2000 Yamaha Fazer 600 Workshop Service Repair Manual

Prix habituel: $16.99
Prix soldé: $16.99
Prix habituel
Prix unitaire: par

23 people are viewing this right now

Taper: Motorcycle

Distributeur:

UGS: 132653

Mots clés: 2000 Fazer Fazer 600 Motorcycle Motorcycles Yamaha

Variantes de produits

Description

The Yamaha Fazer 600, specifically the first-generation model from 2000 (chassis code 4X1), is a versatile middleweight sport-touring motorcycle celebrated for its balanced performance, comfortable ergonomics, and practical design. Building on a legacy of engineering excellence, this model offers a 599 cc inline-four engine, a practical fairing for wind protection, and a steel diamond frame, making it suitable for both daily commuting and longer journeys. Its inline-four, liquid-cooled engine, coupled with a 6-speed transmission, delivers approximately 95-98 hp, providing spirited yet manageable power. The Fazer 600 competed effectively in its class, earning praise for its all-around capabilities and reliability. This comprehensive Workshop Service Repair Manual provides essential guidance for owners and technicians alike. It covers a wide array of critical areas, including detailed engine overhaul procedures, carburetor assembly and tuning, complete chassis service, and in-depth electrical system diagnostics. The manual also offers practical advice on routine maintenance, troubleshooting common issues, and performing component repairs, ensuring the Fazer 600 remains in optimal condition. Its scope extends from basic adjustments to complex rebuilds, making it an indispensable resource for maintaining the performance, safety, and longevity of the 2000 Yamaha Fazer 600.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

Fazer 600

Year:

Generation

Model Generation:

First Generation (4X1)

Codes

Chassis Code:

👋 Introduction

Market Position

Positioning:

The Yamaha Fazer 600 (also known as the FZS600) was a popular middleweight sport-touring motorcycle, known for its versatility, comfort, and spirited performance.

Competitive Analysis

Competitors:

Competed with motorcycles like the Suzuki Bandit 600, Honda CB600F Hornet, and Kawasaki ZX-6R (in its more road-biased tune).

Key Features

Features:

Inline-four engine, comfortable ergonomics for longer rides, practical fairing for wind protection, balanced performance for both commuting and touring.

Manual Utility

Utility:

Essential resource for owners and technicians to perform maintenance, diagnostics, and repairs on the 2000 Yamaha Fazer 600, enabling self-sufficiency and cost savings.

📋 Manual Details

Coverage Areas

Primary Coverage:

Workshop Service Repair

Secondary Coverage:

Engine Overhaul, Chassis, Electrical System, Carburetors, Cooling System, Tuning, Troubleshooting

Page Count

Estimated Page Count:

Refer to actual PDF content; typically 300-500 pages for this era and scope.

Manual Type

Type:

Workshop Service Manual / Repair Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Engine:

Detailed overhaul procedures, component identification, timing, lubrication, cooling system integration.

Fuel System:

Carburetor assembly, disassembly, cleaning, adjustment, synchronization, fuel pump, fuel lines.

Electrical System:

Wiring diagrams, component testing (ignition, starter, lighting, charging), troubleshooting electrical faults.

Chassis:

Frame, suspension (front forks, rear shock), steering, wheel bearings, brake system overhaul (front and rear).

Cooling System:

Radiator, coolant flow, fan operation, thermostat, coolant capacity and specifications.

Procedures Included

Maintenance:

Periodic inspections, lubrication points, filter replacement, chain adjustment, tire pressure.

Repair:

Component replacement, engine rebuild, suspension repair, brake caliper service, electrical component repair.

Troubleshooting:

Diagnostic charts for common problems, symptom-based troubleshooting guides.

Tuning:

Carburetor jetting, ignition timing adjustments (if applicable), general performance tuning advice.

Technical Depth

Depth:

Comprehensive, from basic adjustments to complete engine and chassis disassembly/reassembly.

📊 Manual Specifications

File Format

File Type:

Searchability:

Fully searchable text within the PDF for quick information retrieval.

Print Quality

Quality:

High-resolution scans suitable for printing and clear viewing of diagrams and text.

Binding Type

Binding:

Digital (PDF) - No physical binding required.

Paper Type

Paper:

Digital (PDF) - No physical paper type.

