Positioning:
A critical resource for owners and mechanics of the Isuzu TF/Holden Rodeo RA, known for its robustness and versatility as a light commercial vehicle and lifestyle utility.
Competitors:
Competed against vehicles like the Toyota Hilux, Mitsubishi Triton, Ford Ranger, and Nissan Navara during its production run.
Features:
Off-road capability (4x4 models), durable construction, spacious cabins (Dual Cab), variety of powertrains, popular in commercial and recreational sectors.
Value Proposition:
Provides authorized procedures, specifications, and diagnostic information directly from the manufacturer, ensuring accuracy and effectiveness for maintenance and repairs.
Regions Covered:
Global (LHD and RHD configurations documented)
Body Styles:
Single Cab, Dual Cab, Space Cab (Crew Cab, Extra Cab)
Drivetrain Configurations:
4x2 (RWD), 4x4 (4WD)
Estimated Page Count:
Extensive (exact count not specified, but typical for full factory manual)
Type:
Factory Workshop Manual / Service Manual / Repair Manual
Powertrain:
Engine (Diesel, Turbo Diesel, Petrol V6, Petrol 4-cyl), Manual Transmissions (MSG, MUA), Automatic Transmissions (AW30-40LE, JR405E), Clutch, Transfer Case
Chassis And Suspension:
Frame, Cab Structure, Steering System, Suspension (Front and Rear), Wheels, Tires, Axles (Front and Rear)
Brakes:
Hydraulic Brake System (including ABS if equipped), Parking Brake
Electrical And Body:
Body Electrical Systems, Chassis Electrical Systems, Lighting, Instrumentation, Wiring Diagrams, Body Panels, Doors, Seats, Interior Trim
Comfort And Safety:
Heating and Air Conditioning (HVAC), Restraint Systems (Airbags, Seatbelts), Security Systems
Maintenance And Servicing:
Scheduled maintenance procedures, fluid changes, filter replacements, lubrication
Diagnostics And Troubleshooting:
Fault finding, diagnostic codes (OBD-II for petrol, specific for diesel), symptom-based troubleshooting
Repair And Rebuild:
Component removal and installation, engine overhaul, transmission rebuild, suspension repair, brake system overhaul
Technical Specifications:
Torque specifications, clearances, alignment data, electrical schematics, component tolerances
Depth:
Comprehensive factory-level detail, suitable for professional technicians and advanced DIY enthusiasts
Engine Code:
4JA1 / 4JH1-TC (3.0L Diesel / Turbo Diesel)
Configuration:
Inline 4-cylinder, Direct Injection, Turbocharged Intercooled (4JH1-TC)
Engine Code:
6VE1 (3.5L V6)
Configuration:
V-type, 60-degree bank angle, SOHC or DOHC (depending on specific variant)
Secondary Engine Petrol 4Cyl
Engine Code:
C24SE (2.4L Petrol)
Configuration:
Inline 4-cylinder, DOHC
Petrol Injection:
Multi-point Fuel Injection (MPI)
Diesel Injection:
Common Rail Direct Injection (CRDI) for 4JH1-TC
General:
Varies by body style (Single, Dual, Space Cab), overall length, width, and height are critical for identification and workshop procedures.
Gross Vehicle Weight Rating:
Varies by configuration and payload, specified in manual.
Curb Weight:
Varies by configuration and engine, specified in manual.
Australian Ancap:
3-star rating for some RA Rodeo variants (e.g., 2006 model). Specific ratings should be cross-referenced.
Braking:
Available ABS (Anti-lock Braking System) on certain models.
Restraints:
Driver and passenger airbags (standard on most later models), seatbelt pretensioners.
Audio Systems:
Factory fitted radio/cassette or CD players, basic speaker systems. Manual covers wiring and diagnostics for these.
Braking Systems:
ABS availability on higher trims or specific models.
Wiring Diagrams:
Extensive electrical diagrams for all vehicle systems, crucial for diagnosing any electrical faults or aftermarket installations.
Oil Change Petrol:
Typically 10,000 km or 6 months, refer to manual for precise intervals based on driving conditions.
Oil Change Diesel:
Typically 5,000 km or 6 months for older diesels, up to 10,000 km or 12 months for common rail diesels. Crucial to follow manual recommendations.
Engine Oil Petrol:
API SG/SH/SJ or ACEA A2/A3, viscosity typically 10W-30 or 10W-40. Manual will specify exact grade.
Engine Oil Diesel:
API CF/CF-4 or ACEA B3/B4, viscosity typically 10W-30 or 15W-40. Manual crucial for correct specification.
Transmission Fluid Manual:
API GL-4 or GL-5, specific viscosity (e.g., 75W-90). Check manual for exact type.
Transmission Fluid Automatic:
Dexron III or equivalent for AW30-40LE, Dexron II or equivalent for JR405E. Manual is definitive.
Coolant:
Ethylene glycol-based antifreeze, mixed 50/50 with distilled water. Specific color or type may be recommended.
Common Problems:
Potential for injector pump issues on early diesel models, timing chain wear on V6 petrol engines, rust in common areas (wheel arches, chassis rails), clutch wear. Manual helps diagnose and repair.
Isuzu Trucks And Utilities:
Isuzu has a long-standing reputation for producing robust, reliable commercial vehicles and diesel engines.
Holden Rodeo Ra Lineage:
The RA Rodeo built upon the legacy of the Isuzu TF platform, offering updated styling, improved interiors, and new powertrain options. It was a significant player in the Australian ute market.
Manufacturing Locations:
Primarily manufactured in Thailand (Isuzu) and assembled in various locations globally, including Australia for Holden badged versions.
