Market Segment:
Subcompact/Compact economy car.
Target Audience:
DIY enthusiasts, independent repair shops, owners seeking detailed repair information.
Competitors:
Toyota Yaris, Honda Fit, Ford Fiesta, Chevrolet Aveo.
Licensing:
Officially licensed, derived from OE materials.
Access Duration:
One-year access, with discounts for renewal.
Content Provider:
RepairSurge
General Coverage:
Comprehensive service and repair for the 2009 Nissan Versa.
System Coverage:
Engine, Drivetrain, Brakes, Suspension, Steering, Electrical System, HVAC, Body & Chassis, Maintenance, Troubleshooting, Diagnostics.
Estimated Page Count:
N/A (Software, online access)
Type:
Service and Repair Manual Software
Format:
Online Access Software
Engine Systems:
Engine mechanical, lubrication, cooling, fuel, ignition, emissions control, starting and charging, engine control systems (ECM).
Drivetrain Systems:
Manual transmission, automatic transmission, clutch system, drive shafts, axles, differentials.
Chassis Systems:
Suspension (front and rear), steering system (power steering, rack and pinion), brake system (hydraulic, ABS, parking brake), wheels and tires.
Electrical Systems:
Battery, charging system, starting system, lighting, instruments and gauges, power windows, locks, mirrors, audio system, engine control wiring, chassis wiring.
HVAC Systems:
Heating, ventilation, air conditioning (compressor, refrigerant, evaporator, condenser).
Body Chassis:
Body panels, doors, hood, trunk, bumpers, interior trim, glass, seats.
Maintenance Procedures:
Oil changes, filter replacements, coolant flushes, brake fluid changes, spark plug replacement, belt inspection and replacement, fluid level checks, tire rotation.
Repair Procedures:
Engine component replacement (e.g., alternator, starter, water pump), transmission service and repair, brake pad and rotor replacement, suspension component replacement (shocks, struts, control arms), steering rack replacement, exhaust system repair, A/C system servicing, electrical component diagnosis and replacement.
Diagnostic Procedures:
Troubleshooting guides for common symptoms, diagnostic trouble code (DTC) interpretation and clearing, component testing procedures, wiring diagram analysis.
Depth:
Factory-level, detailed diagnostic and repair procedures.
Detail Level:
Includes step-by-step instructions, torque specifications, diagnostic flowcharts, wiring diagrams, and exploded views.
Engine Type:
Inline 4-Cylinder, DOHC, 16-Valve
Displacement:
1.6 Liters (1598 cc)
Bore X Stroke:
78.0 mm x 83.6 mm
Horsepower:
107 hp @ 6000 rpm
Torque:
111 lb-ft @ 4400 rpm
Fuel Delivery:
Electronic Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline
Engine Oil Type:
SAE 5W-30 (API SN or higher)
Engine Oil Capacity:
Approx. 3.9 U.S. quarts (3.7 liters) with filter change
Coolant Type:
Nissan Genuine Super Long Life Coolant (Blue)
Type:
5-Speed Manual Transmission
Type:
Continuously Variable Transmission (CVT) (e.g., RE0F08A/B)
Manual Transmission Fluid:
API GL-4, SAE 75W-80 (check manual for specific Nissan spec)
Cvt Fluid Type:
Nissan CVT Fluid NS-2 or NS-3 (verify applicable type for 2009)
NHTSA Front Impact Driver:
5-Star
NHTSA Front Impact Passenger:
5-Star
NHTSA Side Impact Front Driver:
5-Star
NHTSA Side Impact Front Passenger:
5-Star
NHTSA Side Impact Rear Driver:
5-Star
NHTSA Side Impact Rear Passenger:
5-Star
NHTSA Rollover FWD:
4-Star
Brake System:
Front ventilated discs, rear drums standard. Optional front and rear discs with ABS.
Traction Control:
Available
Electronic Stability Control:
Available (VDC - Vehicle Dynamic Control)
Airbags:
Front airbags, front side-impact airbags, roof-mounted curtain airbags (optional).
Seatbelts:
3-point front and rear seatbelts, pretensioners, load limiters.
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first.
Tire Rotation Interval:
Every 7,500 miles (12,000 km) or 6 months.
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or 12 months.
Spark Plug Replacement:
Every 105,000 miles (168,000 km) (iridium-tipped)
Engine Coolant Replacement:
First replacement at 105,000 miles (168,000 km), then every 75,000 miles (120,000 km) or 5 years.
Common Problems:
CVT issues (sluggishness, premature failure), minor electrical glitches, rear drum brake wear, intake valve deposits.
Diagnostic Challenges:
Diagnosing CVT specific fault codes, tracing intermittent electrical faults, fuel system component diagnosis.
Manufacturer History:
Nissan Motor Corporation is a Japanese multinational automobile manufacturer founded in 1933, known for a wide range of vehicles from compact cars to commercial trucks.
Versas Segment:
The Nissan Versa (also known as Nissan Tiida or Sunny in some markets) was introduced to North America for the 2007 model year as a replacement for the Sentra's entry-level positioning.
Generation Details:
The 2009 model year represents the first generation (N12/C11 chassis) of the Versa, offering a choice between sedan and hatchback body styles.
Production Locations:
Primarily manufactured in Japan and Mexico.
