🏷️ Basic Information

Make:

Lancia

Model:

Zeta

Year:

2002

Engine Variant:

2.0i 16V

Body Style:

MPV (Multi-Purpose Vehicle)

Generation Designation:

First Generation (Type 179)

Engine Code Common Designation:

Likely based on Fiat/PSA XU or EW family engines, specifically the 2.0 16V variant

👋 Introduction

Market Segment:

Compact MPV (Multi-Purpose Vehicle)

Key Selling Points:

Versatile interior, family-oriented practicality, comfortable ride.

Key Competitors:

Citroën Évasion, Peugeot 806, Fiat Ulysse, Renault Espace.

Platform Sharing:

Developed as part of a joint venture with PSA Peugeot Citroën, sharing its platform with the Citroën Evasion and Peugeot 806, and Fiat Ulysse.

Body Construction:

Monocoque chassis with galvanized steel body panels.

Interior Versatility:

Modular seating arrangements, sliding rear doors for easy access, often featuring up to seven seats.

📋 Manual Details

Geographic Coverage:

Primarily European market, with technical information applicable to global markets where the Lancia Zeta was sold.

Estimated Page Count:

Detailed information not provided, but factory service manuals of this era typically range from 500 to 1500 pages.

Manual Type:

Factory Service and Repair Workshop Manual

Language:

English

Digital Format:

PDF

📖 Manual Coverage

Powertrain:

Engine mechanicals, lubrication, cooling, fuel delivery, ignition, exhaust systems, intake manifold, throttle body.

Transmission:

Manual and/or Automatic transmission service, repair, and diagnosis (specific types not detailed in product info).

Chassis And Suspension:

Front and rear suspension components, steering system, wheel alignment, drive axles, brakes (hydraulic, ABS), and wheel/tire specifications.

Electrical System:

Battery, charging system, starting system, lighting, instrumentation, interior and exterior electronics, body control modules, infotainment components (if applicable).

Body And Interior:

Body panels, doors, latches, glass, interior trim, seating systems, climate control system (HVAC), SRS (Supplemental Restraint System) / Airbag systems.

Emission Control:

Emission control systems, diagnosis of related components (e.g., catalytic converter, O2 sensors), EVAP system.

Maintenance:

Regular scheduled maintenance, fluid changes, filter replacements, spark plug replacement, belt inspection/replacement.

Troubleshooting:

Diagnostic procedures for common and uncommon faults, symptom-based troubleshooting guides, error code interpretation.

Repair And Overhaul:

Step-by-step instructions for component removal, installation, overhaul, and repair, including engine disassembly and reassembly.

Wiring And Schematics:

Detailed electrical wiring diagrams for all vehicle systems, component locations, and circuit descriptions.

Diagnostic Capabilities:

Covers basic diagnostic checks to advanced system analysis, enabling identification of faults across all major vehicle systems.

Repair Complexity:

Suitable for DIY enthusiasts performing routine maintenance and minor repairs, as well as professional mechanics undertaking complete overhauls and complex diagnostics.

Information Type:

Includes specifications, procedures, diagrams, troubleshooting charts, and technical advisories.

📊 Manual Specifications

File Format:

PDF

Printability:

Printable without restriction

Diagram Quality:

Top quality diagrams, exploded views, and illustrations.

Binding Type:

Digital Download (PDF), no physical binding.

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Engine Type:

Inline 4-cylinder, DOHC (Double Overhead Camshaft)

Displacement:

1998 cc (2.0 Liters)

Bore X Stroke:

Specific dimensions not provided, but typical for this engine family.

Compression Ratio:

Likely around 10.0:1 to 10.5:1, typical for naturally aspirated 16V engines of this era.

Horsepower Output:

Approximately 132-138 PS (130-136 hp) at around 6000 rpm.

Torque Output:

Approximately 174-182 Nm (128-134 lb-ft) at around 4000 rpm.

Fuel Delivery:

Multi-point fuel injection (MPI) with electronic engine management.

Ignition System:

Electronic ignition with distributorless ignition system (DIS) or coil-on-plug ignition.

Engine Control Unit:

ECU controlled, likely using a Bosch Motronic or similar system.

🔧 Transmission

Standard Transmission:

5-speed manual transmission.

Optional Transmission:

Likely a 4-speed automatic transmission was available as an option.

