🏷️ Basic Information

Make:

Honda

Model:

Insight

Year:

2011

Chassis Code:

ZE2

Engine Code:

LDA (1.3L i-VTEC + IMA)

👋 Introduction

Segment:

Compact Hybrid Sedan

Target Audience:

Fuel-efficient vehicle buyers, DIY mechanics, Honda enthusiasts

Key Competitors:

Toyota Prius, Ford Fusion Hybrid, Chevrolet Malibu Hybrid

Manufacturer Origin:

Licensed from OE (Original Equipment) materials via RepairSurge

Convenience:

Instant online access, replaces cumbersome printed manuals

Cost Effectiveness:

Saves significant costs compared to dealership repairs

📋 Manual Details

Primary Coverage:

2011 Honda Insight (ZE2 Chassis)

Engine Variants Covered:

1.3L i-VTEC with Integrated Motor Assist (IMA) Hybrid System

Estimated Pages:

Extensive (Digital, no fixed page count)

Type:

Official Service and Repair Manual Software

Language:

English

Format:

Online Access (Web Browser)

📖 Manual Coverage

Powertrain:

Engine (i-VTEC), IMA Hybrid System, Transmission, Drivetrain

Chassis:

Suspension, Steering, Brakes, Wheels, Tires

Electrical:

Wiring Diagrams, Lighting, Audio, Power Accessories, Hybrid Battery System

Body And Interior:

Body Panels, Doors, Seats, HVAC System, Interior Trim

Maintenance:

Scheduled Maintenance, Fluid Changes, Filter Replacements, Inspections

Diagnostics:

Troubleshooting Guides, Diagnostic Trouble Codes (DTCs), Fault Finding

Repair:

Component Replacement, Reassembly, Adjustments, System Overhauls

Special Procedures:

Hybrid Battery Service, IMA System Calibration, High-Voltage System Safety Precautions

Depth:

Comprehensive Factory-Level Repair Information

Diagnostics Detail:

Detailed symptom-based diagnostics, schematic interpretation, and component testing

Rebuild Procedures:

Includes detailed procedures for engine and transmission disassembly/reassembly where applicable

📊 Manual Specifications

Access Method:

Internet Browser Accessible

Clarity:

High-resolution diagrams and text

Binding:

N/A (Online Digital)

Paper Type:

N/A (Online Digital)

Text Search:

Fully searchable text content

Device Compatibility:

PC, Laptop, Smartphone, Tablet

Subscription Period:

1 Year (Renewable)

⚙️ Engine Specifications

Engine Type:

Inline 4-Cylinder with Hybrid Assist

Displacement:

1.3 Liters (1339 cc)

Valve Train:

SOHC i-VTEC (16 Valves)

Bore X Stroke:

73.0 mm x 80.0 mm (approx.)

Compression Ratio:

10.8:1 (approx.)

Combined Horsepower:

98 hp @ 5800 rpm (Gasoline Engine + IMA Motor)

Gasoline Engine Horsepower:

88 hp @ 5800 rpm

Ima Motor Horsepower:

13 hp @ 1500 rpm (peak)

Combined Torque:

123 lb-ft @ 2500 rpm (Gasoline Engine + IMA Motor)

Gasoline Engine Torque:

88 lb-ft @ 2500 rpm

Ima Motor Torque:

104 lb-ft @ 1500 rpm (peak)

Fuel Delivery:

Electronic Fuel Injection (PGM-FI)

Fuel Type:

Unleaded Gasoline

Fuel Tank Capacity:

10.6 Gallons (40 Liters)

Hybrid System Name:

Integrated Motor Assist (IMA)

Battery Type:

Nickel-Metal Hydride (Ni-MH)

Motor Type:

Brushless DC Electric Motor

🔧 Transmission

Transmission Type:

Continuously Variable Transmission (CVT) with Integrated Motor

Optional Transmission:

N/A

Hybrid Integration:

Motor is integrated into the transmission housing, acting as a generator and electric motor

Transmission Fluid Specification:

Honda HCF-2 (Check manual for exact application)

📐 Dimensions

Length:

