2013 Polaris RANGER Owner Manual for Maintenance ATV QUAD OFF Road Download PDF

Prix habituel: $16.99
Prix soldé: $16.99
Prix habituel
Prix unitaire: par

27 people are viewing this right now

Taper: Atv

Distributeur:

UGS: 51424

Mots clés: 2013 ATV Polaris Powersports RANGER RZR Series

Variantes de produits

Description

Welcome to the comprehensive guide for your 2013 RANGER RZR XP 900 and RANGER RZR XP 4 900. These high-performance Side-by-Side vehicles were engineered for recreational riders and trail enthusiasts. Featuring a potent 88 HP 900cc ProStar engine and long-travel independent suspension, the RZR XP models deliver exceptional off-road capability. Whether you choose the agile 2-seater RANGER RZR XP 900 or the spacious 4-seater RANGER RZR XP 4 900, you are equipped for adventure. This vehicle's robust construction and advanced technology, including the Versa-Trac® AWD system, ensure a thrilling and capable experience on challenging terrain. This manual provides essential information for the operation, maintenance, and care of your RANGER RZR. It covers critical areas such as engine and drivetrain maintenance, suspension adjustments, brake system checks, and basic electrical troubleshooting. You will find detailed procedures for routine service, including oil changes, filter replacements, and lubrication, along with guidance on safety practices and pre-ride inspections. The information within is designed to assist both owners and technicians in keeping the vehicle in optimal condition, ensuring reliability and performance for years of off-road enjoyment.

🏷️ Basic Information

Identification

Make:

Polaris

Model:

RANGER RZR XP 900 / RANGER RZR XP 4 900

Year:

Codes

Vin Prefix:

Model Code Rzr Xp 900:

Z13XT90AA/AZ/AK/EF/EM/ES

Model Code Rzr Xp 4 900:

Z13XF90AJ/AW/AZ

👋 Introduction

Market Position

Segment:

High-performance Side-by-Side (SxS) / Utility Task Vehicle (UTV)

Target Audience:

Recreational riders, trail enthusiasts, outdoor adventurers seeking power and capability.

Competitive Analysis

Competitors:

Can-Am Commander, Arctic Cat Wildcat, Yamaha Wolverine

Key Features

Engine Power:

Strong 900cc ProStar engine.

Suspension Travel:

Long-travel independent suspension for excellent off-road capability.

Seating Options:

Available in 2-seater (RZR XP 900) and 4-seater (RZR XP 4 900) configurations.

📋 Manual Details

Coverage Areas

Primary Coverage:

2013 Polaris RANGER RZR XP 900 and 2013 Polaris RANGER RZR XP 4 900

Secondary Coverage:

General Off-Road ATV Maintenance and Safety

Page Count

Estimated Page Count:

120-150 (typical for this model year and format)

Manual Type

Type:

Owner's Manual

Language

Language:

English

Format

Format:

Downloadable PDF

📖 Manual Coverage

Systems Covered

Engine:

100% (Operation, basic maintenance, troubleshooting)

Drivetrain:

100% (Transmission, differentials, AWD system)

Suspension:

100% (Adjustment, inspection)

Brakes:

100% (Operation, inspection, fluid checks)

Electrical:

80% (Basic troubleshooting, battery, lighting, ignition)

Chassis Bodywork:

70% (General care, seat removal, basic component access)

Procedures Included

Basic Maintenance:

Oil change, filter replacement, spark plug inspection, air filter cleaning/replacement, lubrication points

Troubleshooting:

Start-up issues, common warning lights, basic operational anomalies

Safety Operations:

Pre-ride inspections, safe operating practices, passenger safety, load limits

Technical Depth

Depth:

Comprehensive for owner-level maintenance and safe operation. Does not cover full engine rebuilds or advanced electrical diagnostics.

📊 Manual Specifications

File Format

File Type:

Searchability:

Typically OCR-enabled for text search

Print Quality

Quality:

High resolution, suitable for digital viewing and printing

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke DOHC Twin-Cylinder

Displacement:

875 cc

Bore X Stroke:

93.0 mm x 64.4 mm

Cooling System:

Liquid-cooled

Ignition System:

Electronic Ignition

Performance

Horsepower:

Approx. 88 HP (claimed)

Torque:

Not explicitly stated in owner's manual, but high for its class.

