Segment:
Compact Crossover SUV
Target Audience:
Families, individuals seeking a versatile and fuel-efficient SUV.
Competitors:
Toyota RAV4, Honda CR-V, Ford Escape, Nissan Rogue, Hyundai Tucson, Kia Sportage.
Design Philosophy:
Comfortable ride, practical interior, and available AWD, blending car-like handling with SUV utility.
Manual Advantage:
Empowers owners to perform maintenance and repairs, saving money and extending vehicle lifespan.
Engine:
Includes detailed repair and diagnostic procedures for 2.4L I4 and 3.0L V6 engines.
Transmission:
Covers repair and diagnostics for 6-speed automatic transmissions (e.g., 6T45, 6T70).
Brakes:
Detailed information on ABS, hydraulic systems, brake pad replacement, rotor servicing, and parking brake.
Electrical System:
Includes wiring diagrams, component locations, diagnostic procedures for lighting, power accessories, ignition, starting, and charging systems.
Suspension Steering:
Covers front and rear suspension components, steering rack, power steering system, alignment specifications.
HVAC:
Refrigerant system servicing, component replacement (compressor, evaporator, condenser), and diagnostics.
Body Exterior:
Procedures for body panel removal/installation, door mechanisms, glass replacement, bumpers, and trim.
Body Interior:
Includes seat removal, dashboard disassembly, interior trim, and headliner procedures.
Safety Systems:
Airbag system diagnostics and replacement procedures, seatbelt servicing.
Fuel System:
Fuel pump replacement, injector servicing, fuel filter replacement, and fuel pressure diagnostics.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, lubrication, tire rotation, brake checks.
Repair:
Complete repair instructions for all major vehicle systems, from minor component replacements to major overhauls.
Diagnostics:
Detailed troubleshooting guides, symptom-based diagnostics, use of diagnostic scan tools, and specific diagnostic trouble codes (DTCs).
Replacement:
Step-by-step instructions for replacing virtually any part on the vehicle.
Installation:
Procedures for installing accessories and optional equipment.
Specifications:
Torque specifications, clearances, fluid capacities, wiring schematics, component specifications.
Depth:
Complete workshop level, suitable for professional technicians and advanced DIY enthusiasts. Covers everything from basic maintenance to complex engine and transmission rebuilds.
Searchable:
Yes (standard PDF search functionality)
Quality:
High-resolution scans/digital files, suitable for clear printing of text and diagrams.
Binding:
N/A (Digital Download - User printable)
Paper Type:
N/A (Digital Download - User chooses paper type if printing)
Required Software:
Adobe Reader (free download)
Variant 1:
2.4L DOHC I4 (LAF)
Variant 1 Horsepower:
182 hp @ 6700 rpm (approx.)
Variant 1 Torque:
172 lb-ft @ 4500 rpm (approx.)
Variant 2:
3.0L DOHC V6 (LF1)
Variant 2 Horsepower:
264 hp @ 6900 rpm (approx.)
Variant 2 Torque:
221 lb-ft @ 5100 rpm (approx.)
Type:
Electronic Fuel Injection (EFI)
Recommended Fuel:
87 Octane Unleaded Gasoline (premium recommended for V6 for optimal performance)
Type:
Pressurized Liquid Cooling System
Type:
6-speed Automatic (e.g., Hydra-Matic 6T45 for 2.4L, 6T70 for 3.0L)
Drivetrain:
All-Wheel Drive (AWD) available on most trims
Manual Mode:
Driver Shift Control (manual shifting capability)
Transmission Fluid Type:
Dexron VI Automatic Transmission Fluid (ATF)
NHTSA Rollover Rating:
4 out of 5 stars (for 2010-2012 models)
Traction Control:
Standard
Electronic Stability Control:
Standard (StabiliTrak)
Anti Lock Brakes:
Standard (4-wheel disc ABS)
Airbags:
Frontal, side-impact, and curtain airbags
Child Seat Anchors:
LATCH system
Available Systems:
Chevrolet MyLink infotainment system (optional on some trims), touchscreen display, USB connectivity, Bluetooth.
Available Features:
Rear Vision Camera (optional on some trims), Parking Assist (optional on some trims).
Available Features:
Bluetooth for hands-free calling and audio streaming.
Oil Change Interval:
7,500 miles or 6 months (whichever comes first), using synthetic oil. Consult manual for specific conditions.
Engine Air Filter:
Inspect every 30,000 miles, replace as needed. Replace at 100,000 miles as a scheduled item.
Cabin Air Filter:
Inspect every 15,000 miles, replace as needed. Replace at 30,000 miles as a scheduled item.
Transmission Fluid Change:
Recommended every 60,000 to 100,000 miles, depending on driving conditions. Refer to manual for specific recommendations.
Engine Oil Type:
SAE 0W-20 (for 2.4L I4 and 3.0L V6)
Engine Oil Capacity:
Approx. 4.8 quarts (with filter) for 2.4L I4; Approx. 5.5 quarts (with filter) for 3.0L V6
Coolant Type:
GM P/N 12346340 (Blue) or equivalent Dex-Cool® compatible antifreeze/coolant
Engine Oil Consumption:
Some 2.4L Ecotec engines may exhibit oil consumption issues; the manual provides diagnostic procedures.
Transmission Shifting:
Occasional reports of rough shifting or hesitation; manual covers transmission control module (TCM) diagnostics and relearn procedures.
Suspension Noises:
Potential for worn suspension components (e.g., struts, sway bar links) leading to noise; manual guides inspection and replacement.
Manufacturer:
Chevrolet, a division of General Motors (GM).
Generation Introduction:
The second generation Equinox debuted for the 2010 model year, featuring a significant redesign and new powertrain options.
Key Changes 2010:
All-new platform, updated styling, new 2.4L Ecotec I4 and 3.0L V6 engines, new 6-speed automatic transmission, improved fuel economy.
Assembly Locations:
CAMI Automotive (Ingersoll, Ontario, Canada), Oshawa Assembly (Oshawa, Ontario, Canada)
