Polaris 1977 Colt 55 and 1977 Electra Service/Shop Repair Manual

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

This manual covers the 1977 Polaris Colt 55 and 1977 Polaris Electra snowmobiles. These models represent robust engineering from the late 1970s snowmobile market, built with a focus on utility...

17 people are viewing this right now

Typ: Snowmobile

Anbieter:

Art.-Nr: 154045

Stichworte: 1977 Colt 55 Electra Electra Models Polaris Powersports Snowmobile Snowmobiles

Produktvarianten

Beschreibung

This manual covers the 1977 Polaris Colt 55 and 1977 Polaris Electra snowmobiles. These models represent robust engineering from the late 1970s snowmobile market, built with a focus on utility and reliability. Polaris Industries, a pioneer in snowmobile manufacturing, produced these machines in the USA. The Colt series was known for its dependable performance, while the Electra often offered enhanced features. These snowmobiles are equipped with 2-stroke, fan-cooled, twin-cylinder engines, typically featuring an automatic clutch transmission with a belt drive and chain case. Their design prioritizes capability for recreational trail riding and utility in snow conditions. This comprehensive service and shop repair manual provides factory-level repair information for owners and technicians. It details maintenance procedures, troubleshooting guides, and technical specifications essential for keeping your 1977 Polaris snowmobile in optimal condition. Coverage includes engine systems, fuel and ignition systems, transmission and drive components, suspension and steering, braking, and the electrical system. Detailed instructions for routine servicing, repair, and overhaul of major components are included, supported by numerous illustrations. This manual is designed to empower users to perform their own maintenance and repairs, ensuring the longevity and performance of these vintage snowmobiles.
