Positioning:
The Harley-Davidson Sportster XLH series represented a more accessible entry point into Harley ownership, known for its classic styling and V-twin character. This manual serves owners and independent shops seeking to maintain and repair these iconic motorcycles.
Competitors:
Competes with other V-twin cruisers from brands like Indian, Yamaha (V-Star), Honda (Shadow), Kawasaki (Vulcan), and Suzuki (Intruder) in its segment.
Features Of Bike:
Air-cooled Evolution V-twin engine, belt drive, classic styling, customizable platform, responsive handling for its class.
Value:
Empowers owners with the knowledge to perform their own maintenance and repairs, saving on dealership costs and fostering a deeper connection with their machine.
Markets Covered:
North America, Europe, Asia-Pacific (based on typical Harley-Davidson distribution for this era)
Estimated Page Count:
700-900 pages (typical for a comprehensive workshop manual of this era)
Type:
Workshop Service Repair Manual
Format:
Instant Download (likely PDF)
Engine:
Engine disassembly, assembly, inspection, overhaul, troubleshooting, specific component repairs (carburetor, ignition, lubrication, cooling)
Transmission:
Gearbox operation, disassembly, assembly, troubleshooting, clutch operation and adjustment, final drive maintenance
Chassis:
Frame inspection, fork and suspension service, wheel and tire maintenance, brake system service (hydraulic and mechanical components), steering system service
Electrical:
Wiring diagrams, lighting system, ignition system, charging system (alternator, regulator), starting system, battery service, instrumentation, accessory installation
Fuel System:
Carburetor adjustment and overhaul (e.g., Keihin CV), fuel tank service, fuel lines, fuel filter replacement
Bodywork And Trim:
Fender removal and installation, fuel tank removal and installation, seat service, handlebar and control adjustments, minor body panel repairs and painting guidelines
Preventative Maintenance:
Routine checks, lubrication points, fluid changes, filter replacements, bolt torque specifications
Troubleshooting:
Diagnostic procedures for common issues, symptom-based troubleshooting guides, electrical system diagnostics
Repair Procedures:
Step-by-step instructions for component disassembly, overhaul, and reassembly for all major systems
Special Tools:
Identification and usage of specialized tools required for specific repair procedures
Depth:
Comprehensive (covers everything from basic maintenance to complete engine and transmission rebuilds)
đ Manual Specifications
Format Details:
Digital download, typically PDF for ease of searching and printing
Quality:
High-resolution scans or digital originals, ensuring clarity of diagrams and text
Binding:
Not Applicable (Instant Download)
Paper Type:
Not Applicable (Instant Download)
âïž Engine Specifications
Engine Type:
Air-cooled, Evolution V-twin
Displacement 883:
883 cc (53.9 cubic inches)
Displacement 1200:
1200 cc (73.2 cubic inches)
Bore Stroke 883:
76.2 mm x 96.8 mm (3.00 in x 3.81 in)
Bore Stroke 1200:
88.9 mm x 96.8 mm (3.50 in x 3.81 in)
Compression Ratio 883:
8.4:1 (typical)
Compression Ratio 1200:
9.0:1 (typical)
Horsepower Approx 883:
50-55 HP (at crankshaft, approximate)
Horsepower Approx 1200:
65-70 HP (at crankshaft, approximate)
Torque Approx 883:
50-55 ft-lbs (at crankshaft, approximate)
Torque Approx 1200:
65-70 ft-lbs (at crankshaft, approximate)
Fuel Delivery:
Carburetor (typically Keihin CV 40mm for 1200cc, Keihin CV 34mm for 883cc)
Fuel Type:
Unleaded Gasoline, minimum 91 octane (R+M)/2 (95 RON)
Oil Capacity:
Approx. 3 quarts (2.8 liters) with filter change
Oil Type:
Harley-Davidson SYN3 Synthetic Motorcycle Oil (20W-50) or equivalent API SG, Jaso MA rated oil
Type:
5-speed constant mesh, helical gear
Clutch Type:
Wet, multi-plate
Primary Drive:
Chain drive, 34/46 ratio
Final Drive:
Belt drive, 32/65 ratio
Transmission Fluid Type:
Harley-Davidson Primary Chain Case Oil or SAE 50 motorcycle oil
Transmission Fluid Capacity:
Approx. 1 quart (0.95 liters)
Crash Test Ratings:
Not Applicable (Motorcycle) - focus is on mechanical and operational safety systems.
Braking System:
Single disc front and rear with hydraulic actuation. Front caliper typically 2-piston, rear caliper typically 1-piston. ABS was not standard or commonly available on this model year.
Lighting:
Halogen headlamp, LED taillight, incandescent turn signals.
First Service:
1,000 miles (1,600 km) or 6 months
Subsequent Services:
Every 5,000 miles (8,000 km) or 12 months
Engine Oil Viscosity:
20W-50
Brake Fluid Type:
DOT 4 (for hydraulic systems)
Fork Oil Type:
Harley-Davidson Type 'E' or equivalent SAE 10W fork oil (check specific model for exact type)
Common Wear Items:
Clutch plates, drive belt, wheel bearings, fork seals, carburetor adjustments (idle stability), ignition coil issues (less common).
Electrical Considerations:
Corrosion on connectors, aging wiring harness insulation, starter solenoid reliability.
Spark Plugs:
Harley-Davidson OE (e.g., NGK Iridium CR10EIX or equivalent)
Oil Filter Part Number:
Harley-Davidson OE 63796-77B or equivalent aftermarket (e.g., K&N KN-170, Mann-Filter ML092)
Air Filter Part Number:
Harley-Davidson OE 29442-99 or equivalent aftermarket
Heritage:
Harley-Davidson, founded in 1903, is an American motorcycle manufacturer with a long history of producing iconic V-twin engines and cruiser-style motorcycles.
Sportster Lineage:
The Sportster line originated in 1957 and has evolved significantly, with the Evolution engine being introduced in 1986. The 2006 models represent a mature iteration of the Evolution-powered Sportster.
Manufacturing Location:
United States (Milwaukee, Wisconsin)
đ Awards & Recognition
Model Specific Awards:
While specific awards for the 2006 model are not prominently cited, the Sportster line has consistently been recognized for its enduring design, customization potential, and cultural impact within the motorcycle community. It's a perennial favorite among riders seeking authentic American V-twin experience.