Transmission Fluid:

Specific fluid type (e.g., Dexron III for automatic) and capacity would be detailed in the manual.

📐 Dimensions

Length:

Approx. 4550 mm (179.1 in)

Width:

Approx. 1800 mm (70.9 in)

Height:

Approx. 1710 mm (67.3 in)

Wheelbase:

Approx. 2820 mm (111.0 in)

Cargo Volume:

Highly variable depending on seating configuration, but typically around 400-600 liters behind the second row, expandable significantly with seats folded.

Curb Weight:

Approximately 1500-1600 kg (3300-3530 lbs), depending on configuration.

🛡️ Safety Features

Euro Ncap Rating:

While specific ratings for the 2002 model year aren't readily available, the platform's earlier versions typically achieved 3-4 stars. The manual would contain details on passive safety systems.

Braking System:

Front ventilated discs, rear solid discs. ABS (Anti-lock Braking System) likely standard or optional.

Traction Control:

TCS (Traction Control System) may have been available as an option.

Airbags:

Frontal airbags for driver and passenger, side airbags likely optional or standard on higher trims.

Seatbelts:

Three-point inertia reel seatbelts with pre-tensioners for front seats. ISOFIX child seat anchor points.

Child Safety:

Rear door child locks, ISOFIX preparation.

💡 Technology Features

Audio System:

Typically featured a factory-installed radio/cassette or radio/CD player with speakers. Manual will detail head unit operation and speaker locations.

Navigation:

Optional satellite navigation systems were available on some models, but not standard.

Cruise Control:

Available as an option on higher trim levels.

Auxiliary Input:

Rare for this model year; typically required aftermarket modifications for audio device connectivity.

🔧 Maintenance

Oil Change Interval:

Typically every 10,000-15,000 km (6,000-9,000 miles) or 12 months, whichever comes first. Specific interval provided in manual.

Timing Belt Replacement:

Crucial interval for the 2.0 16V engine. Typically around 80,000-120,000 km (50,000-75,000 miles) or 5-7 years. The manual will specify the exact interval and related components (tensioners, water pump).

Engine Oil Specification:

Likely API SJ or SL, with viscosity grades such as 10W-40 or 5W-40, depending on climate. Manual will specify exact API and ACEA grades.

Coolant Specification:

Ethylene glycol-based antifreeze/coolant, typically with a 50/50 mix with distilled water. Manual will specify Lancia or industry standard (e.g., G11/G12).

Brake Fluid Specification:

DOT 4 brake fluid is standard for this era. Manual will confirm.

Power Steering Fluid:

Likely a specific hydraulic fluid, potentially ATF (Automatic Transmission Fluid) type if specified by Lancia. Manual will provide exact specification.

Common Electrical Faults:

Corrosion in connectors, failure of window regulators, issues with central locking actuators.

Common Mechanical Issues:

Wear on suspension components (ball joints, wishbones), potential for exhaust system corrosion, occasional issues with the ignition system (coil packs).

Common Engine Issues:

If the timing belt is not replaced at intervals, catastrophic engine damage can occur. Other potential issues include oil leaks from seals and gaskets.

Climate Control Issues:

Leaking heater matrix, faulty blower motor resistors, or refrigerant leaks in the A/C system.

📚 Vehicle History

Lancia Identity:

Lancia is an Italian automotive manufacturer with a long history of producing sophisticated and often innovative vehicles, known for their comfort and design.

Zeta Development:

The Lancia Zeta was part of a collaborative project with PSA Peugeot Citroën, leading to badge-engineered variants like the Peugeot 806 and Citroën Évasion. This allowed for shared development costs and manufacturing.

Production Period:

The Lancia Zeta was produced from 1995 to 2002.

Manufacturing Location:

Likely manufactured at the Sevel (Société Européenne de Véhicules Légers) plant in France, which produced the platform variants.

🏆 Awards & Recognition

Industry Awards:

While the Zeta itself didn't win specific major awards, its platform siblings (Peugeot 806, Citroën Evasion) were well-regarded in the MPV segment of their time.

Reliability Perception:

Reliability perception of vehicles from this era, especially those with French parentage, can vary. This manual is crucial for maintaining the vehicle effectively.

Emissions Certification:

Compliant with European emission standards for the year 2002 (likely Euro 3).
