Vehicle Segment:
Compact Sports Car / Rear-Wheel Drive Coupe
Key Competitors Early 2010S:
Mazda MX-5 Miata, Nissan 370Z, Toyota GT86/Scion FR-S (platform sharing)
Driving Dynamics:
Lightweight chassis, rear-wheel drive, low center of gravity, driver-focused cockpit, balanced handling.
Value Proposition:
Essential for BRZ owners performing their own maintenance or repairs, saving significant costs compared to dealership service.
Powertrain:
Engine, Lubrication, Ignition, Fuel Injection, Exhaust System, Manual Transmission, Automatic Transmission, Clutch, Driveshaft, Final Drive, Turbocharger
Chassis:
Suspension, Brakes, Steering, Shock Absorbers
Body And Electrical:
Body, Electrical System, Instruments, Heating & Air-Conditioning, SRS (Supplemental Restraint System), Electrical Wiring Diagrams
Maintenance:
Scheduled Maintenance, Fluid Checks and Changes, Filter Replacements, Inspections
Diagnostics And Repair:
Troubleshooting, Component Removal and Installation, System Diagnostics, Repair Procedures, Reassembly
Electrical System Repair:
Comprehensive coverage of wiring harnesses, fuses, relays, lighting, sensors, and diagnostic connectors (OBD-II).
Engine Troubleshooting:
Detailed diagnostics for common engine issues, including misfires, fuel delivery problems, and ignition system faults.
Body And Trim Removal:
Instructions for removing interior and exterior panels, bumpers, and trim pieces.
Suspension And Steering Repair:
Detailed procedures for strut replacement, alignment specifications, ball joint inspection, and power steering system checks.
Brake System Overhaul:
Instructions for brake pad and rotor replacement, caliper service, brake line bleeding, and ABS system checks.
Depth:
Comprehensive, covering from basic maintenance to advanced repairs and diagnostics, including detailed wiring diagrams.
Torque Specifications:
Includes crucial torque values for engine components, suspension, brakes, and wheel lug nuts.
Special Tools:
Identifies and describes necessary special tools for specific repair procedures.
Diagnostic Trouble Codes:
Provides a listing and interpretation of common DTCs and their potential causes and solutions.
Engine Type:
Naturally Aspirated Boxer-4 (Horizontally Opposed)
Displacement:
2.0 Liters (1998 cc)
Bore X Stroke:
86 mm x 86 mm
Horsepower Output:
Approx. 200 hp @ 7000 rpm
Torque Output:
Approx. 151 lb-ft @ 6400 rpm
Injection Type:
D-4S (Direct Injection and Port Injection)
ECU Type:
Denso (Specific ECU part numbers available in manual)
Timing System:
Timing Chain (Dual Overhead Camshafts - DOHC)
Coolant Type:
Subaru Super Coolant (Blue) or equivalent G12/G13 compatible coolant
Presence:
No factory turbocharger on 2012-2013 models (included in manual for aftermarket reference or system understanding).
Type:
6-speed Manual Transmission (Aisin AZ6/TG80)
Type:
6-speed Automatic Transmission (with Paddle Shifters on some trims)
Manual Gear Ratios:
Refer to manual for specific gear ratios (e.g., 1st: 3.647, 2nd: 2.045, 3rd: 1.379, 4th: 1.067, 5th: 0.914, 6th: 0.767, Reverse: 3.437)
Manual Transmission Fluid:
Subaru Extra-S Gear Oil (75W-90 GL-5) or equivalent
Automatic Transmission Fluid:
Subaru ATF-HP (High Performance) or equivalent Dexron VI compatible fluid
Clutch Type:
Hydraulically Actuated Multi-Plate
Wheelbase:
101.2 inches (2570 mm)
Length:
166.1 inches (4220 mm)
Width:
69.9 inches (1775 mm)
Height:
50.6 inches (1285 mm)
Ground Clearance:
Approx. 4.7 inches (120 mm)
Curb Weight:
Approx. 2,762 - 2,824 lbs (1,253 - 1,281 kg) depending on transmission
Gross Vehicle Weight Rating:
Refer to vehicle's VIN plate or manual
Trunk Capacity:
Approx. 6.9 cu ft (195 liters)
NHTSA Overall Rating 2013:
5-Star (Top Safety Pick designation from IIHS in some configurations)
Stability Control:
Vehicle Stability Control (VSC) with Sport Mode
Traction Control:
Traction Control System (TCS)
Airbags:
Front, Side, Curtain Airbags (SRS system detailed in manual)
Seatbelts:
3-point ELR seatbelts with pretensioners and force limiters
Frame Design:
High-tensile steel chassis for rigidity and low weight
Head Unit Features:
Basic AM/FM/CD/MP3 player, optional navigation, Bluetooth connectivity (depending on trim and market).
Key Systems:
ABS, EBD, Brake Assist, VSC, TCS.
Usb Aux Input:
Available on most models for audio playback and charging.
Oil Change Interval:
Every 7,500 miles or 12 months, whichever comes first (refer to manual for specific conditions).
Spark Plug Replacement:
Refer to manual; typically around 60,000 - 100,000 miles for iridium plugs.
Engine Oil Capacity:
Approx. 5.7 US quarts (5.4 Liters) with filter change (refer to manual for exact capacity).
Engine Oil Viscosity:
0W-20 (API SN or higher, ILSAC GF-5 or higher)
Coolant Capacity:
Approx. 6.6 US quarts (6.3 Liters)
Brake Fluid Type:
DOT 3 or DOT 4
Power Steering Fluid:
Refer to manual (often electric power steering, no fluid refill for primary system).
Oil Consumption Early Models:
Some early production models experienced higher-than-average oil consumption, addressed through service bulletins and potential internal updates. Manual covers engine oil level checks.
Clutch Slave Cylinder:
Potential for external clutch slave cylinder leaks; manual details inspection and replacement procedures.
Maintenance Schedule Summary
Items Covered:
Oil and filter, air filter, cabin air filter, brake inspection, tire rotation, drive belt inspection, coolant level, clutch fluid.
