Positioning:
High-performance sport touring motorcycle of its era, bridging the gap between pure sportbikes and touring machines.
Competitors:
Suzuki GSX-R series, Honda CBR series, Kawasaki Ninja series.
Features:
DOHC inline-four engine, advanced suspension for its time, aerodynamic fairing for improved comfort and stability at speed.
Value:
Essential for owners seeking to perform maintenance and repairs themselves, ensuring longevity and optimal performance. Provides factory-accurate procedures and specifications.
Primary Coverage:
Complete Service, Repair, and Maintenance for 1987 Yamaha Fazer (FZR1000)
Estimated Pages:
400-600 (typical for comprehensive service manuals of this era)
Type:
Factory Service Manual / Repair Manual
Format:
Printed (likely original factory publication or high-quality reproduction)
Engine:
Complete engine disassembly, assembly, inspection, and repair (including valve timing, piston/cylinder, crankshaft, lubrication system, cooling system).
Fuel System:
Carburetor service, adjustment, and troubleshooting; fuel pump operation; fuel tank maintenance.
Electrical System:
Ignition system (CDI, spark plugs, coils), lighting (headlight, tail light, indicators), charging system (stator, regulator/rectifier), battery, starter motor, wiring diagrams.
Transmission:
Clutch operation, gearbox disassembly and assembly, gear inspection, shift drum and fork service.
Chassis And Suspension:
Front fork overhaul, rear shock absorber service, swingarm and linkage maintenance, frame inspection.
Brakes:
Hydraulic brake system (front and rear), caliper overhaul, master cylinder service, brake fluid replacement, pad inspection and replacement.
Wheels And Tires:
Wheel bearing service, tire pressure recommendations, rim inspection.
Bodywork And Trim:
Fairing removal and installation, seat maintenance, minor body panel repairs.
Troubleshooting:
Diagnostic procedures for common issues, fault finding guides, symptom-based troubleshooting trees.
Routine Maintenance:
Oil and filter changes, chain adjustment, air filter cleaning/replacement, spark plug replacement, brake fluid flush, coolant flush.
Major Repairs:
Engine rebuilds, gearbox overhauls, suspension component replacement, electrical system diagnosis and repair.
Component Adjustment:
Carburetor synchronization, valve clearance adjustment, clutch cable free play, throttle cable adjustment.
Diagnostic Procedures:
Using test equipment, checking electrical circuits, identifying engine performance issues.
Depth:
Comprehensive: Covers everything from basic fluid changes and adjustments to complete engine and transmission rebuilds, including detailed electrical troubleshooting and specifications.
Digital Format:
N/A (Primarily a printed manual)
Print Quality:
High (Original factory print quality expected, clear diagrams and text)
Binding:
Staple-bound or Perfect Bound (typical for factory manuals)
Paper Quality:
Durable paper stock, often with glossy pages for diagrams
Engine Type:
Liquid-cooled, 4-stroke, DOHC, 16-valve Inline-4
Bore X Stroke:
75.0 mm x 56.0 mm (typical for FZR1000 variants)
Compression Ratio:
10.0:1 (typical for FZR1000 variants)
Horsepower:
Approx. 135-145 hp @ 9,500 rpm (estimated for 1987 FZR1000)
Torque:
Approx. 70-75 lb-ft @ 8,000 rpm (estimated for 1987 FZR1000)
Carburetors:
Four 36mm Mikuni CV (Constant Velocity) carburetors
Fuel Tank Capacity:
Approx. 5.3 US gallons (19-20 Liters)
Ignition Type:
Digital CDI (Capacitor Discharge Ignition)
Cooling Method:
Liquid-cooled
Oil Type:
Yamalube 4 (or equivalent SAE 20W-40 API SG or higher motorcycle oil)
Oil Capacity:
Approx. 3.5 - 4.0 US quarts (3.3 - 3.8 Liters) with filter change
Valve Lash Intake:
0.08 - 0.13 mm (0.003 - 0.005 in)
Valve Lash Exhaust:
0.13 - 0.18 mm (0.005 - 0.007 in)
Transmission Type:
6-speed constant mesh
Clutch Type:
Wet, multi-disc, diaphragm spring
Final Drive:
O-ring sealed chain
Gear Ratios:
Provided in manual for detailed analysis (e.g., 1st: 2.500, 2nd: 1.875, 3rd: 1.458, 4th: 1.238, 5th: 1.083, 6th: 1.000 - typical for FZR1000)
Transmission Oil Type:
API GL-4 SAE 75W-90 hypoid gear oil (or as specified in manual)
Overall Length:
Approx. 2170 mm (85.4 in)
Overall Width:
Approx. 760 mm (29.9 in)
Overall Height:
Approx. 1190 mm (46.9 in)
Wheelbase:
Approx. 1470 mm (57.9 in)
Dry Weight:
Approx. 228 kg (503 lbs) (typical for FZR1000)
Wet Weight:
Approx. 245 kg (540 lbs) (estimated with fluids)
Safety Features:
Not applicable in the same way as automobiles; focus is on rider aids and chassis stability.
Braking System:
Dual front disc brakes with 4-piston calipers, single rear disc brake.
Suspension Geometry:
Designed for stability at high speeds and confidence in cornering.
Lighting:
Halogen headlight, taillight, brake light, turn signals.
Oil Change Interval:
Every 3,000 miles or 6 months (typical recommendation)
Filter Change Interval:
With every oil change
Valve Clearance Check:
Every 6,000 - 12,000 miles (refer to manual for exact interval and specific checks)
Brake Fluid Flush:
Every 12,000 miles or 2 years
Coolant Type:
Yamaha Coolant (or equivalent mixture of ethylene glycol-based antifreeze and distilled water)
Brake Fluid Type:
DOT 3 or DOT 4 hydraulic brake fluid
Common Wear Items:
Clutch wear, carburetor synchronization drift, fork seal leaks, charging system components (stator/regulator) can be prone to failure over time.
Carburetor Issues:
Can become clogged with age and disuse, requiring thorough cleaning and synchronization.
Chain Maintenance:
Regular cleaning, lubrication, and adjustment are crucial for drivetrain longevity.
Heritage:
Yamaha's reputation for building high-performance, reliable motorcycles with innovative technology.
Fzr Lineage:
The FZR1000 was a flagship model for Yamaha, introducing advanced technologies like the EXUP valve in later iterations and setting benchmarks for sportbike performance in the late 80s.
Production Era:
The 1987 model year falls within the early generation of the FZR1000, which was a significant model in Yamaha's lineup.
