Suzuki KIZASHI 2010-2011 Full Service Repair Manual

Prix habituel: $17.99
Prix soldé: $17.99
Prix habituel
Prix unitaire: par

🏷️ Basic Information Identification Make: Suzuki Model: Kizashi Year: 2010-2011 Codes Engine Code Primary: J24B Generation Generation Name: First Generation (BY) 👋 Introduction Market Position Segment: Mid-size sedan, often positioned...

17 people are viewing this right now

Taper: Car

Distributeur:

UGS: 162196

Mots clés: 2010 2011 Car Cars Featured KIZASHI Suzuki

Variantes de produits

Description

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

Kizashi

Year:

2010-2011

Codes

Engine Code Primary:

Generation

Generation Name:

First Generation (BY)

👋 Introduction

Market Position

Segment:

Mid-size sedan, often positioned as a sportier alternative in its class.

Competitive Analysis

Key Competitors:

Nissan Altima, Honda Accord, Toyota Camry, Subaru Legacy, Ford Fusion, Mazda6.

Key Features

Distinguishing Features:

Standard AWD on many models, sporty handling for its class, distinctive styling, powerful 2.4L engine.

Target Audience

Ideal Owner:

Drivers seeking a stylish, well-equipped, and capable sedan with an emphasis on driving dynamics and all-weather capability.

📋 Manual Details

Coverage Areas

Countries Of Sale Covered:

North America, Australia, Europe, Asia (specific markets may vary based on original manual distribution)

Page Count

Estimated Page Count:

Approx. 2500-3500 pages (typical for a full service manual, exact count not specified)

Manual Type

Manual Type:

Full Service and Repair Manual

Language

Language:

English

Format

File Format:

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine assembly, cylinder head, block, pistons, crankshaft, camshafts, valve train, lubrication system, cooling system, fuel system (injection and delivery), intake and exhaust systems.

Engine Management:

Engine Control Module (ECM) diagnostics, sensor inputs (MAF, MAP, O2, crank, cam), actuator outputs (injectors, ignition coils), emissions control systems (EVAP, EGR).

Transmission Manual:

Manual transmission (MT) internal components, clutch system, shift linkage, gear ratios, repair and overhaul procedures.

Transmission Automatic:

Automatic transmission (AT) internal components (torque converter, planetary gear sets, valve body), hydraulic control systems, transmission control module (TCM) diagnostics, repair and overhaul procedures.

Drivetrain:

All-Wheel Drive (AWD) system (if applicable), front and rear differentials, drive shafts, CV joints, wheel bearings, hub assemblies.

Suspension:

Front and rear suspension components (struts, shocks, springs, control arms, ball joints, bushings), steering system (rack and pinion, power steering pump/motor), wheel alignment specifications.

Brakes:

Brake system components (discs, pads, calipers, master cylinder, brake lines, ABS modulator), hydraulic system bleeding, parking brake system.

Electrical System:

Battery, charging system (alternator), starting system (starter motor), lighting (headlights, taillights, interior), fuses, relays, wiring diagrams, power distribution.

Body And Chassis:

Body panel removal and installation, doors, hood, trunk, glass, bumpers, frame and unibody structure repair, corrosion protection.

HVAC:

Heating, Ventilation, and Air Conditioning (HVAC) system components (compressor, condenser, evaporator, blower motor, climate control module), refrigerant handling, diagnostics.

Interior:

Seats, dashboard, interior trim panels, airbags system (SRS), seat belts, interior lighting, audio system integration.

Safety Systems:

Anti-lock Braking System (ABS), Electronic Stability Control (ESC), Traction Control System (TCS), airbag system (SRS) component identification, diagnostics, and replacement.

Diagnostics And Troubleshooting:

Diagnostic Trouble Codes (DTCs), symptom-based troubleshooting guides, wiring harness testing, component testing procedures.

Procedures Included

Maintenance Procedures:

Scheduled maintenance tasks, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacements (oil, air, cabin), spark plug replacement, belt inspection and replacement.

Repair Procedures:

Detailed step-by-step instructions for component removal, installation, overhaul, and adjustment for all major vehicle systems.

Troubleshooting Procedures:

Systematic diagnostic approaches to identify and resolve common and uncommon vehicle issues.

Electrical Troubleshooting:

Use of wiring diagrams, circuit testing, component resistance checks, continuity testing.

Special Tools:

Identification of specific tools required for certain repair and maintenance procedures.

Technical Depth

Depth Of Coverage:

Comprehensive, from basic maintenance to complete engine and transmission rebuilds.

Diagnostics Level:

Advanced diagnostics, including troubleshooting of electronic control modules and sensors.

Rebuild Procedures:

Detailed instructions for the complete disassembly, inspection, repair, and reassembly of major mechanical components.

📊 Manual Specifications

File Format

PDF Quality:

High-quality, suitable for professional use, zoomable for detail.

Print Quality

Printable:

Fully printable for offline use.

