🏷️ Basic Information

Make:

Toyota

Model:

RAV4

Year:

2009

Chassis Code:

XJ40 (Third Generation, ACA33/38, GSA33/38)

Engine Codes Gasoline:

2AZ-FE (2.4L), 3MZ-FE (3.5L V6)

👋 Introduction

Segment:

Compact Crossover SUV

Competitors 2009:

Honda CR-V, Nissan Rogue, Ford Escape, Mazda CX-7, Subaru Forester

Design:

Second-generation redesign offered a more sophisticated interior, improved ride quality, and available V6 engine.

Convenience:

Instant online access, searchable content, accessible on multiple devices.

📋 Manual Details

Systems Covered:

Engine, Drivetrain, Transmission (Automatic & Manual), Brakes, Suspension, Steering, Electrical System, HVAC, Bodywork, Diagnostic Trouble Codes (DTCs), Maintenance, Troubleshooting, Wiring Diagrams, Specifications

Estimated Pages:

2000+

Type:

Official Factory Service and Repair Manual Software

Language:

English

Format:

PDF Download (via Web Browser Access)

📖 Manual Coverage

Engine Mechanical:

Complete engine overhaul, cylinder head, block, pistons, crankshaft, camshaft, timing system, lubrication, cooling system

Engine Electrical:

Ignition system, fuel injection system, starting system, charging system, engine control unit (ECU), sensors, actuators, emission control

Transmission Drivetrain:

Automatic Transmission (U250E), Manual Transmission (NV3500), Front-Wheel Drive (FWD), All-Wheel Drive (AWD) system, differentials, drive axles, CV joints

Suspension Steering:

Front suspension (MacPherson struts), Rear suspension (Independent Double Wishbone), power steering system, steering rack, steering column

Brakes:

Front disc brakes, rear disc brakes, Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), parking brake

Electrical Body:

Lighting system, power windows, power locks, mirrors, wipers, horn, instrument cluster, interior/exterior lights, body control module (BCM), anti-theft system, keyless entry

HVAC:

Air conditioning system, heating system, ventilation, climate control module, refrigerant, cabin air filter

Maintenance Procedures:

Oil changes, filter replacements (oil, air, cabin), fluid checks and changes (coolant, brake, transmission, power steering), spark plug replacement, battery maintenance, tire rotation and balancing

Repair Procedures:

Engine component replacement (alternator, starter, water pump, thermostat), transmission service, brake pad and rotor replacement, suspension component replacement (shocks, struts, control arms), steering component repair, exhaust system repair, electrical component diagnosis and replacement

Diagnostic Procedures:

Troubleshooting common issues, reading Diagnostic Trouble Codes (DTCs), using scan tools, pinpoint tests for electrical circuits, live data analysis

Depth:

Comprehensive; covers routine maintenance to complete engine and transmission overhauls, including detailed diagnostic procedures and wiring diagrams.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High-resolution, printable pages

Binding Type:

Not Applicable (Digital Download)

Paper Type:

Not Applicable (Digital Download)

Searchable Text:

Yes

Licensing:

Officially Licensed, derived from OE materials

⚙️ Engine Specifications

Engine 2 4L:

2AZ-FE Inline-4, DOHC, VVT-i

Engine 2 4L Displacement:

2362 cc (2.4 Liters)

Engine 2 4L Bore X Stroke:

88.5 mm x 96.0 mm

Engine 2 4L Compression Ratio:

9.8:1

Engine 2 4L Horsepower:

166 hp @ 6000 rpm

Engine 2 4L Torque:

163 lb-ft @ 4000 rpm

Engine 3 5L V6:

3MZ-FE V6, DOHC, VVT-i

Engine 3 5L V6 Displacement:

3456 cc (3.5 Liters)

Engine 3 5L V6 Bore X Stroke:

94.0 mm x 83.0 mm

Engine 3 5L V6 Compression Ratio:

10.8:1

Engine 3 5L V6 Horsepower:

269 hp @ 6200 rpm

Engine 3 5L V6 Torque:

246 lb-ft @ 4700 rpm

Fuel Delivery:

Electronic Fuel Injection (EFI)

