Segment:
Compact/Mid-size Coupe and Convertible
Target Audience:
DIY mechanics, enthusiasts, small repair shops.
Competitors:
Honda Civic Coupe, Mitsubishi Eclipse, Ford Mustang (entry-level trims), Chevrolet Camaro (entry-level trims).
Unique Selling Points:
Offers coupe and convertible variants on a reliable Toyota platform, combining sporty styling with practical engineering.
Manual Value Proposition:
Provides factory-level diagnostic and repair data in a convenient digital format, empowering owners to maintain and repair their vehicle efficiently and cost-effectively.
Primary Coverage:
1999 Toyota Solara
Secondary Coverage:
Includes information relevant to the XV20 platform, potentially assisting with shared components across other Toyota models of the era.
Estimated Pages:
Over 1500 pages (typical for comprehensive factory-derived software).
Type:
Service and Repair Manual Software
Format:
PDF Download (Access via web browser on compatible devices)
Access Duration:
1 Year (with options for renewal)
Powertrain:
Engine (2.2L 5S-FE, 3.0L 1MZ-FE), Transmission (4-speed automatic, 5-speed manual), Drivetrain components.
Chassis:
Suspension (front MacPherson struts, rear independent suspension), Steering (power-assisted rack and pinion), Brakes (front vented discs, rear discs, ABS).
Electrical:
Complete wiring diagrams, diagnostic procedures for all electrical systems, lighting, audio, instrumentation, charging system, starting system.
Body And Interior:
Body panel removal and installation, interior trim, HVAC system, doors, windows, seats, safety restraints.
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, tire rotation, spark plug replacement.
Repair And Overhaul:
Engine component replacement (pistons, rings, valves), transmission overhaul, brake caliper and rotor replacement, suspension component replacement (shocks, struts, bushings).
Diagnostics And Troubleshooting:
Step-by-step diagnostic procedures for common and uncommon issues, symptom-based troubleshooting guides, OBD-II diagnostic trouble codes (DTCs).
Electrical Troubleshooting:
Wiring diagram interpretation, circuit testing, component diagnostics, ABS system troubleshooting.
Depth:
Comprehensive: Covers everything from basic maintenance to complete engine and transmission rebuilds, including detailed diagnostic strategies and electrical system analysis.
Engine 1 Displacement:
2.2 Liters (2164 cc)
Engine 1 Configuration:
Inline 4-cylinder, DOHC, 16 valves
Engine 1 Horsepower:
133 hp @ 5200 rpm
Engine 1 Torque:
145 lb-ft @ 4400 rpm
Engine 2 Displacement:
3.0 Liters (2995 cc)
Engine 2 Code:
1MZ-FE (V6)
Engine 2 Configuration:
V-6, DOHC, 24 valves
Engine 2 Horsepower:
194 hp @ 5200 rpm
Engine 2 Torque:
209 lb-ft @ 4400 rpm
Fuel Injection:
Electronic Fuel Injection (EFI) with Sequential Port Injection
Fuel Type:
Unleaded Regular Gasoline (87 octane recommended)
ECU Type:
Toyota Electronic Control Unit (ECU) with OBD-II diagnostics
Transmission Type Std:
4-speed Automatic (A241E)
Transmission Type Opt:
5-speed Manual (E150F)
Automatic Features:
Electronically controlled, lock-up torque converter
Automatic Transmission Fluid:
Toyota ATF T-IV (Type T-IV)
Manual Transmission Fluid:
GL-4 Gear Oil (SAE 75W-90)
Length:
Coupe: 187.0 in. / Convertible: 187.8 in.
Width:
Coupe: 70.0 in. / Convertible: 70.0 in.
Height:
Coupe: 54.1 in. / Convertible: 54.3 in.
Curb Weight 2.2L:
Approx. 3000 - 3200 lbs (depending on body style and options)
Curb Weight 3.0L:
Approx. 3200 - 3400 lbs (depending on body style and options)
Gross Vehicle Weight Rating:
Available in manual.
Trunk Volume:
Coupe: Approx. 13.5 cu ft. / Convertible: Approx. 7.7 cu ft. (with top up).
NHTSA Frontal Impact Driver:
Not explicitly rated for 1999 model year by NHTSA in a standardized way comparable to modern ratings. However, known to have dual front airbags.
NHTSA Frontal Impact Passenger:
Not explicitly rated for 1999 model year by NHTSA in a standardized way comparable to modern ratings. However, known to have dual front airbags.
IIHS Ratings:
Not available for 1999 model year.
ABS:
Optional (Standard on V6 models)
Airbags:
Dual front airbags
Seatbelts:
3-point front seatbelts with pretensioners, 3-point rear seatbelts.
Rollover Protection:
Convertible models feature reinforced A-pillars and potentially pop-up roll bars (check specific VIN).
Audio System:
Factory-installed AM/FM stereo with CD player and cassette tape player. Optional premium JBL sound system.
Navigation:
Not available from factory for 1999 model year.
Cruise Control:
Standard on most models.
Traction Control:
Not typically available for 1999 model year.
Auxiliary Input:
Not available from factory.
Oil Change Interval:
Every 5,000 miles or 6 months, whichever comes first (or per manual recommendation).
Air Filter Replacement:
Every 30,000 miles or 2 years, or as needed based on driving conditions.
Spark Plug Replacement:
2.2L: Platinum-tipped plugs, 100,000-mile interval. 3.0L V6: Platinum-tipped plugs, 100,000-mile interval.
Timing Belt Replacement:
2.2L 5S-FE: Timing belt, replace every 90,000 miles (critical preventative maintenance). 3.0L 1MZ-FE V6: Timing belt, replace every 90,000 miles.
Engine Oil Capacity 2.2L:
4.5 US quarts (with filter) - API Service SG, SH, or SJ rated, SAE 5W-30 recommended.
Engine Oil Capacity 3.0L:
4.5 US quarts (with filter) - API Service SG, SH, or SJ rated, SAE 5W-30 recommended.
Coolant Type:
Toyota Super Long Life Coolant (SLLC) - Pink or Toyota Genuine Long Life Coolant (LLC) - Red. Pre-diluted 50/50 with distilled water.
Brake Fluid:
DOT 3 or DOT 4 (refer to reservoir cap)
Common Problems:
Oil leaks (valve cover gasket, oil pan gasket), suspension wear (bushings, ball joints), catalytic converter issues (on higher mileage vehicles), AC system leaks, intermittent electrical issues (door locks, power windows).
Timing Belt Failure Consequences:
Interference engine design: Timing belt failure on 5S-FE and 1MZ-FE engines will result in bent valves and severe internal engine damage.
Toyota Reputation:
Renowned for reliability, durability, and quality manufacturing.
Solara Introduction:
Introduced for the 1999 model year as a sportier, more stylish alternative to the Camry sedan. Based on the XV20 Camry platform.
First Generation Design:
Designed by Calty Design Research (Toyota's North American design studio). Available as a coupe and later as a convertible.
Manufacturing Location:
Georgetown, Kentucky, USA (TMMK)
Production Years First Gen:
1999-2003
Model Specific Awards:
None widely publicized for the 1999 model year as a standalone model, but benefits from Toyota's overall strong reputation for reliability.
Consumer Reports Reliability:
Toyota vehicles of this era generally received high marks for reliability from sources like Consumer Reports, a trend the Solara typically followed.