Binding Type

Binding Type:

Digital (PDF) - N/A (printable)

Paper Type

Paper Type:

Digital (PDF) - N/A (user chooses paper type upon printing)

Usability

Searchable:

Likely searchable text within the PDF for quick information retrieval.

Zoom Functionality:

Yes, allows for detailed viewing of diagrams and text.

⚙️ Engine Specifications

Primary Engine

Engine Type:

Inline 4-cylinder, DOHC, 16-valve, VVT

Displacement:

2.4 Liters (2393 cc)

Bore X Stroke:

88.0 mm x 98.5 mm

Compression Ratio:

9.8:1

Performance

Horsepower SAE Net:

172 hp @ 6000 rpm

Torque SAE Net:

170 lb-ft @ 4000 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (MPFI)

Recommended Fuel:

87 Octane Unleaded Gasoline

Cooling System

Cooling Medium:

Water-cooled

Lubrication System

Oil Type Capacity:

Refer to manual for specific SAE viscosity grade (e.g., 0W-20 or 5W-30) and capacity (typically around 4.5-5.0 quarts with filter).

🔧 Transmission

Standard

Transmission Type Standard:

6-speed Manual Transmission (MT)

Optional

Transmission Type Optional:

Continuously Variable Transmission (CVT) with manual shift mode

Features

Drivetrain Options:

Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) available.

Fluid Specifications

Automatic Transmission Fluid:

Refer to manual for specific CVT fluid type (e.g., Suzuki CVT Fluid Green-1).

Manual Transmission Fluid:

Refer to manual for specific manual transmission fluid type and viscosity (e.g., SAE 75W-90 GL-4 or GL-5).

📐 Dimensions

Exterior

Length:

Approximately 190.4 inches

Width:

Approximately 71.4 inches

Height:

Approximately 59.3 inches

Wheelbase:

Approximately 109.3 inches

Weights

Curb Weight Estimate:

Approximately 3300-3500 lbs (varies by trim and drivetrain)

🛡️ Safety Features

Ratings

NHTSA Front Driver Side Impact:

5-Star (for 2010 model year tested)

NHTSA Front Passenger Side Impact:

5-Star (for 2010 model year tested)

IIHS Top Safety Pick:

Yes (for 2011 model year)

Active Features

Standard Active Safety:

ABS, EBD (Electronic Brake-force Distribution), Traction Control System (TCS), Electronic Stability Control (ESC).

Passive Features

Standard Passive Safety:

Front dual-stage airbags, front side-impact airbags, side curtain airbags (front and rear).

💡 Technology Features

Infotainment

Audio System:

Standard AM/FM/CD/MP3 audio system with auxiliary input. Optional premium audio systems (e.g., Rockford Fosgate) were available on higher trims.

Navigation System:

Optional touch-screen navigation system available on select trims.

Driver Assistance

Cruise Control:

Standard cruise control.

Keyless Entry Start:

Available keyless entry and push-button start on higher trims.

Connectivity

Bluetooth:

Optional Bluetooth connectivity for hands-free calling and audio streaming.

🔧 Maintenance

Service Intervals

Engine Oil Change:

Typically every 7,500 miles or 6 months, whichever comes first, for conventional oil. Check manual for synthetic oil recommendations and potential longer intervals.

Air Filter Replacement:

Every 15,000-30,000 miles or as needed based on driving conditions.

Cabin Air Filter Replacement:

Every 12,000-15,000 miles or annually.

Spark Plug Replacement:

Typically around 100,000 miles, depending on plug type (e.g., iridium).

Coolant Flush:

Every 60,000 miles or 4 years, whichever comes first.

Fluid Specifications

Engine Coolant:

Suzuki Super Long Life Coolant (Blue) or equivalent HOAT coolant.

Brake Fluid:

DOT 3 or DOT 4 Brake Fluid.

Known Issues

Common Wear Items:

Brake pads and rotors, front suspension bushings and ball joints, wheel bearings (especially on AWD models).

Potential Electrical Gremlins:

Occasional reports of minor electrical issues, though generally reliable.

Cvt Longevity:

Early CVT models in some vehicles can be sensitive to fluid maintenance; strict adherence to the manual is crucial.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation, a Japanese multinational corporation known for its automobiles, motorcycles, and ATVs.

Model Evolution

First Generation Introduction:

The Kizashi was first unveiled in concept form in 2007 and entered production for the 2010 model year. It represented Suzuki's re-entry into the mainstream North American sedan market after a hiatus.

Production

Manufacturing Plant:

Sawa Factory, Kokubu, Japan

Production Years:

2009-2015 (globally), specific market availability for 2010-2011 in North America.

🏆 Awards & Recognition

Recognitions

IIHS Award:

Recognized as an IIHS Top Safety Pick for 2011.

Ratings

NHTSA Overall Safety Rating:

NHTSA awarded 5 stars for side-impact safety for the 2010 model year.
