Now Yamaha FZS1000 FZS 1000 Fazer 01-03 Service Repair Workshop Manual

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

20 people are viewing this right now

Typ: Motorcycle

Anbieter:

Art.-Nr: 123632

Stichworte: 2001 2002 2003 Fazer FZS 1000 FZS1000 Motorcycle Motorcycles Yamaha

Produktvarianten

Beschreibung

The FZS1000 Fazer, also known by its model nickname FZS1000, is a distinguished sport-touring motorcycle that graced the market from 2001 to 2005. Engineered with a potent inline four-cylinder engine derived from the renowned YZF-R1, this model offers impressive power and performance, suitable for both spirited riding and long-distance touring. Its design emphasizes rider comfort and aerodynamic efficiency through a full fairing, complemented by a sportbike-derived chassis tuned for stability. The FZS1000 Fazer is celebrated for its blend of exhilarating performance, practical comfort, and hallmark engineering quality and reliability, making it a compelling choice for discerning riders. This comprehensive Service Repair Workshop Manual for the FZS1000 Fazer (chassis code RN04) covers models from 2001, 2002, and 2003. It provides detailed, step-by-step instructions for a wide array of maintenance and repair procedures, encompassing engine, transmission, chassis, steering, suspension, brakes, electrical systems, fuel system, cooling system, and bodywork. The manual also includes critical information on scheduled maintenance, troubleshooting, inspection guidelines, disassembly and assembly, and torque specifications. Its purpose is to equip owners, mechanics, and technicians with the knowledge necessary to maintain, diagnose, and repair the FZS1000 Fazer effectively, ensuring optimal performance and longevity.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

FZS1000 Fazer

Model Nickname:

FZS1000

Product Name:

Yamaha FZS1000 FZS 1000 Fazer 01-03 Service Repair Workshop Manual

Codes

Chassis Codes:

👋 Introduction

Market Position

Category:

Sport Touring Motorcycle

Target Audience:

Riders seeking a powerful, comfortable, and versatile motorcycle for long-distance touring and spirited riding

Competitive Analysis

Key Competitors:

Honda VFR800, Suzuki TL1000S (earlier models), Kawasaki ZRX1200R (different styling but similar power class)

Key Features

Engine Architecture:

Inline four-cylinder, liquid-cooled, DOHC engine derived from the YZF-R1

Handling Characteristics:

Sportbike-derived chassis tuned for stability and comfort on longer rides

Wind Protection:

Full fairing for improved aerodynamic efficiency and rider comfort

Value Proposition

Manual Utility:

Enables owners to perform a wide range of maintenance and repair tasks, saving on dealership labor costs.

Instant Access:

Immediate download eliminates shipping delays and allows for immediate use.

📋 Manual Details

Coverage Areas

Years Covered:

2001, 2002, 2003

Page Count

Estimated Page Count:

Estimated 400+ pages (based on typical factory service manuals for this class of motorcycle)

Manual Type

Manual Type:

Service Repair Workshop Manual

Language

Language:

English (assumed based on product description)

Format

Format:

Adobe Acrobat PDF

📖 Manual Coverage

Systems Covered

Engine:

Complete engine disassembly, assembly, inspection, tuning, and troubleshooting

Transmission:

Gearbox inspection, repair, clutch operation, and maintenance

Chassis:

Frame, sub-frame, swingarm, and related components

Steering:

Headstock bearings, fork assembly, steering adjustments

Suspension:

Front telescopic forks (including damping and spring adjustments), rear monoshock absorber, linkage system

Brakes:

Front and rear brake systems, hydraulic lines, calipers, master cylinders, disc inspection, bleeding procedures

Electrical:

Wiring diagrams, lighting system, ignition system, charging system, starter motor, fuses, relays, battery service

Fuel System:

Carburetor assembly, fuel pump, fuel filter, fuel tank maintenance

Lubrication:

Oil change procedures, oil filter replacement, oil type specifications, lubrication points

Cooling System:

Radiator, cooling fan, coolant type and capacity, thermostat, water pump

Exhaust System:

Exhaust pipe, muffler inspection, gasket replacement

Bodywork:

Fairing removal and installation, seat system, lock systems

Procedures Included

Maintenance:

Scheduled maintenance tasks, lubrication, fluid changes, filter replacement, spark plug checks

Troubleshooting:

Diagnostic procedures for common and uncommon issues, fault finding charts

Repair:

Detailed step-by-step repair instructions for all major components and systems

Inspection:

Component inspection guidelines, wear limits, and specifications

Disassembly Assembly:

Complete teardown and reassembly procedures for engine, transmission, suspension, etc.

