Model Years Covered:
2010, 2011, 2012, 2013, 2014, 2015, 2016
Chassis Code:
GM Theta Platform (Specifically the Theta Premium variant for later models)
Engine Codes Implied:
LF1 (3.0L V6), LFX (3.6L V6), LE9 (2.4L I4), LU9 (3.6L V6 - Canadian Market)
Vehicle Segment:
Compact Crossover SUV
Vehicle Purpose:
Practical family vehicle, often positioned as an affordable and capable crossover
Key Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Hyundai Tucson, Kia Sportage
Manual Advantage:
Vehicle-specific, factory-level detail, comprehensive coverage, digital format convenience
Value Proposition:
Empowers owners and technicians to perform accurate maintenance, diagnosis, and repair, saving time and money compared to relying solely on dealerships.
Powertrain:
Engine (all aspects), Fuel System, Lube System, Cooling System, Intake & Exhaust, Emission Control, Automatic Transmission, Manual Transmission (if applicable to certain trims/years), Transfer Case (if applicable)
Chassis:
Drive Shaft, Differential, Axles, Suspension (Front and Rear), Steering Column, Power Steering, Brakes (Hydraulic, Parking), Tire & Wheel
Electrical And Electronics:
Ignition, Starting, Charging, Control Systems (ECU, PCM, TCM), Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Air Conditioning, Multiplex/CAN Communication, Wiring Schematics
Body And Interior:
Wiper & Washer, Door Locks, Meter & Audio/Visual Systems, Horn, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Lighting
Maintenance And Service:
Scheduled maintenance, fluid changes, filter replacements, inspections
Diagnosis And Troubleshooting:
Step-by-step diagnostic procedures, symptom analysis, fault code interpretation
Repair And Rebuild:
Component removal, installation, overhaul, and replacement
Specifications And Data:
Torque values, clearances, fluid types and capacities, electrical specifications
Depth:
Factory-level detail, suitable for professional technicians and advanced DIYers
Detail Level:
Complete step-by-step instructions, diagrams, illustrations, and wiring schematics
Compatibility:
Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac
Required Software:
Adobe PDF Reader, Winzip (free)
Printability:
Yes (all pages printable)
Image Scaling:
Images can be blown up and printed enlarged
Binding Format:
Digital (PDF - no physical binding)
Paper Type Implication:
N/A (Digital format, but printable on any paper type)
Engine Options:
2.4L Ecotec Inline-4 (LE9) and 3.0L/3.6L V6 (LF1/LFX)
2.4L I4 Horsepower:
Approx. 182 hp @ 6700 rpm (Varies slightly by year)
2.4L I4 Torque:
Approx. 172 lb-ft @ 4900 rpm (Varies slightly by year)
3.6L V6 Horsepower:
Approx. 263-288 hp @ 6300-6400 rpm (Varies by year)
3.6L V6 Torque:
Approx. 225-269 lb-ft @ 4400-4900 rpm (Varies by year)
Fuel Delivery:
Multi-port Fuel Injection (MPFI) or Direct Injection (DI) for later V6 models
Fuel Type:
Unleaded Gasoline
Transmission Type:
6-speed Automatic Transmission (Generally standard across most powertrains)
Transmission Options:
All-wheel drive (AWD) was an available option on most trims, paired with the automatic transmission.
Transmission Features:
Includes electronic control, adaptive shift logic, and manual mode for driver selection.
NHTSA Overall Rating:
Mixed ratings across model years and tests, typically 4 out of 5 stars overall in earlier years, with specific test results varying.
Active Safety Features:
Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC)
Passive Safety Features:
Front airbags, front side-impact airbags, curtain airbags, active head restraints (availability may vary by trim/year)
Infotainment System:
Available Chevrolet MyLink infotainment system with touchscreen, Bluetooth connectivity, USB ports, and optional navigation (depending on trim and year).
Driver Assistance Features:
Available rear parking sensors, rearview camera (standard on later models or optional on earlier ones), and potentially blind-spot monitoring on higher trims.
Connectivity Features:
Bluetooth hands-free calling and audio streaming, USB connectivity for media playback and device charging.
Oil Change Interval:
Typically every 7,500 miles or 12 months (using synthetic oil), or as indicated by the oil life monitor system.
Tire Rotation Interval:
Every 7,500 miles
Cabin Air Filter Replacement:
Typically every 15,000-20,000 miles or annually
Engine Oil Specification:
Dexos1® SAE 5W-30 Synthetic (Consult manual for exact specifications based on engine variant and climate)
Transmission Fluid Specification:
Dexron® VI Automatic Transmission Fluid (ATF)
Coolant Specification:
GM Engineering Standard GMW3420 (Orange or Pink colored coolant)
Common Issues:
Early models and specific powertrains have reported issues with catalytic converter failure, transmission solenoid problems, and occasional electrical gremlins. The V6 engines, while powerful, can be prone to timing chain issues if oil changes are neglected.
Chevrolet Heritage:
Longstanding American automotive manufacturer known for a broad range of vehicles from economical sedans to performance cars and trucks.
Captiva Sport Origins:
The Captiva Sport was a rebadged version of the Opel Antara, sold in North America. It aimed to fill a niche in Chevrolet's SUV lineup between the Equinox and the larger Traverse.
Production Location:
Primarily manufactured in Mexico (GM's Ramos Arizpe plant)
Production Period:
Introduced for the 2008 model year (as Saturn Vue successor) and continued as Chevrolet Captiva Sport through 2016.
Safety Awards:
Received generally good safety ratings from organizations like the IIHS and NHTSA for its respective model years, though specific awards are not prominently documented.
Consumer Reviews:
Consumer reviews often highlight its practicality, comfortable ride, and value proposition, while also noting some interior material quality concerns and less engaging driving dynamics compared to some competitors.
