🏷️ Basic Information

Make:

BMW

Model:

X5

Generation:

E70

Model Year:

2009

Chassis Code:

E70

👋 Introduction

Segment:

Luxury Mid-size SUV

Positioning:

Premium Sport Activity Vehicle (SAV) with emphasis on driving dynamics, luxury, and advanced technology.

Key Competitors:

Mercedes-Benz M-Class, Audi Q7, Lexus RX, Porsche Cayenne, Volvo XC90

Design Philosophy:

Blend of BMW's characteristic sportiness with SUV practicality and luxury, featuring a distinctive kidney grille and athletic stance.

Innovation:

Advanced xDrive all-wheel-drive system, sophisticated suspension options, and integrated electronic systems.

📋 Manual Details

Engine Coverage:

All gasoline and diesel engines for E70 X5 (2007-2013)

Transmission Coverage:

Automatic and Steptronic transmissions

Electrical Coverage:

Full electrical system diagrams, modules, sensors, and actuators

Chassis Coverage:

Suspension, steering, brakes, driveline, and drivetrain components

Body Coverage:

Body panels, interior trim, doors, glass, and seals

Maintenance Coverage:

Scheduled maintenance, fluid changes, filter replacements, and general upkeep

Troubleshooting Coverage:

Diagnostic procedures, common fault codes, and symptom-based troubleshooting

Repair Coverage:

Step-by-step repair instructions for all major components and systems

Total Pages:

Approx. 2500+ pages (indicative for comprehensive workshop manuals)

Type:

Workshop Service Repair Manual

Language:

English

Format:

PDF (Digital Download)

📖 Manual Coverage

Engine Systems:

N62 V8, N52 Inline-6, N55 Inline-6, M62 V8 (if applicable to specific 2009 variants), S63 V8 (if applicable), diesel engines (M57, N57) - including cooling, lubrication, fuel injection, ignition, exhaust, emissions control

Transmission Systems:

ZF 6HP automatic transmissions, Steptronic operation, transfer case, xDrive all-wheel drive system

Braking Systems:

Hydraulic brake system, ABS, DSC (Dynamic Stability Control), electronic parking brake, brake pad and rotor replacement, brake fluid flush

Suspension Systems:

Front and rear suspension, adaptive drive (if equipped), air suspension (if equipped), struts, shocks, control arms, ball joints, bushings

Steering Systems:

Power steering system, steering rack, tie rods, power steering fluid

Electrical Systems:

Battery, alternator, starter, lighting, interior/exterior electronics, comfort systems, infotainment wiring, diagnostic connectors (OBD-II)

Body And Interior Systems:

Door mechanisms, window regulators, sunroof, seats, airbags, climate control system, dashboard, center console

Routine Maintenance:

Oil and filter change, air filter replacement, cabin filter replacement, spark plug replacement, brake fluid flush, coolant flush, drive belt inspection and replacement

Engine Repairs:

Head gasket replacement, valve cover gasket replacement, piston and ring inspection/replacement, crankshaft and camshaft inspection, engine mount replacement, timing chain service (if applicable)

Transmission Repairs:

Transmission fluid and filter change, solenoid replacement, torque converter replacement, valve body repair, transmission rebuild procedures

Brake System Repairs:

Brake caliper rebuild/replacement, brake hose replacement, ABS module diagnosis and replacement, DSC sensor calibration

Suspension And Steering Repairs:

Strut and shock absorber replacement, control arm bushing replacement, ball joint replacement, power steering pump replacement, steering rack repair

Electrical Diagnostics:

Wiring harness repair, sensor testing and replacement, module programming, ECU diagnosis, starter and alternator testing

Bodywork Procedures:

Door panel removal, mirror replacement, bumper cover removal, headlight and taillight replacement, interior trim panel removal

Diagnostic Troubleshooting:

Fault code reading and interpretation, live data stream analysis, component testing with diagnostic tools (e.g., ISTA/D)

Depth:

Comprehensive: Covers routine maintenance, intermediate repairs, and major overhauls. Includes detailed diagnostic trees and specifications.

📊 Manual Specifications

File Type:

Portable Document Format (.PDF)

Searchability:

Fully searchable text for quick information retrieval

Print Readability:

High-resolution digital scans for clear diagrams and text, suitable for printing.