Torque Specifications:

Precise torque values for all critical fasteners

Technical Depth

Diagnostic Capabilities:

Advanced diagnostic procedures, electrical system testing, and fuel system calibration

Rebuild Procedures:

Full engine and transmission rebuild instructions

Special Tools:

Identification of necessary special tools for specific procedures

📊 Manual Specifications

File Format

File Format:

Searchable Text:

Likely searchable text for ease of use

Print Quality

Print Quality:

High resolution, suitable for printing clear diagrams and text

Binding Type

Binding Type:

Digital (user printable for binding in 3-ring binders)

Paper Type

Paper Type:

N/A (Digital product)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 4-stroke, DOHC, 5 valves per cylinder, inline-four

Displacement:

998 cc (61 cu in)

Bore X Stroke:

74.0 mm x 58.0 mm

Compression Ratio:

11.4:1

Performance

Horsepower:

Approx. 140-145 HP (claimed, at crankshaft)

Torque:

Approx. 76-78 ft-lbs (claimed, at crankshaft)

Fuel System

Fuel Delivery:

Carburetor (4 x Mikuni BST37 or similar) with Accelerator Pump and Exhaust Control Induction System (EXUP)

Fuel Capacity:

21 liters (5.5 US gal)

Ignition

Ignition System:

TCI (Transistor Controlled Ignition)

Lubrication

Oil Capacity:

4.6 Liters (5.0 US qt) with filter change; 4.3 Liters (4.5 US qt) without filter change

Recommended Oil Type:

Yamalube 4, SAE 10W-40 or 20W-50 API SG, SH, SJ, SL or higher

🔧 Transmission

Standard

Transmission Type:

6-speed, constant mesh

Clutch Type:

Wet, multiple disc

Features

Final Drive:

O-ring sealed chain

Fluid Specifications

Transmission Oil:

Yamalube Gear Oil, SAE 80 API GL-4 (or equivalent)

📐 Dimensions

Exterior

Length:

2,165 mm (85.2 in)

Width:

780 mm (30.7 in)

Height:

1,240 mm (48.8 in)

Wheelbase:

1,495 mm (58.9 in)

Weights

Dry Weight:

214 kg (472 lbs)

Wet Weight:

Approx. 245 kg (540 lbs) (fully fueled)

Front Tire Size:

120/70 ZR17M/C (58W)

Rear Tire Size:

180/55 ZR17M/C (73W)

Wheel Type:

Cast aluminum

🛡️ Safety Features

Ratings

Safety Features Note:

As a motorcycle, safety ratings (like automotive crash tests) are not directly applicable. Focus is on rider protection and vehicle dynamics.

Active Features

Braking System:

Dual 298 mm discs with 4-piston calipers (front), Single 267 mm disc with 2-piston caliper (rear)

Suspension Stability:

Adjustable suspension for optimal handling and stability

Passive Features

Lighting:

Halogen headlights, LED taillight

💡 Technology Features

Infotainment

Instrument Cluster:

Analog tachometer, digital speedometer, fuel gauge, clock, odometer, trip meters, indicator lights

Driver Assistance

Power Delivery Enhancement:

EXUP (Exhaust Ultimate Power) valve system in the exhaust for improved torque at lower RPMs and power delivery across the rev range.

Connectivity

Connectivity Features:

N/A (Motorcycle of this era did not feature Bluetooth or advanced electronic rider aids beyond basic ignition and fueling)

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 5,000 - 6,000 km (3,000 - 3,700 miles) or 6 months

Air Filter Cleaning Interval:

Every 5,000 - 6,000 km (3,000 - 3,700 miles)

Spark Plug Replacement Interval:

Every 10,000 - 12,000 km (6,000 - 7,500 miles)

Valve Clearance Check Interval:

Every 20,000 - 24,000 km (12,000 - 15,000 miles)

Fluid Specifications

Coolant Type:

Yamaha's Genuine Coolant (or equivalent ethylene glycol-based coolant with corrosion inhibitors), mix ratio 50:50 with distilled water

Brake Fluid Type:

DOT 4

Known Issues

Common Wear Items:

Clutch plates, chain and sprockets, brake pads, fork seals

Potential Carburetor Issues:

Carburetor synchronization can drift over time, potentially affecting smooth running and fuel economy. Idle adjustment may be needed.

Electrical System:

While generally robust, battery connections and grounds should be kept clean and tight. Age-related component failure is possible.

Part Numbers

Oil Filter Part Number:

Yamaha 3YX-13440-00-00 (or equivalent aftermarket filters)

Air Filter Part Number:

Yamaha 5DM-14451-00-00 (or equivalent aftermarket filters)

Spark Plug Part Number:

NGK CR9E (or equivalent)

📚 Vehicle History

Brand Heritage

Manufacturer Origin:

Japan

Model Evolution

Introduction Year:

Platform Basis:

Leveraged the powerful engine and chassis technology from the Yamaha YZF-R1

Facelifts Updates:

Minor updates throughout its production run, including color schemes and some component refinements.

Production

Production Years:

2001 - 2005 (globally)

🏆 Awards & Recognition

Recognitions

Market Reception:

Praised for its potent engine performance, comfortable riding position, and capable handling, making it a strong contender in the sport-touring segment.
