🏷️ Basic Information

Make:

Land Rover

Model:

Range Rover Sport

Generation:

First Generation (L320)

Model Years Covered:

2005-2012

Chassis Code:

L320

Vin Code Prefix:

SAL (South Africa)

👋 Introduction

Vehicle Segment:

Luxury Mid-Size SUV

Target Audience:

Buyers seeking a blend of off-road capability and on-road refinement, often associated with luxury and performance.

Key Competitors:

BMW X5, Mercedes-Benz ML-Class, Porsche Cayenne, Audi Q7

Off Road Capability:

Renowned Land Rover Terrain Response system, robust chassis, and advanced four-wheel-drive components.

On Road Performance:

Comfortable ride, refined interior, powerful engine options, and sophisticated suspension systems.

Design Language:

Distinctive Range Rover styling cues with a sportier, more dynamic profile.

Cost Savings:

Potential to save significant money on maintenance and repair by enabling DIY tasks and informed mechanic interactions.

Comprehensiveness:

Covers a vast array of systems and procedures, making it the most comprehensive resource available for this vehicle.

📋 Manual Details

General Maintenance:

Included

Engine Repair:

Included

Driveline Service:

Included

Suspension And Steering:

Included

Brake System:

Included

Electrical Systems:

Included

Climate Control:

Included

Infotainment And Navigation:

Included

Bodywork And Chassis:

Included

Total Pages:

5500+

Type:

Official Workshop Service Manual

Intended User:

Land Rover Technicians and Owners

Primary Language:

English

Digital Format:

PDF

Platform Compatibility:

Windows and macOS

Required Software:

Adobe Acrobat Reader

📖 Manual Coverage

Engine Systems:

Engine General, Cooling System, Supercharger Cooling, Fuel Charging & Controls, Accessory Drive, Starting System, Engine Ignition, Glow Plug System, Emission Control, Intake Air Filtering & Distribution, Evaporative Emissions, Electronic Engine Controls

Transmission And Driveline:

Automatic Transmission Transaxle, Manual Transmission Transaxle, Clutch, Transfer Case, Four Wheel Drive System, Driveshaft, Front Axle/Diff, Rear Axle/Diff, Front Halfshafts, Rear Halfshafts

Chassis And Suspension:

Chassis, Suspension, Wheels & Tyres, Vehicle Dynamic Suspension, Ride & Handling Optimisation

Braking And Steering:

Full Brake System, Front Discs, Rear Discs, Parking Brake & Actuation, Hydraulic Brake, Power Brake, Anti Lock Control, Steering System, Power Steering, Steering Linkage, Steering Column, Steering Column Switches

Electrical And Electronics:

Climate Control System, Air Conditioning, Control Components, Instrumentation & Warning Systems, Horn, Clock, Information & Message Centre, Warning Devices, Engine Protection System, Parking Aid, Battery & Charging System, Generator & Regulator, Information & Entertainment Systems, Lighting (Exterior/Interior), Electrical Distribution, Wiring Harnesses, Anti-Theft System, Navigation, Cellular Phone, Wiring Diagrams

Routine Maintenance:

Oil changes, filter replacements, fluid checks, spark plug service, brake pad inspection/replacement, tire rotation.

Diagnostic Troubleshooting:

Step-by-step troubleshooting guides for common and uncommon issues across all major systems.

Component Repair And Rebuild:

Detailed instructions for engine, transmission, differential, suspension, brake caliper, and steering rack repairs or rebuilds.

Electrical System Repair:

Wiring diagrams, component testing, diagnosis of electrical faults, repair of lighting, communication, and control modules.

HVAC System Service:

Refrigerant charging, leak detection, blower motor replacement, control panel diagnosis.

Safety System Checks:

ABS, traction control, and stability control system diagnostics.

Diagnostic Capability:

Advanced diagnostics with detailed component testing procedures and expected values.

Mechanical Repair:

Comprehensive rebuild procedures for major mechanical components like engines and transmissions.

Electrical Schematics:

Full, detailed wiring diagrams for all vehicle systems.

Special Tools:

Identification and usage instructions for specialized tools required for specific repairs.

📊 Manual Specifications

PDF Quality:

High-resolution, searchable text

Printability:

Printable pages for physical reference

Physical Manual:

Not Applicable (Digital PDF)

Physical Manual:

Not Applicable (Digital PDF)

⚙️ Engine Specifications

Engine Type 1:

4.4L V8 (Naturally Aspirated/Supercharged)

Engine Type 2:

4.2L V8 Supercharged (AJ-V8 Gen III)

Engine Type 3:

3.6L V8 TD (TDV8)

Engine Type 4:

2.7L V6 TD (TDV6)

Engine Type 5:

3.0L V6 TD (SDV6) - Later Models

Horsepower Approx:

390 hp (4.2L), 510 hp (4.4L Supercharged)

Torque Approx:

410 lb-ft (4.2L), 461 lb-ft (4.4L Supercharged)

Horsepower Approx:

272 hp

Torque Approx:

472 lb-ft

Horsepower Approx:

