Yamaha FZR400 FAZER Shop Manual 1986-1990

Prix habituel: $16.99
Prix soldé: $16.99
Prix habituel
Prix unitaire: par

20 people are viewing this right now

Taper: Motorcycle

Distributeur:

UGS: 150289

Mots clés: 1986 1987 1988 1989 1990 FAZER FZR400 Motorcycle Motorcycles Yamaha

Variantes de produits

Description

The FZR400 Fazer is a performance-oriented sportbike from the 1980s, produced between 1986 and 1990. This model, likely including variants such as the FZR400R and FZR400RR, features a compact 399cc inline-four cylinder engine, known for its responsive power delivery and high-revving characteristics. Its engineering emphasizes agile handling and sporty ergonomics, making it a popular choice for riders seeking an engaging and dynamic riding experience. The heritage in developing innovative and reliable motorcycles is evident in the FZR400’s design, which contributed to the strong reputation in the middleweight sportbike segment. This comprehensive shop manual provides detailed information for the maintenance, repair, and troubleshooting of the FZR400 Fazer models from 1986 to 1990. It covers all major systems, including the engine, fuel system, ignition, transmission, brakes, suspension, and electrical components. The manual offers step-by-step procedures for routine maintenance, component overhauls, and advanced diagnostics, along with essential technical specifications, torque values, and fluid recommendations. This resource is an indispensable tool for owners and technicians aiming to preserve the performance, reliability, and longevity of their FZR400.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

FZR400 Fazer

Model Designation:

FZR400R / FZR400RR (depending on market and specific sub-model)

Product Name:

Yamaha FZR400 FAZER Shop Manual 1986-1990

Codes

Model Codes Covered:

Likely includes 1WG, 3KF, 3TJ variants.

👋 Introduction

Market Position

Positioning:

Performance-oriented sportbike in the 400cc class, aimed at riders seeking agility and responsive handling.

Target Audience:

Enthusiast riders, DIY mechanics, aspiring motorcycle technicians.

Competitive Analysis

Competitors:

Honda CBR400RR, Suzuki GSX-R400, Kawasaki ZXR400 (in markets where these were prevalent).

Key Features Vehicle

Features:

Compact 400cc four-cylinder engine, advanced chassis design for its era, sporty ergonomics, capable of spirited riding.

Key Features Manual

Benefits:

Empowers owners to perform maintenance and repairs, saving significant costs compared to dealership services. Provides in-depth technical understanding.

Value Proposition

Manual Value:

Essential tool for maintaining the longevity and performance of the FZR400, crucial for preserving its value.

📋 Manual Details

Coverage Areas

Year Coverage:

1986, 1987, 1988, 1989, 1990

Geographic Coverage:

Global (assumed, as service manuals typically aim for broad applicability, though regional variations may exist).

Page Count

Estimated Page Count:

Comprehensive (typically 300-600+ pages for a full shop manual).

Manual Type

Type:

Shop Manual / Service Manual / Repair Manual

Language

Language:

English (implied by product description context, standard for technical manuals).

Format

Format:

Digital Download (PDF, compatible with PC, MAC, Tablets & Smartphones)

📖 Manual Coverage

Systems Covered

Engine:

Complete engine disassembly, assembly, inspection, tuning, and component diagnosis (cylinder head, pistons, crankshaft, valve train, lubrication system, cooling system).

Fuel System:

Carburetor overhaul and adjustment (likely Mikuni CV units), fuel tank, fuel pump, fuel lines, fuel filter.

Ignition System:

CDI, ignition coils, spark plugs, timing checks, troubleshooting.

Transmission:

Gearbox disassembly, inspection, assembly, clutch operation, gear selection mechanism.

Chassis Frame:

Frame inspection, steering head bearing service, general chassis components.

Suspension:

Front fork (telescopic) disassembly, seal replacement, oil specification, rear shock absorber (monoshock) overhaul and adjustment.

Brakes:

Front and rear disc brake systems, caliper overhaul, brake pad replacement, master cylinder service, brake fluid specifications, bleeding procedures.

Electrical System:

Wiring diagrams, lighting system, battery, charging system (alternator, rectifier/regulator), starter motor, fuses, relays, instrumentation, switches.

Cooling System:

Radiator, cooling fan, thermostat, water pump, coolant specifications, flushing procedures.

Exhaust System:

Exhaust pipe and silencer inspection, potential for emissions control system details.

Bodywork Fittings:

Fairing removal and installation, seat, fuel tank mounting, minor body panel adjustments.

Procedures Included

Maintenance:

Routine checks, lubrication points, filter changes, spark plug replacement, chain adjustment, brake fluid changes, coolant changes.

Troubleshooting:

Systematic diagnosis of common problems, fault finding charts, electrical symptom diagnosis.

Repair Overhaul:

Detailed step-by-step instructions for component disassembly, repair, reassembly, and adjustment.

Technical Specifications:

Torque values for critical fasteners, clearances, tolerances, fluid capacities, electrical specifications.

Component Inspection:

Guidance on checking wear and tear on engine internals, transmission parts, suspension components, and brake system parts.

Technical Depth

Depth:

Comprehensive (from basic user maintenance to complete engine rebuilds and complex electrical diagnostics).

