Market Segment:
High-performance sportbike (superbike)
Competitors:
BMW S1000RR, Yamaha R1, Kawasaki ZX-10R, Honda CBR1000RR, Suzuki GSX-R1000
Distinguishing Features:
L-twin engine, desmodromic valve system, Italian design and engineering, advanced electronics (for its era)
Coverage:
All aspects of repair, maintenance, and servicing
Estimated Page Count:
Comprehensive, specific count not provided but described as extensive
Type:
Workshop Service Repair Manual, Parts Catalogue
Language:
English (Implied by standard workshop manual conventions)
Format:
HTML (Downloadable)
Covered Systems:
Fairing, Control Devices, Wheel Suspension, Brakes, Handlebar, Steering, Frame, Fuel System, Exhaust System, Ignition System, Injection System, Engine Removal/Installation, Lubrication System, Cylinder/Piston/Clutch, Gearbox/Connecting Rods, Electric System, Wiring Diagram
Engine Mechanical:
Cylinder head, valves, pistons, connecting rods, crankshaft, lubrication system, oil pump, oil cooler, cooling system.
Fuel And Injection:
Fuel tank, fuel pump, fuel filter, injectors, throttle bodies, ECU control, diagnostic port.
Ignition And Electrical:
Ignition coils, spark plugs, battery, alternator, starter motor, lighting system, wiring harnesses, ECU functions, sensors.
Included Procedures:
Detailed step-by-step written procedures, exploded views, diagnostics, troubleshooting, maintenance, repair, component installation/removal, servicing
Engine Rebuild:
Complete engine removal, disassembly, inspection, repair, and reassembly procedures with torque specifications.
Suspension Service:
Front fork (Ohlins on S model) disassembly, seal replacement, oil changes, and rear shock absorber adjustment/rebuild.
Brake System Maintenance:
Brake pad replacement, fluid bleeding, caliper service, master cylinder overhaul.
Depth:
Comprehensive, suitable for technicians and advanced DIY mechanics
Diagnostic Capabilities:
Fault code reading and interpretation, troubleshooting guides for electrical and mechanical issues, component testing procedures.
Parts Identification:
Detailed exploded views with part numbers for easy identification and ordering.
Engine Type:
Longitudinal 90º 'L' twin cylinder, four-stroke
Compression Ratio:
12.7±0.5:1
Valve Actuation:
Desmodromic, with toothed belt, double overhead camshaft (DOHC)
Peak Horsepower:
Approximately 180 HP (Varies slightly by market and specific tuning, manual will detail exact specs)
Peak Torque:
Approximately 97 lb-ft (Varies slightly by market and specific tuning, manual will detail exact specs)
Fuel Delivery:
Electronic fuel injection, elliptical throttle bodies
Fuel Type:
Unleaded gasoline, minimum 95 octane (RON)
Braking System:
Dual 330mm semi-floating discs, radial calipers (front); Single 245mm disc, caliper (rear), Brembo components standard
Traction Control:
Ducati Traction Control (DTC) likely standard or optional on 1198S, detailed in manual
Frame Construction:
Monocoque in aluminum alloy
Display:
Digital LCD dashboard displaying speed, RPM, gear position, lap timer, etc.
Electronics Suite:
Ducati Data Analyser (DDA) capability (optional for 1198, standard on 1198S) for logging and analyzing performance data.
Diagnostics:
OBD-II port for diagnostic scanning, covered in the manual.
Desmo Service Interval:
Every 12,000 km (7,500 miles) or 24 months (whichever comes first) - critical for valve adjustment
Oil Change Interval:
Typically every 6,000-7,500 km (3,750-4,500 miles) or 12 months
Engine Oil Type:
Refer to manual for specific Ducati-approved grade (e.g., SAE 15W-50, API SG or higher, JASO MA)
Engine Oil Capacity:
Refer to manual (typically around 3.5-4.0 liters)
Coolant Type:
Ethylene glycol based coolant with corrosion inhibitors
Brake Fluid Type:
DOT 4 (or DOT 5.1 if specified by Ducati for the system)
Clutch Fluid Type:
DOT 4 (or DOT 5.1 if specified by Ducati for the system)
Desmodromic Valve Adjustment:
Requires specialized tools and knowledge; incorrect adjustment can lead to severe engine damage.
Fuel Pump Reliability:
Some early models or specific batches might have had issues; manual will cover diagnostic procedures.
Electrical Connections:
As with many performance bikes, ensuring clean and secure electrical connections is vital.