170.5 inches (4330 mm)

Width:

67.0 inches (1702 mm)

Height:

57.3 inches (1455 mm)

Wheelbase:

103.2 inches (2620 mm)

Front Track:

58.7 inches (1490 mm)

Rear Track:

58.5 inches (1485 mm)

Ground Clearance:

5.0 inches (127 mm)

Cargo Volume:

12.4 cu ft (351 Liters)

Curb Weight:

2,952 lbs (1339 kg)

Gross Vehicle Weight Rating Gvwr:

3,897 lbs (1768 kg)

🛡️ Safety Features

NHTSA Front Crash Test Rating:

5-Star (Driver), 5-Star (Passenger)

NHTSA Side Crash Test Rating:

5-Star (Driver), 5-Star (Passenger)

NHTSA Rollover Rating:

4-Star

IIHS Front Crash Rating:

Good

IIHS Side Crash Rating:

Good

IIHS Roof Strength Rating:

Good

ABS:

Standard

Electronic Stability Control:

Standard (VSA - Vehicle Stability Assist)

Traction Control:

Standard

Brake Assist:

Standard

Airbags:

Dual front, front side, side curtain airbags

Seatbelts:

3-point seatbelts with pretensioners and load limiters

Child Seat Anchors:

LATCH system

💡 Technology Features

Audio System:

Standard AM/FM/CD player with 4 speakers; optional upgrades available with more speakers and display screens.

Connectivity:

Optional Bluetooth HandsFreeLink, USB audio interface

Cruise Control:

Standard

Eco Mode:

Engages an 'ECON' mode to optimize engine and transmission operation for better fuel efficiency.

Automatic Engine Shutoff:

Engine automatically shuts off when stopped (e.g., at traffic lights) to conserve fuel.

Regenerative Braking:

Captures kinetic energy during deceleration to recharge the IMA battery.

🔧 Maintenance

Oil Change Interval:

5,000 miles or 6 months (whichever comes first), or per Maintenance Minder system

Air Filter Replacement:

Check per Maintenance Minder system, typically 15,000-30,000 miles

Spark Plug Replacement:

Refer to manual, typically around 100,000 miles for iridium-tipped plugs

Brake Fluid Replacement:

Every 3 years (unlimited mileage)

Transmission Fluid Replacement:

Check per Maintenance Minder system or every 60,000-100,000 miles depending on usage

Engine Oil Type:

0W-20 Synthetic Motor Oil (API Certified)

Engine Oil Capacity:

3.9 US Quarts (3.7 Liters) with filter change

Coolant Type:

Honda Genuine All Season Antifreeze/Coolant Type 2 (Blue)

Coolant Capacity:

Approx. 1.2 US Gallons (4.5 Liters)

Hybrid Battery Degradation:

As with many hybrids of this era, hybrid battery degradation can occur over time, leading to reduced electric assist and fuel economy. The manual details diagnostic procedures for the IMA system.

Cvt Hesitation:

Some owners have reported occasional CVT hesitation. Proper fluid maintenance and diagnostic checks are crucial.

HVAC System Issues:

Occasional issues with HVAC blower motors or climate control units. The manual provides diagnostic trees for these components.

📚 Vehicle History

Honda History:

Founded in 1948, Honda is renowned for its engineering excellence, reliability, and innovation in automotive and powersports.

Insight First Generation:

The first-generation Insight (1999-2006) was a groundbreaking two-seater hybrid, notable for its aerodynamic design and exceptional fuel economy.

Insight Second Generation:

The second-generation Insight (2009-2014) marked a significant shift, becoming a more conventional four-door hatchback, targeting a broader market with its hybrid technology.

2011 Insight Updates:

The 2011 model received minor updates, primarily in trim levels and features, refining its position in the hybrid market.

Production Location:

Suzuka Factory, Japan

🏆 Awards & Recognition

Fuel Economy Rating:

EPA estimated 51 MPG city / 48 MPG highway / 50 MPG combined (for 2011 models), making it one of the most fuel-efficient vehicles of its time.

Green Car Awards:

Frequently cited for its environmental friendliness and fuel efficiency.
