2010-2013 Kawasaki KRF750N P R S V Teryx 750 4X4 Service Repair Manual Instant Download (2010 2011 2012 2013) PDF
Prix habituel
$16.99
Prix soldé
$16.99
Prix habituel
Prix unitaire
/ par
Vente
Épuisé
The Kawasaki Teryx 750 4X4, model designation KRF750, represents a robust and capable side-by-side utility vehicle designed for recreational riders, hunters, farmers, and utility users. Covering model years 2010 through...
The Kawasaki Teryx 750 4X4, model designation KRF750, represents a robust and capable side-by-side utility vehicle designed for recreational riders, hunters, farmers, and utility users. Covering model years 2010 through 2013, this generation 2 model is equipped with a powerful liquid-cooled, 4-stroke, 749cc V-twin engine featuring electronic fuel injection and a selectable 2WD/4WD shaft drive system with a locking front differential. Notable features include its durable chassis, robust suspension, and a cargo bed with a 350 lbs capacity and 1,250 lbs towing capacity, all engineered for reliable off-road performance.
This comprehensive English-language service repair manual provides detailed instructions for the service, repair, and maintenance of the Kawasaki Teryx 750 4X4. It covers all essential systems, including the powertrain, chassis, electrical components, fuel, and cooling systems. The manual offers step-by-step repair procedures, disassembly and reassembly guidance, and diagnostic information to assist owners and technicians in performing maintenance and troubleshooting effectively. Its format ensures clarity and accessibility, allowing users to zoom for detailed views and quickly locate necessary information for optimal vehicle upkeep and longevity.
Step-by-step repair instructions for all covered systems
Troubleshooting:
Implicitly covered through detailed repair procedures and diagnostic information
Disassembly Assembly:
Engine Removal/Installation, Component Disassembly and Reassembly
Technical Depth
Depth:
Comprehensive; covers detailed repair and maintenance procedures suitable for DIY and professional mechanics.
Diagnostic Capability:
Includes information for diagnosing common issues within the covered systems.
📊 Manual Specifications
File Format
File Type:
PDF
Readability:
Zoomable for clarity on computer.
Searchability:
Likely text-searchable PDF for quick information retrieval.
Print Quality
Quality:
Digital (High resolution, allows for clear printing if desired).
Binding Type
Binding:
N/A (Digital download)
Paper Type
Paper:
N/A (Digital download)
Compatibility
Operating Systems:
All Versions of Windows & Mac
Requirements
Software Requirements:
Adobe PDF Reader & WinZip
⚙️ Engine Specifications
Primary Engine
Engine Type:
Liquid-cooled, 4-stroke, V-twin, OHC, 4-valve per cylinder
Displacement:
749 cc (45.7 cu. in.)
Bore X Stroke:
85.0 x 66.0 mm (3.35 x 2.60 in.)
Compression Ratio:
9.8:1
Performance
Horsepower:
Approximately 53 HP (Varies slightly by model year and specific tuning, manual will provide exact figures).
Torque:
Approximately 47.1 lb-ft (Varies slightly by model year, manual will provide exact figures).
Fuel System
Fuel Delivery:
Electronic Fuel Injection (DFI) with two 36mm throttle bodies.
Fuel Type:
Unleaded gasoline, Octane Rating 87 or higher.
Ignition
Ignition System:
TCBI with digital advance
Cooling System
Cooling Method:
Liquid-cooled
Lubrication System
Oil Type:
SAE 10W-40 API SG or SH, JASO MA, Manual will specify exact Kawasaki oil grades.
Oil Capacity:
Refer to manual for precise capacity with filter change.
🔧 Transmission
Standard
Type:
CVT (Continuously Variable Transmission) with high/low range and reverse.
Features
Drive System:
Shaft Drive, Selectable 2WD/4WD with locking front differential.
Fluid Type
Cvt Fluid:
Kawasaki Genuine CVT Fluid or equivalent DEXRON III (Refer to manual for exact specification).
📐 Dimensions
Exterior
Overall Length:
Approx. 116.5 in. (2960 mm)
Overall Width:
Approx. 58.3 in. (1480 mm)
Overall Height:
Approx. 75.5 in. (1918 mm)
Wheelbase:
Approx. 80.5 in. (2045 mm)
Weights
Curb Weight:
Approx. 612.9 lbs (278 kg) to 630.7 lbs (286 kg) depending on exact trim and features. Manual will have precise figures.
Cargo
Cargo Bed Capacity:
Approx. 8.8 cu ft (249 L) / 350 lbs (159 kg) capacity.
Towing Capacity:
Approx. 1,250 lbs (567 kg).
🛡️ Safety Features
Ratings
Safety Standards:
Designed to meet ANSI/ROHVA standards for Side-by-Side Recreational Off-Highway Vehicles. Manual will detail specific safety features and operational guidelines.
Active Features
Braking System:
Hydraulic disc brakes (front and rear). Specifics on caliper type and rotor size detailed in manual.
Basic instrument cluster with speedometer, odometer, trip meter, fuel gauge, clock, and indicator lights. No advanced infotainment system typical of modern cars.
Driver Assistance
Power Steering:
Electric Power Steering (EPS) available on select trims (P, R, S, V models), reducing steering effort, especially at low speeds and over rough terrain. Manual details calibration and troubleshooting for EPS.
Connectivity
Features:
N/A - Primarily mechanical and electrical systems for vehicle operation.
🔧 Maintenance
Service Intervals
Initial Service:
First service typically at 600 miles (1000 km) or 6 months. Manual will specify exact break-in procedures.
Engine Oil Change:
Every 1,200 miles (2,000 km) or 6 months. Manual will detail specific intervals based on usage.
Air Filter Cleaning:
More frequently if operating in dusty conditions. Periodic inspection and cleaning recommended every 600 miles (1000 km).
Spark Plug Replacement:
Refer to manual for specific mileage, typically around 7,500 miles (12,000 km).
Fluid Specifications
Coolant Type:
Kawasaki Motorcycle Antifreeze (or equivalent ethylene glycol-based coolant with corrosion inhibitors). Manual will specify ratio and type.
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid. Manual will specify exact type and bleeding procedures.
Gear Oil Type:
Kawasaki Hypoid Gear Oil GL-5 or equivalent. Manual will detail specific viscosity and capacity for final drive and transmission.
Known Issues
Common Wear Items:
CVT belt wear, suspension bushings, wheel bearings (depending on usage and maintenance).
Potential Problems:
As with many off-road vehicles, proper fluid maintenance and component inspection are crucial to prevent premature wear. The manual will address common diagnostic checks.
📚 Vehicle History
Brand Heritage
Manufacturer:
Kawasaki Heavy Industries Motorcycle & Engine Company.
Model Evolution
First Generation:
Introduced in 2008 as the KRF750A/B Teryx, featuring a V-twin engine and robust chassis.
Updates For 2010:
The 2010 model year introduced significant updates including improved styling, a tighter turning radius, a new electric power steering (EPS) option on certain models (R, S, V trims), and revised suspension tuning.
Production
Manufacturing Location:
Likely assembled in the USA (Kawasaki Motors Manufacturing Corp., U.S.A.) or Japan. Manual may contain specific factory codes.
🏆 Awards & Recognition
Recognitions
Awards:
Specific awards are not readily available for this model, but the Teryx series is generally well-regarded for its robust construction and off-road capability.
