The Daihatsu Gran Move, produced between 1996 and 2001, is a versatile compact MPV renowned for its exceptional space efficiency within compact exterior dimensions. Designed for families and individuals seeking a practical vehicle with a higher seating position and greater cargo capacity than conventional hatchbacks, the Gran Move offered a unique blend of maneuverability and interior volume. Its engineering focused on practicality and reliability, characteristic of compact car manufacturing. Available with approximately 1.3-liter or 1.6-liter inline 4-cylinder engines, and either a 5-speed manual or 4-speed automatic transmission, this model provided a functional and economical transportation solution.
This comprehensive workshop manual, written in German, serves as an essential resource for maintaining and repairing the Daihatsu Gran Move. It covers a wide array of critical systems, including general information, engine mechanics, emission control, fuel and lubrication systems, cooling and ignition, starter and charging systems, clutch, manual and automatic transmissions, front and rear axles, suspension, brakes, and steering. Additionally, detailed sections address bodywork, body electrical systems, and extensive wiring diagrams. The manual provides in-depth procedures for scheduled maintenance, diagnostics, component repair, and replacement, offering technical specifications and torque values suitable for both professional technicians and experienced DIY enthusiasts.
Chassis Codes:
G301, G303
Production Years:
1996-2001
Vehicle Segment:
Compact MPV / Hatchback
Target Audience:
Families, individuals seeking practical and versatile small car with higher seating position and cargo capacity than typical hatchbacks.
Competitors:
Competed with other compact MPVs and larger hatchbacks of its era, such as Opel/Vauxhall Agila, Fiat Multipla (later), and some smaller C-segment hatchbacks offering similar practicality.
Design Philosophy:
Compact exterior dimensions with surprisingly spacious and flexible interior, offering good visibility and a higher driving position.
Usp:
Practicality and space efficiency in a small footprint, typical of Daihatsu's specialization in compact vehicles.
Content Summary:
General Information, Maintenance, Engine, Emission Control, Fuel System, Lubrication, Cooling System, Ignition System, Starter System, Charging System, Clutch, Manual Transmission, Front Axle and Suspension, Rear Axle and Suspension, Brake System, Steering, Body, Body Electrical, Wiring Diagrams, Injection System, Automatic Transmission
Type:
Workshop Manual / Werkstatthandbuch
Download Availability:
Instant Download
Print Capability:
Printable
Operating System Compatibility:
Windows, Mac
Powertrain:
Engine (mechanical, fuel, ignition, cooling, lubrication, emissions), Clutch, Manual Transmission, Automatic Transmission
Chassis:
Front Suspension, Rear Suspension, Steering System, Brake System
Electrical:
Ignition System, Starter System, Charging System, Body Electrical, Wiring Diagrams (Stromlaufplan)
Bodywork:
Body (Karosserie), Body Electrical (Karosserie-Elektrik)
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, inspections
Diagnostics:
Troubleshooting guides, symptom-based diagnostics, fault code interpretation (where applicable for the era)
Repair Overhaul:
Engine rebuild procedures, transmission overhaul, brake caliper replacement, suspension component repair, electrical component repair
Component Replacement:
Detailed instructions for replacing major components (e.g., engine, transmission, suspension arms, steering rack)
Level Of Detail:
Comprehensive, suitable for professional technicians and experienced DIYers. Includes detailed specifications, torque values, clearances, and diagnostic flowcharts.
