Jaguar XK120 XK140 XK150 Complete Workshop Service Repair Manual 1948 1949 1950 1951 1952 1953 1954 1955 1956 1957 1958 1959 1960 1961

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

28 people are viewing this right now

Typ: Car

Anbieter:

Art.-Nr: 154852

Stichworte: 1948 1949 1950 1951 1952 1953 1954 1955 1956 1957 1958 1959 1960 1961 Car Cars Jaguar XK XK120 XK140 XK150

Produktvarianten

Beschreibung

This comprehensive workshop service repair manual covers the Jaguar XK Series, encompassing the XK120, XK140, and XK150 models produced between 1948 and 1961. These iconic British sports cars, powered by the renowned Jaguar XK engine in 3.4L and 3.8L configurations, are celebrated for their exceptional performance, elegant design, and motorsport heritage. The manual details various body styles, including the Open Two-Seater, Drophead Coupe, and Fixed Head Coupe, and provides essential information for maintaining and repairing all engine variants, trim levels, and transmission types, including the distinctive Moss gearbox. This manual serves as an authoritative guide for owners and mechanics alike, offering in-depth coverage of all essential vehicle systems. It provides detailed procedures for routine maintenance, engine overhaul, transmission and clutch repair, brake system servicing, suspension and steering adjustments, and electrical system troubleshooting. With step-by-step instructions, diagnostic guides for common issues, and technical specifications, this resource is designed to facilitate accurate and efficient maintenance and repair, ensuring the longevity and optimal performance of your Jaguar XK Series vehicle.

🏷️ Basic Information

Identification

Make:

Jaguar

Model:

XK120, XK140, XK150

Common Name:

Jaguar XK Series

Codes

Chassis Codes:

XK120 (from 1948), XK140 (from 1954), XK150 (from 1957)

👋 Introduction

Market Position

Target Audience:

Owners and mechanics of Jaguar XK120, XK140, and XK150 classic sports cars, aiming to perform maintenance and repairs themselves or understand service procedures.

Competitive Analysis

Manual Value Proposition:

Offers significant cost savings for owners by enabling DIY repairs, providing authoritative technical guidance, and ensuring correct procedures are followed.

Key Features

Ease Of Use:

Designed for ease of use with step-by-step instructions and photographic or diagrammatic representations of procedures.

Accessibility:

Accessible on multiple devices (PC, Mac, tablets, smartphones), offering flexibility for users in different locations.

📋 Manual Details

Coverage Areas

Models Covered:

All XK120, XK140, and XK150 models, including all engine variants, trim levels, and transmission types.

Years Covered:

1948, 1949, 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961

Page Count

Estimated Page Count:

Comprehensive, typically hundreds of pages for a complete workshop manual of this era. Specific count not provided but implied to be exhaustive.

Manual Type

Type:

Complete Workshop Service Repair Manual

Language

Language:

English (presumed, standard for official Jaguar manuals of this era)

Format

Format:

Downloadable Digital File (PDF)

📖 Manual Coverage

Systems Covered

Engine:

Complete engine overhaul, tuning, lubrication, cooling system, fuel system (including carburettors), ignition system.

Transmission:

Manual transmission (Moss gearboxes, specific variations), clutch, driveshaft, rear axle and differential.

Brakes:

Hydraulic brake system (front disc, rear drum), parking brake, brake fluid specifications.

Suspension:

Front independent suspension (wishbones, torsion bars), rear leaf spring suspension, shock absorbers, steering.

Electrical:

Wiring diagrams, lighting system, ignition system, starting system, charging system (generator), instrumentation, accessory circuits.

Bodywork:

Chassis lubrication, body panel adjustments, door mechanisms, convertible top (if applicable), trim.

Procedures Included

Maintenance:

Routine servicing, oil changes, filter replacements, lubrication schedules, tune-ups.

Repair:

Complete disassembly and reassembly procedures for all major mechanical and electrical components.

Troubleshooting:

Diagnostic guides, common problems and their solutions, fault finding procedures.

Adjustments:

Carburettor tuning, ignition timing adjustments, valve clearance settings, brake adjustments.

Technical Depth

Depth:

Comprehensive workshop-level detail, suitable for professional mechanics and experienced enthusiasts. Includes internal component specifications and rebuild procedures.

📊 Manual Specifications

File Format

Format:

Searchability:

Likely text-searchable if a quality scan/OCR was performed, enabling quick information retrieval.

Print Quality

Printability:

Printable by chapter or in its entirety, allowing for physical reference in a workshop environment.

