Model:
Teryx 750 FI 4x4 LE Sport
Product Name:
2009-2010 Kawasaki Teryx 750 FI 4x4 LE Sport KRF750RAF ATV Workshop Service Repair Manual Download
Chassis Codes:
KRF750NAF, KRF750PAF, KRF750RAF, KRF750SAF, KRF750SAFA, KRF750TAF
Target Audience:
Owners of 2009-2010 Kawasaki Teryx 750 FI 4x4 LE Sport ATVs seeking to perform maintenance, repairs, and diagnostics.
Vehicle Segment:
Recreational Off-Highway Vehicle (ROV) / Utility-Task Vehicle (UTV) / Side-by-Side (SxS).
Value Proposition:
Provides comprehensive factory-level service information, enabling owners to save money on labor costs and understand their vehicle better. Offers instant access, eliminating shipping delays.
Manual Features:
High-quality diagrams, detailed instructions, step-by-step repair procedures, troubleshooting guides, maintenance schedules.
Engine Systems:
General Information, Fuel System (DFI), Cooling System, Engine Top End, Engine Lubrication System, Engine Removal/Installation, Crankshaft/Transmission
Drivetrain Systems:
Converter System, Crankshaft/ Transmission
Chassis Systems:
Wheels/Tires, Brakes, Suspension, Steering, Frame
Electrical Systems:
Electrical System
Auxiliary Systems:
Appendix
Additional Systems:
General Information, Periodic Maintenance, Fuel System (DFI), Cooling System, Engine Top End, Converter System, Engine Lubrication System, Engine Removal/Installation, Crankshaft/Transmission, Wheels/Tires, Brakes, Suspension, Steering, Frame, Electrical System, Appendix.
Maintenance Procedures:
Periodic Maintenance, Fluid Changes, Filter Replacements, Inspection Procedures
Repair Procedures:
Engine Rebuild, Transmission Overhaul, Suspension Overhaul, Brake Service, Steering System Repair, Electrical Component Diagnosis and Repair
Diagnostic Procedures:
Troubleshooting Guides, Fault Code Diagnosis (DFI), Electrical Schematics
Additional Procedures:
Detailed diagnostic procedures for the DFI system, torque specifications for all fasteners, component disassembly and reassembly instructions, wiring diagrams, troubleshooting flowcharts.
Depth Of Coverage:
Comprehensive; suitable for DIY enthusiasts and professional technicians alike. Covers routine maintenance to complete engine and component overhauls.
Manual Scope:
This manual provides a comprehensive guide covering every aspect of the vehicle, from basic adjustments to complete overhauls. It includes factory specifications and procedures necessary for accurate and efficient servicing.
Print Quality:
High quality; designed for printing. All pages are printable.
Searchable:
Likely searchable within PDF reader, depending on original document quality.
File Organization:
Likely organized into chapters and sections for easy navigation, potentially with a searchable index within the PDF.
Binding Type:
N/A (Digital Download - PDF)
Paper Type:
N/A (Digital Download - PDF)
Software Requirements:
Adobe PDF Reader
Operating Systems:
Compatible with all versions of Windows & Mac
Engine Type:
V-twin, 4-stroke, SOHC, 4-valve cylinder head, liquid-cooled
Displacement:
749 cc (45.7 cu in)
Bore X Stroke:
85.0 x 66.0 mm (3.35 x 2.60 in)
Horsepower:
Approximately 50-55 HP (est. at crankshaft, actual may vary)
Torque:
Approximately 45-50 lb-ft (est. at crankshaft, actual may vary)
Fuel Delivery:
Digital Fuel Injection (DFI) with dual 34mm throttle bodies
Fuel Type:
Unleaded gasoline, 87 octane or higher recommended
Fuel Pump Type:
Electric fuel pump
Ignition System:
Digital CDI
Lubrication System:
Forced lubrication, wet sump
Cooling Method:
Liquid-cooled
Starting System:
Electric starter
Valve Adjustment:
Hydraulic valve adjusters (shim-under-bucket, requiring occasional inspection and adjustment as per manual schedule).
Transmission Type:
Continuously Variable Transmission (CVT) with High/Low range and Reverse
Drive System:
Shaft drive, selectable 4-wheel drive with locking front differential
Differential Lock:
2WD/4WD system with a variable assist 4WD system and a fully locking front differential.
Cvt Fluid Type:
Kawasaki Genuine CVT Fluid (or equivalent specified in manual)
Final Drive Fluid Type:
Kawasaki Genuine Hypoid Gear Oil (SAE 80W-90 recommended for front and rear differentials)
Overall Length:
Approx. 115.2 in (2925 mm)
Overall Width:
Approx. 58.1 in (1475 mm)
Overall Height:
Approx. 75.8 in (1925 mm)
Wheelbase:
Approx. 85.8 in (2180 mm)
Curb Weight:
Approx. 651.5 lbs (295.5 kg)
Cargo Bed Capacity:
Approx. 350 lbs (159 kg)
Towing Capacity:
Approx. 1250 lbs (567 kg)
Infotainment Features:
Not applicable; this is a utility/sport ATV focused on performance and off-road capability. Typically includes basic instrumentation (speedometer, odometer, fuel gauge, warning lights).
Driver Assistance Features:
Selectable 4WD with locking front differential provides enhanced traction control in difficult terrain.
Connectivity Features:
Not applicable.
Initial Service:
First service typically recommended around 100-200 miles or 1 month (refer to manual for specifics).
Engine Oil Change:
Every 600 miles or 6 months, or more frequently under severe use (refer to manual).
Air Filter Cleaning:
Check and clean every 300 miles or 3 months, replace as needed (more often in dusty conditions).
Spark Plug Replacement:
Recommended replacement every 3000-4000 miles or per manual recommendations.
Engine Oil Specification:
SAE 10W-40 API SG or higher (Kawasaki Genuine 4-stroke Engine Oil recommended).
Engine Oil Capacity:
Approx. 2.2 US qt (2.1 L) without filter change, 2.4 US qt (2.3 L) with filter change (refer to manual for exact capacity).
Coolant Type:
Permanent type antifreeze coolant, 50/50 mix with distilled water (Kawasaki Genuine Coolant recommended).
Common Wear Items:
CVT belt wear, brake pad wear, suspension bushings, wheel bearings.
DFI System Considerations:
While generally reliable, maintaining clean fuel injectors and checking for proper air intake sealing is crucial for optimal DFI performance.
Kawasaki Atv Legacy:
Kawasaki has a long-standing history in the powersports industry, known for durable and high-performance off-road vehicles, including the Mule utility vehicle and various ATV lines.
Teryx Development:
The Teryx line was developed to compete in the sport-utility side-by-side (SxS) market, offering a blend of utility and performance features. The 750 FI model represented a significant advancement with its fuel injection system for improved throttle response and efficiency.
