TOYOTA FORKLIFT Repair And Service Manual

Prix habituel: $17.99
Prix soldé: $17.99
Prix habituel
Prix unitaire: par

🏷️ Basic Information Identification Make: Toyota Product Type: Forklift Truck Series Covered: EFG, VFG Models Covered Efg Series Models: 7FB10, 7FBH10, 7FB14, 7FBH14, 7FB15, 7FBH15, 40-7FB15, 7FB18, 7FBH18, 7FB20, 7FBH20,...

18 people are viewing this right now

Taper: Forklift

Distributeur:

UGS: 29036

Mots clés: All models Cars Featured Forklift Toyota

Variantes de produits

Description

🏷️ Basic Information

Identification

Make:

Toyota

Product Type:

Forklift Truck

Series Covered:

EFG, VFG

Models Covered

Efg Series Models:

7FB10, 7FBH10, 7FB14, 7FBH14, 7FB15, 7FBH15, 40-7FB15, 7FB18, 7FBH18, 7FB20, 7FBH20, 40-7FB20, 7FB25, 7FBH25, 40-7FB25, 7FB30, 7FBJ35

Vfg Series Models:

42-7FGF15, 02-7FDF15, 42-7FGF18, 02-7FDF18, 42-7FGF20, 62-7FDF20, 02-7FDF20, 42-7FGF25, 62-7FDF25, 02-7FDF25, 02-7FGF30, 62-7FDF30, 02-7FDF30, 02-7FGJF35, 02-7FDJF35

📋 Manual Details

Description

Manual Type:

Repair and Service Manual

Manual Source:

Factory

Availability

Format:

PDF Download

Language

Language:

English

Purpose

Benefit:

DIY Repair, Cost Savings

⚙️ Engine Specifications

General

Engine Type:

Electric (for EFG series), Internal Combustion (for VFG series - assumed based on model codes like FG for gasoline/LPG)

Electric Efg

Motor Type:

AC or DC electric motor (specifics vary by model)

Ic Vfg

Fuel Type:

Gasoline, LPG (Liquefied Petroleum Gas), Diesel (model dependent)

Displacement:

Varies by model and engine option (e.g., 2.0L - 4.0L common for this class)

Power Output:

Varies by engine and model (typically 40-70 HP range)

🔧 Transmission

General

Type:

Automatic Transmission

Drive System:

Rear-wheel steer, Front-wheel drive

🛡️ Safety Features

Features

Safety Systems:

Operator presence system, warning lights, audible alarms, tilt lock

🔧 Maintenance

Lubrication

Engine Oil Capacity:

Varies by engine model (refer to manual for specific model and engine)

Hydraulic Oil Capacity:

Varies by model and mast configuration (refer to manual)

Intervals

Service Interval:

Recommended intervals for lubrication, filter changes, and inspections (detailed in manual)

📄 Performance

Lifting Capacity

Rated Capacity:

1,000 kg to 3,500 kg (approx. 2,200 lbs to 7,700 lbs), depending on model

Travel Speed

Max Travel Speed:

Varies by model and load, typically 15-20 km/h (9-12 mph)

Lift Speed

Max Lift Speed:

Varies by model and load, typically 400-600 mm/s (16-24 in/s)

📄 Chassis

Mast Type

Mast Options:

Duplex, Triplex masts with varying lift heights

Tyres

Tyre Type:

Solid rubber, Pneumatic (depending on model and application)
