Engine:
Detailed disassembly, assembly, repair, and adjustment procedures for all engine variants, including cylinder head, block, crankshaft, pistons, valves, cooling system, lubrication system, and fuel system.
Transmission:
Comprehensive coverage of manual and automatic transmission systems, including clutch, gearbox, driveshafts, and differentials.
Brakes:
Detailed procedures for front and rear brake systems, including hydraulic components, master cylinder, wheel cylinders, brake shoes/pads, drums/discs, and parking brake.
Electrical:
In-depth electrical system diagnostics and repair, including battery, charging system (generator), ignition system, lighting, starting system, gauges, and wiring diagrams.
Suspension Steering:
Complete information on front and rear suspension systems, shock absorbers, springs, steering box, linkages, and wheel alignment specifications.
Bodywork Chassis:
Procedures for body panel removal and installation, chassis frame inspection and repair, doors, windows, interior trim, and bumpers.
Cooling System:
Detailed instructions for radiator, water pump, thermostat, hoses, and fan assembly maintenance and repair.
Fuel System:
Coverage of fuel tank, fuel lines, fuel pump, carburettors (including SU carburetors), and related components.
Exhaust System:
Information on exhaust manifold, pipes, muffler, and heat shields.
HVAC:
While limited for this era, may cover heater core and associated ducting.
Maintenance:
Comprehensive periodic maintenance schedules, fluid level checks, lubrication points, and filter replacement procedures.
Troubleshooting:
Systematic diagnostic procedures for common and uncommon problems, with symptom-based troubleshooting guides.
Repair:
Detailed, step-by-step instructions for component removal, repair, installation, and adjustment, including overhaul procedures.
Diagnostics:
Diagnostic flowcharts, testing procedures, and interpretation of results for various vehicle systems.
Adjustments:
Precise instructions for adjustments such as carburetor tuning, ignition timing, valve clearance, brake adjustment, and steering geometry.
Specifications:
Inclusion of critical service data, including torque specifications, clearances, fluid capacities, and wear limits.
Special Tools:
Identification and usage instructions for required special service tools for specific repair operations.
Depth:
Extremely detailed, bumper-to-bumper coverage suitable for professional mechanics and dedicated DIY enthusiasts. Includes complete engine rebuilds, transmission overhauls, and in-depth electrical diagnostics.
Quality:
High-resolution PDF, ensuring clarity of text and illustrations.
Printable:
Yes, all 978 pages are printable for convenient workshop use.
Binding Style:
Digital (PDF), allowing for immediate access and flexible viewing.
Operating Systems:
Compatible with Windows, Mac, and Linux operating systems via Adobe Reader.
Software:
Adobe Reader (or compatible PDF viewer) required for access.
Oil Change:
Recommended every 3,000 miles or 6 months; detailed in manual.
Grease Points:
Regular lubrication of various chassis points is critical and detailed in the manual.
Engine Oil:
SAE 20W/50 or 20W/60 depending on climate. Manual specifies correct grades and capacities.
Coolant:
Ethylene glycol based antifreeze mixed with distilled water (50/50 ratio). Capacity approximately 13 pints.
Brake Fluid:
DOT 3 or DOT 4 glycol-based brake fluid. Manual specifies type and capacity.
Transmission Oil Manual:
Gear oil SAE 90 (EP). Manual specifies exact type and capacity for Moss gearbox.
Transmission Oil Automatic:
Dexron-III or equivalent automatic transmission fluid (ATF). Manual specifies type and capacity.
Differential Oil:
EP (Extreme Pressure) Gear Oil SAE 90. Manual specifies capacity.
Common Problems:
Rust in sills and wheel arches, wear in steering components, carburetor tuning challenges, occasional gearbox synchromesh issues (Moss gearbox).
Genuine Parts:
Emphasis on using correct, original specification Jaguar parts for reliability and performance.