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded gasoline, 87 octane minimum

Fuel Capacity:

7.25 gal (27.4 L)

🔧 Transmission

Standard

Transmission Type:

Automatic (CVT - Continuously Variable Transmission)

Drive Modes:

2WD / AWD (Versa-Trac®)

Features

Gear Selection:

High, Low, Neutral, Reverse, Park

Clutch:

Durable, belt-driven CVT with engine braking

Fluid Specifications

Cvt Fluid Type:

Polaris AGL Premium Synthetic Gearcase Lubricant or equivalent API GL-4

Final Drive Fluid Type:

Polaris Demand Drive Fluid (front differential) / Polaris AGL (rear differential)

📐 Dimensions

Exterior

Length Rzr Xp 900:

116.5 in. (296 cm)

Length Rzr Xp 4 900:

145.6 in. (370 cm)

Width:

64 in. (162.6 cm)

Height Rzr Xp 900:

73 in. (185.4 cm)

Height Rzr Xp 4 900:

75 in. (190.5 cm)

Wheelbase Rzr Xp 900:

81.4 in. (206.8 cm)

Wheelbase Rzr Xp 4 900:

107.4 in. (272.8 cm)

Ground Clearance:

13.5 in. (34.3 cm)

Cargo

Cargo Box Capacity:

300 lbs (136 kg)

Weights

Dry Weight Rzr Xp 900:

1,175 lbs (533 kg)

Dry Weight Rzr Xp 4 900:

1,352 lbs (613 kg)

Towing Capacity:

1,500 lbs (680 kg)

Payload Capacity Rzr Xp 900:

425 lbs (193 kg)

Payload Capacity Rzr Xp 4 900:

675 lbs (306 kg)

🛡️ Safety Features

Ratings

Crash Ratings:

N/A (ATVs/SxS are not typically subject to automotive crash testing standards)

Active Features

Braking System:

Hydraulic Disc Brakes with Dual-Bore Front and Rear Calipers

Parking Brake:

Parking Brake Lever

A Arm Guarding:

Integrated A-arm guards for protection

Passive Features

Seatbelts:

3-point seatbelts (standard)

Roll Cage:

ROPS (Roll-Over Protection Structure)

Doors:

Full Doors (standard on XP 4, partial on XP 900)

Lighting:

LED Accent Lights, Dual LED Headlights, Dual LED Tail Lights

💡 Technology Features

Infotainment

Instrument Cluster:

Digital Gauge with Odometer, Speedometer, Tachometer, Trip Meter, Fuel Gauge, Coolant Temp, Clock, Diagnostic Indicators

Driver Assistance

A Wd System:

Polaris's Versa-Trac® AWD system automatically engages all four wheels when needed.

Connectivity

Charging Port:

Often includes a DC power outlet for charging accessories.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 100 hours or 12 months, whichever comes first.

Air Filter Inspection:

Every 25 hours or 3 months. Clean or replace as needed.

Spark Plug Inspection:

Every 100 hours or 12 months.

Transmission Fluid Check:

Every 50 hours or 6 months.

Lubrication Points:

Every 25 hours or 3 months (refer to manual for specific locations).

Fluid Specifications

Engine Oil Type:

Polaris Synthetic 2W-50 (or equivalent SAE 5W-50 synthetic meeting API CI-4)

Engine Oil Capacity:

2.1 US quarts (2.0 Liters)

Coolant Type:

Polaris Full Synthetic 2-Cycle Oil or equivalent JIS K 2234 LLC

Brake Fluid Type:

DOT 4

Known Issues

Common Wear Items:

CVT belts, wheel bearings, ball joints, tie rod ends due to aggressive use.

Potential Maintenance Concerns:

Proper lubrication, timely belt replacement, and keeping air filters clean are crucial for longevity.

📚 Vehicle History

Brand Heritage

Brand Focus:

Polaris is a long-standing manufacturer of powersports vehicles, known for innovation in ATVs and UTVs.

Model Evolution

Rzr Lineage:

The RZR (Recreational Sport) line was introduced to target the sport performance segment of the ATV market, evolving into powerful SxS vehicles.

Xp Series Introduction:

The 'XP' designation signifies the high-performance variant, featuring the most powerful engines and advanced suspensions in the RZR lineup at the time of release.

Production

Manufacturing Location:

USA (Polaris factories)

🏆 Awards & Recognition

Recognitions

Industry Acclaim:

The RZR XP 900 was widely praised by powersports media for its performance and handling upon its release.

Ratings

Performance Reviews:

Consistently rated highly for its power-to-weight ratio and suspension capabilities in its class.

Certifications

Epa Approval:

As a trail vehicle, typically meets EPA emissions standards for off-road use.