190 hp (2.7L), 240 hp (3.0L)

Torque Approx:

325 lb-ft (2.7L), 390 lb-ft (3.0L)

Induction Type Petrol:

Naturally Aspirated and Supercharged

Induction Type Diesel:

Turbocharged Direct Injection (Common Rail)

🔧 Transmission

Type:

6-Speed Automatic (ZF 6HP26)

Type:

6-Speed Manual (for some early TDV6 models, less common)

Drivetrain:

Permanent Four-Wheel Drive (4WD)

Transfer Case:

Two-speed electronic transfer case with Terrain Response

Automatic Transmission Fluid:

TF-0871 (e.g., ZF LifeguardFluid 6)

📐 Dimensions

Approx:

4783 mm (188.3 in)

Approx:

1915 mm (75.4 in) (excluding mirrors)

Approx:

1784 mm (70.2 in)

Approx:

2745 mm (108.1 in)

Curb Weight Range:

Approx. 2100-2400 kg (4630-5291 lbs) depending on engine and configuration

Rear Seats Up:

Approx. 878 liters (31.0 cu ft)

Rear Seats Down:

Approx. 1800 liters (63.6 cu ft)

🛡️ Safety Features

NHTSA Front Crash Test:

4-star (for driver and passenger, from earlier testing periods)

IIHS Front Overlap Crash Test:

Good (for models tested with appropriate updates)

Traction Control:

Standard

Electronic Stability Control:

Standard

Anti-Lock Braking System:

Standard

Terrain Response:

Standard (Adjusts powertrain, suspension, and electronic aids for various terrains)

Airbags:

Front, side, curtain airbags

Seatbelts:

Pre-tensioning front seatbelts

💡 Technology Features

Features:

Touchscreen interface, premium audio systems (Harman Kardon, Meridian on later models), navigation, Bluetooth connectivity, auxiliary inputs.

Features:

Parking sensors (front and rear), rearview camera, adaptive cruise control (optional), blind-spot monitoring (optional on later models).

Features:

Integrated phone systems, USB and auxiliary ports for media playback.

🔧 Maintenance

Oil And Filter Change:

Typically every 10,000-15,000 miles or 12 months, whichever comes first (refer to specific engine recommendations).

Brake Fluid Flush:

Every 2-3 years

Coolant Change:

Every 4-5 years or 100,000 miles (initial fill), subsequent changes vary.

Timing Belt Or Chain:

V8 engines use timing chains, TDV6/SDV6 engines use timing belts (refer to manual for specific replacement intervals, often 100,000-150,000 miles).

Engine Oil Petrol V8:

SAE 5W-30 or 0W-30 (e.g., Castrol EDGE Professional Professional OE 5W-30 or similar meeting WSS-M2C153-G or WSS-M2C153-H)

Engine Oil Diesel Tdv6 Sdv6:

SAE 5W-30 (meeting Ford WSS-M2C153-G or equivalent diesel specification)

Coolant Type:

OAT (Organic Acid Technology) Antifreeze/Coolant, Jaguar/Land Rover specification STJLR.651.5003 (e.g., Prestone AF2000 or similar).

Brake Fluid:

DOT 4

Air Suspension Components:

Air springs (spring bags) can degrade and leak over time, leading to vehicle sag. Air compressor can also fail. Manual provides diagnostic and replacement procedures.

Diesel Particulate Filter (Dpf):

Early diesel models may experience DPF clogging if primarily used for short-distance city driving. Manual covers DPF regeneration and cleaning procedures.

Turbocharger Issues:

Potential for turbocharger failures or boost leaks, especially in high-mileage vehicles. Manual details turbo diagnostics and replacement.

Interior Electronics:

Some issues with infotainment screens, navigation systems, or climate control modules can occur. Detailed electrical diagrams and troubleshooting are included.

V8 Timing Chain Guides:

Certain early V8 engines can suffer from worn timing chain guides, leading to rattling noises. Manual provides inspection and replacement steps.

Oil Filter ( Example For 4.4L V8):

LR004303 (or equivalent, e.g., Mann-Filter HU821y)

Air Filter ( Example For Tdv6):

LR011308 (or equivalent, e.g., Mann-Filter C27004)

📚 Vehicle History

Land Rover Legacy:

A history of robust off-road vehicles dating back to 1948, known for capability and durability.

First Generation Launch:

Launched in 2005 as a more performance-oriented and road-focused alternative to the larger Range Rover.

Design Inspiration:

Based on the LR3/Discovery 3 platform but with unique styling and luxury appointments.

Facelift:

Received a significant facelift for the 2010 model year, including updated styling, interior, and powertrain options (e.g., introduction of the 3.0L SDV6 diesel and updated V8 engines).

Manufacturing Location:

Solihull, West Midlands, United Kingdom

🏆 Awards & Recognition

Off Road Capability Award:

Consistently recognized for its off-road prowess and ability to handle diverse terrains, reflecting Land Rover's heritage.

Luxury And Comfort Accolades:

Praised for its luxurious interior, comfortable ride, and refined driving experience, competing effectively in the premium SUV segment.