Binding:

N/A (Digital Format)

Paper Quality:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Options 2009:

3.0L Inline-6 (N52), 4.8L V8 (N62), 3.0L Turbo Diesel (M57)

Engine Code 3.0L I6:

N52B30

Engine Displacement 3.0L I6:

2996 cc (3.0 Liters)

Horsepower 3.0L I6:

255 hp @ 6600 rpm

Torque 3.0L I6:

236 lb-ft @ 2750-4000 rpm

Engine Code 4.8L V8:

N62B48

Engine Displacement 4.8L V8:

4799 cc (4.8 Liters)

Horsepower 4.8L V8:

350 hp @ 6300 rpm

Torque 4.8L V8:

350 lb-ft @ 3400 rpm

Engine Code 3.0L Diesel:

M57TUD30

Engine Displacement 3.0L Diesel:

2993 cc (3.0 Liters)

Horsepower 3.0L Diesel:

261 hp @ 4000 rpm

Torque 3.0L Diesel:

443 lb-ft @ 1750-2500 rpm

Fuel Type:

Unleaded gasoline (premium recommended), Diesel fuel

Injection System:

Direct injection (gasoline models), Common Rail Direct Injection (diesel models)

Forced Induction:

Turbocharged (diesel models), Optional Twin-turbocharged (N63 V8 later models, N54 Inline-6 in some markets/variants)

🔧 Transmission

Transmission Type:

6-speed Steptronic automatic transmission

Optional Transmission:

N/A for most 2009 models; manual was phased out for E70.

Drivetrain:

xDrive all-wheel-drive system (standard)

Transmission Fluid Spec:

BMW LT-3 or equivalent (refer to manual for specific application)

📐 Dimensions

Length:

191.8 inches (4872 mm)

Width:

75.5 inches (1918 mm)

Height:

69.5 inches (1766 mm)

Wheelbase:

115.3 inches (2930 mm)

Seating Capacity:

5 (standard), 7 (optional)

Cargo Volume Behind 2Nd Row:

25.7 cu ft (728 Liters)

Cargo Volume Max:

75.2 cu ft (2130 Liters)

Curb Weight Approx:

4700-5000 lbs (2132-2268 kg) depending on engine and options

Towing Capacity Max:

5000 lbs (2268 kg)

🛡️ Safety Features

NHTSA Rollover Resistance:

4/5 Star (indicative, check specific test data)

Stability Control:

Dynamic Stability Control (DSC)

Traction Control:

Automatic Stability Control + Traction (ASC+T), Dynamic Traction Control (DTC)

Braking Assistance:

Anti-lock Braking System (ABS), Electronic Brake Force Distribution (EBD), Brake Assist

Airbags:

Front airbags, front side-impact airbags, head protection system (front and rear)

Seatbelts:

3-point inertia-reel seatbelts with pretensioners and force limiters

💡 Technology Features

Infotainment System:

iDrive infotainment system with navigation, radio, CD/DVD player, auxiliary input, Bluetooth connectivity

Display Type:

Central color LCD screen

Available Features:

Adaptive Headlights, Parking Assistant (Park Distance Control), Rearview Camera, Head-Up Display (HUD)

Connectivity Options:

BMW Assist with Bluetooth, USB adapter, optional satellite radio

🔧 Maintenance

Oil Change Interval:

Condition-based service (CBS) system, typically 10,000-15,000 miles or annually.

Brake Fluid Flush:

Every 2 years (regardless of mileage)

Spark Plug Replacement N52:

Approx. 60,000 miles

Transmission Fluid Service:

Recommended between 60,000-100,000 miles (BMW's stance varies, but service is advisable)

Engine Oil Spec Gasoline:

BMW Longlife-01 (LL-01) or Longlife-04 (LL-04) 5W-30 or 0W-30 synthetic oil

Engine Oil Spec Diesel:

BMW Longlife-04 (LL-04) 5W-30 or 0W-30 synthetic oil

Coolant Spec:

BMW Blue Antifreeze/Coolant (ethylene glycol-based)

Power Steering Fluid:

Pentosin CHF 11S or Pentosin CHF 202 (check specific model requirements)

Common Issues E70:

Valve cover gasket leaks, oil pan gasket leaks, cooling system leaks (water pump, thermostat, hoses), VANOS solenoid failures, active steering system issues, rear air suspension leaks (if equipped), exhaust manifold cracks (N62 V8), DPF issues (diesel models)

📚 Vehicle History

Brand Focus:

BMW, Bayerische Motoren Werke AG, known for performance, luxury, and engineering excellence in automobiles.

First Generation:

E53 (1999-2006)

Second Generation:

E70 (2007-2013)

E70 Launch Year:

2006 (for the 2007 model year)

E70 Facelift:

LCI (Life Cycle Impulse) in 2010

Manufacturing Locations:

Spartanburg, South Carolina, USA; Leipzig, Germany

🏆 Awards & Recognition

Typical Awards For Segment:

Often recognized for luxury, performance, and utility in automotive reviews and awards (e.g., Car and Driver's "10Best SUVs" in earlier iterations of similar BMW models).
