Segment:
Compact Crossover SUV
Target Audience:
DIY mechanics, independent repair shops, Toyota RAV4 owners seeking detailed repair and maintenance information.
Competitors 2006:
Honda CR-V, Nissan Xterra, Ford Escape, Subaru Forester, Mazda Tribute
Unique Selling Points:
Officially licensed, factory-derived data, comprehensive coverage, digital convenience, licensed by RepairSurge.
Benefit To User:
Enables accurate and efficient self-repair, reduces reliance on expensive repair shops, extends vehicle lifespan.
Regions Covered:
Global (primarily North American specifications, but principles apply widely)
Estimated Pages:
1500-2000+ (typical for comprehensive factory service manuals)
Type:
Official Factory Service and Repair Manual Software
Format:
Digital Download (PDF or proprietary software accessed via web browser)
Powertrain:
Engine (2AZ-FE), Transmission (Automatic U250E, Manual P310F), Drivetrain (AWD system, differentials)
Chassis:
Suspension (front MacPherson strut, rear multi-link), Steering (power assisted rack and pinion), Brakes (front ventilated discs, rear solid discs, ABS/EBD)
Electrical:
Body electrical systems, powertrain control module (PCM), multiplex communication system, lighting, infotainment, HVAC controls
Body And Trim:
Body panels, interior trim, glass, bumpers, seats, airbags
Maintenance:
Scheduled maintenance, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacements, lubrication
Repair:
Engine overhaul, transmission overhaul, brake component replacement, suspension component replacement, electrical component repair, body repair
Diagnostics:
Diagnostic trouble code (DTC) interpretation, component testing, troubleshooting guides, wiring diagrams
Technical Specifications:
Torque specifications, alignment data, component clearances, electrical specifications
Wiring Diagrams:
Extensive and detailed electrical wiring diagrams for all systems are included, crucial for troubleshooting.
Depth:
Comprehensive: Covers routine maintenance, advanced diagnostics, component-level repair, and complete overhauls.
Diagnostic Tools Required:
Covers procedures requiring standard hand tools, specialized automotive tools, and factory scan tools (e.g., for ECU programming/diagnostics).
Digital Format:
PDF Downloadable / Web-based Software
Readability:
High resolution, clear diagrams and text for digital viewing and potential printing.
Binding:
N/A (Digital Format)
Paper Type:
N/A (Digital Format)
Coverage Scope:
Full Factory Service Manual (FSM) equivalent, providing a complete reference for all repair and maintenance procedures.
Engine Type:
Inline 4-cylinder, DOHC, 16-valve, VVT-i (Variable Valve Timing with intelligence)
Displacement:
2.4 Liters (2362 cc)
Bore X Stroke:
88.5 mm x 96.8 mm
Horsepower Gross:
166 hp @ 6000 rpm
Torque Gross:
163 lb-ft @ 4000 rpm
Fuel Delivery:
Electronic Fuel Injection (EFI), Sequential Port Injection
Recommended Fuel:
87 Octane Unleaded Gasoline
Coolant Type:
Toyota Super Long Life Coolant (Pink) or equivalent
Oil Capacity W Filter:
4.5 US Quarts (4.3 Liters)
Recommended Oil Viscosity:
SAE 5W-30 (API Certified)
Transmission Type FWD:
U250E 4-speed Automatic
Transmission Type AWD:
U250E 4-speed Automatic with Active Torque Split AWD
Manual Transmission Option:
P310F 5-speed Manual (less common in North America for 2006)
Automatic Features:
Electronically Controlled Transmission (ECT), Overdrive (O/D Off button)
Automatic Transmission Fluid:
Toyota Genuine ATF WS (World Standard) or equivalent
Automatic Transmission Fluid Capacity:
3.6 US Quarts (3.4 Liters) for dry fill, 3.1 US Quarts (2.9 Liters) for drain and refill
Length:
176.0 inches (4470 mm)
Width:
71.5 inches (1815 mm)
Height:
67.3 inches (1708 mm) (with roof rails)
Wheelbase:
103.1 inches (2619 mm)
Ground Clearance:
7.3 inches (185 mm)
Curb Weight FWD:
3360 lbs (1524 kg)
Curb Weight AWD:
3510 lbs (1592 kg)
Gross Vehicle Weight Rating:
4575 lbs (2075 kg)
Cargo Volume Behind 2Nd Row:
34.2 cu ft (968 liters)
Cargo Volume With 2Nd Row Folded:
68.3 cu ft (1934 liters)
Towing Capacity:
1500 lbs (680 kg) (with optional towing package)
NHTSA Frontal Driver:
5 Stars
NHTSA Frontal Passenger:
5 Stars
NHTSA Side Driver:
5 Stars
NHTSA Side Passenger:
5 Stars
IIHS Frontal Offset:
Good
ABS:
Standard (Anti-lock Braking System)
Ebd:
Standard (Electronic Brake-force Distribution)
Traction Control:
Standard (TRAC)
Stability Control:
Standard (VSC - Vehicle Stability Control)
Airbags Front:
Standard (Driver and Front Passenger Airbags)
Airbags Side:
Optional/Standard on some trims (Front Side Airbags and Roll-Sensing Side Curtain Airbags)
Seatbelts:
3-point ELR with pretensioners and force limiters (all positions)
Audio System:
Factory AM/FM/CD player with optional premium audio system (JBL) and subwoofer.
Display:
Digital odometer, trip computer. Optional navigation system on higher trims.
Auxiliary Input:
Not standard; aftermarket solutions or CD changer interface may be available.
HVAC:
Manual or automatic climate control with air conditioning.
Keyless Entry:
Standard or optional depending on trim level.
Oil And Filter Change:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first (severe driving conditions may require more frequent changes).
Engine Air Filter:
Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km).
Cabin Air Filter:
Inspect annually, replace as needed.
Coolant Replacement:
First replacement at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km) thereafter.
Transmission Fluid Change:
Refer to manual for specific intervals based on driving conditions. Generally, 60,000-100,000 miles is a common guideline, but check for severe service.
Spark Plugs:
Iridium-tipped spark plugs: 120,000 miles (192,000 km).
Power Steering Fluid:
Dexron II or equivalent power steering fluid
Common Wear Items:
Brake pads/rotors, suspension components (bushings, struts/shocks), catalytic converter (rare), exhaust system components.
Engine Performance:
Occasional oil consumption due to piston ring wear in higher mileage engines. Check PCV system for proper ventilation.
Transmission Behavior:
Some reports of occasional hard shifting, often related to transmission fluid condition or solenoid issues.
Electrical Quirks:
Rarely, minor electrical gremlins related to body control modules or sensors, typically addressed by software updates or component replacement.
Toyota Reputation:
Renowned for reliability, durability, and quality.
Rav4 Generation:
Second Generation (XA20) Facelift, introduced for the 2004 model year. This 2006 model represents the latter part of this generation.
Key Changes Facelift:
Revised front and rear styling, updated interior trim, improved engine and transmission options.
Manufacturing Location:
Takaoka Plant, Aichi, Japan; Toyota Motor Manufacturing Canada (TMMC), Woodstock, Ontario, Canada
Second Generation Production:
2000-2005 (Pre-facelift), 2004-2006 (Facelift)