Recommended Fuel:

87 Octane Unleaded Gasoline (for 2.4L), 87 Octane Unleaded Gasoline (for 3.5L V6)

🔧 Transmission

Transmission 2 4L:

5-speed Automatic (U250E)

Transmission 3 5L V6:

6-speed Automatic (AB60E)

Manual Transmission Availability:

Rarely offered on this generation, primarily on base models in certain markets (e.g., 5-speed Manual with 2.4L)

Drive Type Options:

Front-Wheel Drive (FWD), All-Wheel Drive (AWD)

📐 Dimensions

Length:

173.2 inches (2.4L FWD), 174.7 inches (AWD & V6)

Width:

70.1 inches

Height:

65.2 inches (FWD), 65.4 inches (AWD)

Wheelbase:

104.7 inches

Ground Clearance:

8.1 inches

Cargo Volume Behind Rear Seat:

31.4 cubic feet

Cargo Volume With Rear Seat Folded:

68.3 cubic feet

Curb Weight 2 4L FWD:

3,460 lbs

Curb Weight 2 4L AWD:

3,595 lbs

Curb Weight 3 5L V6 AWD:

3,715 lbs

🛡️ Safety Features

NHTSA Front Crash Test:

5 Stars

NHTSA Side Impact Crash Test:

5 Stars

IIHS Front Offset Crash Test:

Good

IIHS Side Impact Crash Test:

Good

Standard Safety Features:

ABS, EBD, Brake Assist, Traction Control (TRAC), Vehicle Stability Control (VSC)

Airbags:

Driver and front passenger airbags, front side curtain airbags, front and rear side-curtain airbags (optional/standard depending on trim)

💡 Technology Features

Audio System:

Standard CD player with AM/FM, available premium JBL audio system with subwoofer, auxiliary audio input, optional touchscreen navigation system.

Features:

Standard Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Traction Control (TRAC), Vehicle Stability Control (VSC). Optional: Backup camera.

Features:

Auxiliary audio input jack for portable music players.

🔧 Maintenance

Oil Change Interval:

Every 5,000 miles or 6 months (severe conditions), or 10,000 miles or 12 months (synthetic oil, normal conditions, consult manual for specific interval).

Engine Air Filter:

Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles under normal conditions.

Cabin Air Filter:

Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles under normal conditions.

Transmission Fluid Change:

Check every 30,000 miles, change fluid at approximately 60,000-100,000 miles, or as per severe service schedule. Consult manual for specific ATF type and interval.

Coolant Replacement:

Initial replacement at 100,000 miles, then every 50,000 miles thereafter (Toyota Super Long Life Coolant).

Engine Oil 2 4L:

SAE 5W-20, API SN or ILSAC GF-5 certified (Full Synthetic recommended)

Engine Oil 3 5L V6:

SAE 5W-20, API SN or ILSAC GF-5 certified (Full Synthetic recommended)

Transmission Fluid Automatic 5Spd:

Toyota Genuine ATF WS (World Standard)

Transmission Fluid Automatic 6Spd:

Toyota Genuine ATF WS (World Standard)

Coolant:

Toyota Super Long Life Coolant (Pink)

Brake Fluid:

SAE J1703 or FMVSS No. 116 DOT 3

Power Steering Fluid:

Toyota Genuine Power Steering Fluid or Dexron II/III

Common Complaints:

Excessive oil consumption (2AZ-FE engine, particularly in earlier models of this generation), occasional ABS/VSC warning lights, minor interior rattles, potential for catalytic converter issues (less common).

📚 Vehicle History

Toyota Legacy:

Toyota is renowned for reliability, durability, and quality, a reputation built over decades.

Rav4 Generation:

Third Generation (2006-2012), XJ40 platform. This generation saw a significant increase in size and offered a longer wheelbase option, moving it further into the compact SUV segment.

Production Location:

Nagoya, Japan; Ontario, Canada

🏆 Awards & Recognition

IIHS Top Safety Pick:

Awarded for Good performance in front, side, and rear impact tests, and for head restraint design.

Consumer Reports Ratings:

Generally receives good ratings for reliability and owner satisfaction.