Diagnostic Capabilities:

Advanced diagnostic procedures, including electrical troubleshooting with multimeter usage and interpretation of symptoms.

Rebuild Procedures:

Detailed instructions for rebuilding major components like the engine, transmission, and carburetors.

📊 Manual Specifications

File Format

Type:

Digital Download (e.g., PDF)

Searchability:

Likely text-searchable if a well-produced digital document.

Print Quality

Quality:

Professional digital reproduction (implies clear diagrams and text).

Binding Type

Type:

Not Applicable (Digital Download)

Paper Type

Type:

Not Applicable (Digital Download)

⚙️ Engine Specifications

Primary Engine

Type:

4-stroke, DOHC, inline-four cylinder

Displacement:

399 cc (approximate, actual may vary slightly by sub-model)

Bore X Stroke:

Typically around 57.0 mm x 39.2 mm

Compression Ratio:

Around 11.5:1 to 12.0:1

Performance

Horsepower:

Approximately 53-60 PS (39-44 kW) at 11,000-12,000 RPM (market dependent, often restricted in some regions).

Torque:

Approximately 37-40 Nm (27-30 lb-ft) at 10,000-11,000 RPM.

Fuel System

Carburetion:

4 x Mikuni constant velocity (CV) carburetors (e.g., VM29 or similar).

Fuel Type:

Unleaded gasoline (RON 91 or higher recommended).

Cooling System

Type:

Liquid-cooled

🔧 Transmission

Standard

Type:

6-speed constant mesh, sequential return

Final Drive:

O-ring sealed chain

Features

Clutch Type:

Wet, multiple-disc, cable-actuated

Gear Ratios:

Specific ratios detailed in the manual, crucial for performance tuning.

📐 Dimensions

Exterior

Length:

Approx. 2,000 - 2,050 mm

Width:

Approx. 720 - 750 mm

Height:

Approx. 1,120 - 1,160 mm

Wheelbase:

Approx. 1,370 - 1,390 mm

Weights

Dry Weight:

Approx. 160 - 170 kg

Wet Weight:

Approx. 175 - 185 kg (with all fluids)

Fuel Capacity:

Approx. 16 liters

🛡️ Safety Features

Ratings

Safety Certification:

Compliant with relevant safety standards of its era (e.g., ADR for Australia, DOT for US, etc. - specific details depend on market).

Active Features

Braking System:

Dual front disc brakes, single rear disc brake. ABS was not common in this class at this time.

Handling:

Designed for agile handling, featuring a balanced chassis and suspension setup.

Passive Features

Lighting:

Halogen headlight, tail light, turn signals.

💡 Technology Features

Infotainment

Features:

Basic analog instrumentation: speedometer, tachometer, odometer, trip meter, engine temperature gauge, indicator lights.

Driver Assistance

Features:

None (this is a 1980s sportbike; electronic rider aids were not present).

Connectivity

Features:

None (analog electrical system).

🔧 Maintenance

Service Intervals

Oil Change:

Every 3,000 - 5,000 km or 6 months, whichever comes first.

Spark Plugs:

Inspect every 5,000 km, replace as needed (typically every 10,000-15,000 km).

Chain Lubrication Adjustment:

Lubricate every 500 km, adjust tension as needed to maintain 20-30mm free play.

Valve Clearance Check:

Every 10,000 - 15,000 km (critical for engine health).

Fluid Specifications

Engine Oil:

Yamaha recommends Yamalube 4 (or equivalent) 10W-40 API SE or SF. Check manual for precise SAE viscosity based on ambient temperature.

Coolant:

50% Ethylene Glycol based coolant and 50% distilled water. Use a high-quality motorcycle-specific coolant.

Brake Fluid:

DOT 3 or DOT 4 brake fluid (check manual for specific recommendation).

Fork Oil:

Yamaha Suspension Fluid (or equivalent) SAE 10W (capacity per leg typically 460-480cc - verify in manual).

Known Issues

Common Problems:

Carburetor synchronization drift, aging rubber fuel lines, potential wear in the valve train at higher mileage, suspension seal leaks.

Electrical Issues:

Corroded connectors, faulty rectifier/regulator units, worn starter motor brushes can be common with age.

Engine Wear:

Cam chain tensioner wear, potential for carbon buildup in combustion chambers affecting performance.

📚 Vehicle History

Brand Heritage

Heritage:

Yamaha has a long history of producing high-performance motorcycles, known for innovation in engine technology and chassis design.

Model Evolution

Evolution:

The FZR400 line represented Yamaha's entry and evolution in the competitive 400cc supersport segment, evolving from earlier models like the FZ400R.

Production

Production Years:

The FZR400 model series spanned several generations, with the 1986-1990 period covering key iterations like the 1WG and 3TJ models.

Manufacturing Location:

Japan (Yamaha's primary manufacturing base for motorcycles).

🏆 Awards & Recognition

Recognitions

Reputation:

Highly regarded in its class for its handling, engine characteristics, and reliability when properly maintained. Often praised for its 'baby supersport' appeal.

Historical Impact:

Contributed to Yamaha's reputation for building potent and exciting motorcycles in the middleweight sportbike category.