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, liquid-cooled, DOHC, inline-four

Displacement:

599 cc

Bore X Stroke:

62.0 mm x 49.6 mm

Compression Ratio:

12.2:1

Performance

Horsepower:

Approximately 95-98 hp @ 12,000 rpm (claimed, depending on market)

Torque:

Approximately 64 Nm (47 lb-ft) @ 10,000 rpm (claimed, depending on market)

Fuel System

Carburetion:

Four 37mm Mikuni CV carburetors

Fuel Capacity:

19 Liters (5.0 US gal)

Ignition

Ignition System:

Digital TCI (Transistor Controlled Ignition)

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Clutch:

Wet, multiple disc

Final Drive:

O-ring sealed chain

Features

Gear Ratios:

Refer to manual for specific gear ratios.

Transmission Fluid Spec:

Yamalube 10W-40 or equivalent API SG, JASO MA

📐 Dimensions

Exterior

Length:

2,105 mm (82.9 in)

Width:

770 mm (30.3 in)

Height:

1,215 mm (47.8 in)

Wheelbase:

1,435 mm (56.5 in)

Weights

Dry Weight:

189 kg (417 lbs)

Wet Weight:

Approximately 211 kg (465 lbs) (with fluids)

Wheels Tires

Front Tire:

120/70ZR17M/C (58W)

Rear Tire:

170/60ZR17M/C (72W)

Suspension

Front Suspension:

Telescopic forks, coil spring, oil damped, 130 mm travel

Rear Suspension:

Swingarm, coil spring, oil damped, preload adjustable, 135 mm travel

🛡️ Safety Features

Ratings

Safety Ratings:

N/A for motorcycles in typical automotive crash safety rating systems. Focus on component integrity and design.

Active Features

Brakes Front:

Dual 298mm discs, 4-piston calipers

Brakes Rear:

Single 245mm disc, 2-piston caliper

Passive Features

Lighting:

Halogen headlamp, LED tail lamp

Frame Construction:

Steel diamond frame

💡 Technology Features

Infotainment

Infotainment System:

Not applicable. Basic analogue instrumentation.

Driver Assistance

Driver Assistance Features:

Not applicable. No electronic rider aids.

Connectivity

Connectivity Options:

Not applicable.

Engine Management

Engine Management System:

TCI ignition system, carbureted fuel delivery. Manual covers tuning adjustments for optimal performance.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 4,000-6,000 km (2,500-3,700 miles) or 6 months, whichever comes first. Consult manual for precise interval.

Air Filter Check Interval:

Every 8,000-12,000 km (5,000-7,500 miles). Replacement based on condition.

Spark Plug Replacement Interval:

Every 16,000-24,000 km (10,000-15,000 miles). Consult manual for specific type and gap.

Chain Maintenance Interval:

Lubricate and adjust chain every 800-1,000 km (500-620 miles).

Fluid Specifications

Engine Oil Type:

Yamalube 4 (10W-40) or equivalent API SG, JASO MA certified.

Coolant Type:

High-quality ethylene glycol based coolant with corrosion inhibitors. 50% solution with distilled water. Refer to manual for specific Yamaha coolant.

Brake Fluid Type:

DOT 4

Known Issues

Common Issues:

Occasional carburation issues due to sync or cleaning needs, regulator/rectifier failures (common on many bikes of this era), potential rear shock absorber wear over time.

Troubleshooting Focus:

The manual addresses these common issues with detailed diagnostic steps and repair procedures.

📚 Vehicle History

Brand Heritage

Brand Heritage:

Yamaha Motor Company, established in 1955, has a rich history in motorcycle manufacturing, known for innovation, performance, and reliability across various segments.

Model Evolution

Fazer 600 Evolution:

The FZS600 Fazer was introduced in 1998, evolving from the Yamaha FZR600R and XJ600 Diversion. The 2000 model represents the initial generation of this successful sport-tourer, characterized by its practical fairing and versatile performance.

Production

Production Location:

Japan

Production Years:

1998-2003 (First Generation), succeeded by the FZS600S and later the FZ6.

🏆 Awards & Recognition

Recognitions

Industry Recognition:

The FZS600 Fazer was highly regarded in motorcycle publications for its value, performance, and versatility, often receiving positive reviews for its balanced capabilities as a sport-tourer.

Ratings

Owner Satisfaction:

Generally high owner satisfaction due to its reliability and practical nature. The manual is key to maintaining this.

Certifications

Certification Standard:

Manual adheres to standard automotive repair documentation practices.
