inspection and replacement.
Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based diagnostics, electrical troubleshooting charts, component testing.
Repair:
Step-by-step repair procedures for all major systems, component replacement, alignment, brake service, engine rebuilds, transmission rebuilds.
Diagnostics:
On-Board Diagnostics (OBD-II) system usage, scanner tool operation, sensor testing, module programming.
Technical Specifications:
Torque specifications, clearances, fluid capacities, electrical component specifications, diagnostic parameters.
Wiring Diagrams:
Comprehensive wiring schematics for all vehicle systems, including power distribution, grounds, and signal paths.
Depth:
Complete factory-level technical information for diagnosis, repair, and maintenance. Covers everything from basic fluid changes to complete engine and transmission overhauls.
Engine 2.3L Ecoboost Type:
Inline 4-Cylinder Turbocharged
Engine 2.3L Ecoboost Displacement:
2.3 Liters (2300 cc)
Engine 2.3L Ecoboost Horsepower:
Approx. 310 hp @ 5500 rpm
Engine 2.3L Ecoboost Torque:
Approx. 320 lb-ft @ 2500-4500 rpm
Engine 3.7L V6 Type:
Naturally Aspirated V6
Engine 3.7L V6 Displacement:
3.7 Liters (3726 cc)
Engine 3.7L V6 Horsepower:
Approx. 300 hp @ 6500 rpm
Engine 3.7L V6 Torque:
Approx. 280 lb-ft @ 4000 rpm
Engine 5.0L V8 Type:
Naturally Aspirated V8 (Coyote)
Engine 5.0L V8 Displacement:
5.0 Liters (4951 cc)
Engine 5.0L V8 Horsepower:
Approx. 435 hp @ 6500 rpm
Engine 5.0L V8 Torque:
Approx. 400 lb-ft @ 4250 rpm
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded gasoline (premium recommended for optimal performance, especially for EcoBoost and GT models)
Wheelbase:
Approx. 107.1 inches (2720 mm)
Overall Length:
Approx. 188.3 inches (4783 mm)
Overall Width:
Approx. 75.1 inches (1908 mm)
Overall Height:
Approx. 54.4 inches (1382 mm)
Curb Weight 2.3L Ecoboost:
Approx. 3,532 lbs (1602 kg)
Curb Weight 3.7L V6:
Approx. 3,735 lbs (1694 kg)
Curb Weight 5.0L Gt:
Approx. 3,835 lbs (1739 kg)
Trunk Volume Coupe:
Approx. 13.5 cu ft (382 Liters)
Trunk Volume Convertible:
Approx. 11.4 cu ft (323 Liters)
Oil Change Interval:
Every 7,500-10,000 miles or 12 months, whichever comes first (synthetic oil recommended).
Engine Air Filter:
Inspect every 15,000 miles, replace as needed.
Cabin Air Filter:
Replace every 15,000-20,000 miles or annually.
Spark Plugs 2.3L Ecoboost:
Replace at 100,000 miles.
Spark Plugs 3.7L V6:
Replace at 100,000 miles.
Spark Plugs 5.0L V8:
Replace at 100,000 miles.
Transmission Fluid Manual:
Check level as needed, fluid change typically at higher mileage intervals (e.g., 100,000 miles) or if performance is affected.
Transmission Fluid Automatic:
Check level as needed, fluid and filter change recommended at 60,000-100,000 miles depending on driving conditions.
Engine Oil 2.3L Ecoboost:
SAE 5W-30 Synthetic (Ford WSS-M2C946-B1 or equivalent)
Engine Oil 3.7L V6:
SAE 5W-20 (Ford WSS-M2C945-A or equivalent)
Engine Oil 5.0L V8:
SAE 5W-20 (Ford WSS-M2C945-A or equivalent)
Coolant:
Ford Premium Engine Coolant (Yellow) WSS-M97B44-D2 or equivalent; 50/50 mixture with distilled water.
Brake Fluid:
DOT 4 Motor Vehicle Brake Fluid.
Transmission Fluid Manual:
Refer to manual for specific fluid type and capacity (often a gear oil meeting specific GL rating).
Transmission Fluid Automatic:
MERCON LV (XT-10-QLVC) or equivalent.
Known Issues 2.3L Ecoboost:
Potential for coolant hose leaks, turbocharger issues at higher mileage, attention to maintenance for longevity.
Known Issues 3.7L V6:
Less common, but attention to oil changes and general maintenance is key.
Known Issues 5.0L V8:
Focus on cooling system integrity, exhaust manifold concerns in some early models, regular oil changes.
General Issues:
Some early models had reports of manual transmission clutch pedal issues, potential for water intrusion in certain areas if not properly maintained, TPMS sensor issues.