Binding Type

Binding:

N/A (Digital download)

Paper Type

Paper Type:

N/A (Digital download)

⚙️ Engine Specifications

Primary Engine

Xk120 Engine:

3.4L (3442cc) DOHC Inline-6 (Jaguar XK engine)

Xk120 Power Output:

Approx. 160-180 bhp (depending on specific tuning/variant)

Xk120 Torque:

Approx. 193-200 lb-ft (depending on specific tuning/variant)

Xk140 Engine:

3.4L (3442cc) DOHC Inline-6 (Jaguar XK engine), enhanced cylinder head and camshafts

Xk140 Power Output:

Approx. 190-210 bhp (depending on specific tuning/variant, e.g., XK140 MC)

Xk150 Engine:

3.4L (3442cc) DOHC Inline-6 (Jaguar XK engine), later models offered 3.8L (3781cc) variant

Xk150 Power Output (3.4L):

Approx. 210 bhp

Xk150 Power Output (3.8L):

Approx. 250 bhp (XK150 S model)

Fuel System

Carburettors:

Typically twin SU (H6 or HD6) or Zenith carburetors. Manual will cover adjustment and overhaul.

Fuel Type:

Leaded gasoline (e.g., 95 RON or higher, manual will specify octane requirements for original engines)

🔧 Transmission

Standard

Type:

4-speed manual transmission, notably the Moss gearbox (pre-synchromesh on first gear in early models).

Optional

Type:

Overdrive option available on some models (e.g., Laycock de Normanville).

Features

Gear Ratios:

Specific gear ratios for each model and transmission variant are covered in detail.

Transmission Fluid:

Manual will specify appropriate gear oil (e.g., EP 80 or similar).

📐 Dimensions

Exterior

Body Styles:

Open Two-Seater, Drophead Coupe, Fixed Head Coupe.

Wheelbase:

XK120: 102 inches (2591 mm), XK140/XK150: 104 inches (2642 mm)

Track Front:

Approx. 50 inches (1270 mm)

Track Rear:

Approx. 52 inches (1321 mm)

Weights

Curb Weight:

Approximately 2,800 - 3,200 lbs (1270 - 1450 kg) depending on body style and equipment.

🛡️ Safety Features

Ratings

Crash Safety:

No formal crash test ratings exist for this era of vehicle. Focus is on mechanical soundness and driver control.

Active Features

Braking System:

Hydraulically operated, front disc brakes (introduced on XK140), rear drum brakes. Manual covers system operation and maintenance.

Passive Features

Seat Belts:

Not standard equipment; manual may cover aftermarket installation procedures if documented by Jaguar for later periods or accessories.

💡 Technology Features

Infotainment

Features:

Basic analog instrumentation (speedometer, tachometer, oil pressure, water temperature, ammeter). No modern infotainment systems.

Driver Assistance

Features:

None. Focus is on driver engagement and mechanical feedback.

Connectivity

Features:

🔧 Maintenance

Service Intervals

Oil Change:

Typically every 3,000 miles or 6 months, though manual may recommend more frequent checks for classic vehicles. Details on engine oil and filter replacement.

Grease Points:

Regular lubrication of chassis grease points as per schedule in the manual (e.g., kingpins, steering joints, prop shaft UJ's).

Fluid Specifications

Engine Oil:

Manual will specify viscosity (e.g., SAE 20W-50) and type (likely mineral oil, with specific recommendations regarding zinc content for flat-tappet cams). Original specification may have been SAE 30 or 20W-30.

Coolant:

Water/glycol mixture. Manual will specify capacity and correct type of antifreeze.

Brake Fluid:

Typically DOT 3 or DOT 4 glycol-based fluid. Manual will specify correct type and bleeding procedures.

Known Issues

Engine Wear:

Oil consumption, potential wear in valve guides and bearings. Manual covers inspection and overhaul.

Cooling System:

Overheating due to radiator efficiency or water pump issues. Manual provides diagnostics for the cooling system.

Transmission Syncromesh:

Wear in Moss gearbox synchromesh rings (where applicable), leading to difficult gear changes. Manual details repairs and adjustments.

Electrical Gremlins:

Aging wiring, Lucas components can be temperamental. Detailed wiring diagrams are essential and are included.

📚 Vehicle History

Brand Heritage

Legacy:

Jaguar's post-war resurgence, building on motorsport success with the XK engine, establishing the brand's reputation for performance and luxury.

Model Evolution

Xk120:

Launched in 1948 as a concept, famed for its 120 mph top speed. Initially hand-built, later mass-produced.

Xk140:

Introduced in 1954 with improved chassis, rack-and-pinion steering, optional Laycock de Normanville overdrive, and standard front disc brakes. Minor styling updates.

Xk150:

Launched in 1957, featuring a significant restyling with a single-sweep windscreen, updated dashboard, and improved performance options, including the larger 3.8-liter engine.

Production

Production Period:

1948 - 1961 (across all XK models)

Production Volume:

Approximately 12,000+ units combined across XK120, XK140, and XK150 variants.

🏆 Awards & Recognition

Recognitions

Motorsport Heritage:

The XK engine and its derivatives powered many successful Jaguar race cars, including Le Mans winners. This manual provides the basis for maintaining such vehicles.

Ratings

Automotive Press Reviews:

Consistently praised for performance, handling, and beautiful design. Often cited as iconic British sports cars.

Certifications

Classic Status:

Highly regarded classic cars, eligible for numerous historic motoring events and concourse d'elegance.
