Segment:
Compact SUV / Crossover
Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Subaru Forester
Vehicle Identity:
Offers Jeep's characteristic rugged styling and optional Freedom Drive II 4x4 system for enhanced off-road capability within the compact SUV segment.
Manual Purpose:
Empowers owners and technicians with factory-level diagnostic, repair, and maintenance information.
Primary Coverage:
All repairs, servicing, and troubleshooting procedures
Page Count Estimate:
Hundreds of pages (specific count not provided, but described as 'very detailed')
Type:
Factory Service & Repair Workshop Manual
Powertrain:
Engine mechanicals, fuel system, ignition system, exhaust system, cooling system, lubrication system
Drivetrain:
Transmission (manual & automatic), clutch, axles, driveshafts, differentials, 4WD system
Chassis:
Suspension (front & rear), steering system, brake system (hydraulic, ABS, parking brake)
Electrical:
Battery, charging system, starting system, lighting, wipers, power windows, power locks, instrument cluster, audio system, HVAC controls, safety systems (airbags, seatbelts)
Body:
Body panels, doors, windows, bumpers, interior trim, glass, seals
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement, brake pad/rotor replacement, tire rotation
Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based diagnostics, component testing, wiring diagrams for fault finding
Repair:
Engine overhaul, transmission rebuilds, suspension component replacement, brake caliper/master cylinder replacement, electrical component repair/replacement, body panel repair
Diagnostics:
Detailed diagnostic procedures for all major systems, including powertrain control module (PCM) and body control module (BCM) related issues
Depth:
Comprehensive, from basic maintenance to complete engine and transmission overhauls, including intricate electrical troubleshooting
Searchability:
Likely searchable text-based PDF (standard for professional manuals)
Printability:
Printable (single pages or entire manual)
Image Quality:
Detailed photos and diagrams (high quality as expected from factory manuals)
Binding:
Digital (PDF Download) - No physical binding
Paper Type:
N/A (Digital Format)
Engine 1:
2.4L World Engine (GEMA)
Engine 1 Code:
GEMA (Global Engine Manufacturing Alliance)
Engine 1 Configuration:
Inline-4 Cylinder
Engine 1 Displacement:
2359 cc (2.4 Liters)
Engine 1 Bore X Stroke:
88 mm x 97 mm
Engine 1 Compression Ratio:
9.5:1
Engine 1 Horsepower:
172 hp @ 6000 rpm
Engine 1 Torque:
165 lb-ft @ 4400 rpm
Fuel Delivery:
Sequential Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline
Valve Train:
DOHC (Dual Overhead Camshafts), 16 valves, Continuously Variable Valve Timing (CVVT)
Engine 2:
2.0L World Engine (GEMA) - Available in some markets
Engine 2 Displacement:
1998 cc (2.0 Liters)
Engine 2 Horsepower:
158 hp @ 6300 rpm
Engine 2 Torque:
141 lb-ft @ 5000 rpm
Transmission Std:
5-Speed Manual Transmission
Transmission Opt:
Continuously Variable Transmission (CVT) - Market dependent
Cvt Features:
Electronically controlled, simulated gear shifts (on some models), AutoStick functionality
Manual Trans Fluid:
Refer to manual for specific fluid type and capacity (e.g., Mopar Manual Transmission Lubricant or equivalent API GL-4 SAE 75W-80)
Cvt Fluid:
Refer to manual for specific CVT fluid type and capacity (e.g., Mopar CVT Fluid or equivalent)
NHTSA Front Crash:
5 Stars (Driver and Passenger)
IIHS Front Overlap:
Good (for models with side airbags)
Airbags:
Frontal airbags, front side-impact airbags, available side curtain airbags
Seatbelts:
3-point front and rear seatbelts, pretensioners, load limiters
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Traction Control System (TCS)
Electronic Stability:
Electronic Stability Control (ESC) - Standard on later models or optional
Audio Options:
Base AM/FM/CD audio system, optional Boston Acoustics premium sound system, available Uconnect infotainment with Bluetooth and voice command (later models).
Esc:
Electronic Stability Control (ESC)
Traction Control:
Traction Control System (TCS)
Uconnect Availability:
Optional Uconnect system with hands-free calling and USB connectivity on later models.
Oil Change Interval:
Refer to manual; typically every 5,000 to 7,500 miles or 6-12 months depending on driving conditions and oil type used.
Tire Rotation Interval:
Every 5,000 to 7,500 miles
Engine Air Filter:
Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles or sooner if dirty.
Cabin Air Filter:
Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles or sooner if dirty.
Spark Plugs:
Refer to manual for specific type and interval (e.g., for the 2.4L World Engine, typically iridium spark plugs with a longer interval).
Engine Oil Type:
Refer to manual; typically SAE 5W-20 Synthetic Blend or Full Synthetic
Engine Oil Capacity:
Refer to manual for specific capacity (approx. 4.5 quarts for 2.4L)
Coolant Type:
Refer to manual; typically Mopar Antifreeze/Coolant (HOAT) 50/50 mix
Brake Fluid Type:
Refer to manual; typically DOT 3
Cvt Issues:
Some CVT models experienced issues with juddering, delayed engagement, or failure, often related to fluid degradation or internal component wear. Regular fluid changes are critical.
Engine Mounts:
Premature wear or failure of engine mounts, leading to increased vibration and noise.
Throttle Body:
Sticking or faulty electronic throttle body can cause idle issues or poor performance.
Wiper Motor:
Failure of the front or rear wiper motor.
Climate Control:
Issues with HVAC blower motor or blend door actuators.
Brand Identity:
Jeep, a division of Chrysler (later FCA, now Stellantis), known for its off-road capability and iconic SUV heritage.
Jeep Patriot Intro:
The Jeep Patriot was introduced in 2007 as a compact crossover SUV, sharing its platform with the Jeep Compass and Dodge Caliber.
Design Philosophy:
Designed to offer a more affordable and practical entry into the Jeep brand, with a focus on distinctive Jeep styling and some degree of off-road prowess.
Production Location:
Belvidere Assembly Plant, Illinois, USA
