Honda Vfr750f 1990-1996 Service Repair Manual

Normaler Preis
$16.99
Verkaufspreis
$16.99
Normaler Preis
The Honda VFR750F, produced from 1990 to 1996, represents the second generation (RC36) of Honda's renowned sport-touring motorcycle. Known for its sophisticated engineering, this model features a powerful 748cc 90-degree...
20 people are viewing this right now
Typ: Motorcycle
Anbieter:
Art.-Nr: 104810
Honda Vfr750f 1990-1996 Service Repair Manual
The Honda VFR750F, produced from 1990 to 1996, represents the second generation (RC36) of Honda's renowned sport-touring motorcycle. Known for its sophisticated engineering, this model features a powerful 748cc 90-degree V4 liquid-cooled engine, a 6-speed manual transmission, and a distinctive Pro-Arm single-sided swingarm on later iterations. The VFR750F was celebrated for its balanced performance, comfortable ergonomics, and exceptional reliability, making it a versatile machine equally suited for spirited riding and long-distance touring. Its design philosophy emphasized a blend of sportbike capabilities with touring comfort, setting a high standard in its class and earning consistent praise from motorcycle publications for its build quality and performance. This comprehensive service and repair manual in English provides detailed guidance for the Honda VFR750F models (RC30, RC36) from 1990 through 1996. It covers all essential aspects of maintenance, troubleshooting, and repair, including in-depth procedures for the engine, fuel system, transmission, cooling system, brakes, suspension, and electrical systems. The manual includes factory maintenance schedules, diagnostic procedures for common issues, and step-by-step instructions for component removal and installation, such as clutch and gearbox service. With abundant illustrations, diagrams, and high-resolution content suitable for printing, this manual is an indispensable resource for owners, mechanics, and technicians seeking to maintain and preserve the optimal performance and longevity of their VFR750F.
🏷️ Basic Information
Identification
Make:
Honda
Model:
VFR750F
Product Name:
Honda VFR750F 1990-1996 Service Repair Manual
Codes
Model Codes Covered:
RC30, RC36
Generation
Generation:
Second Generation (RC36)
👋 Introduction
Market Position
Market Segment:
Sport touring motorcycle, known for its V4 engine, comfortable ergonomics, and sophisticated engineering. Positioned as a premium, reliable, and versatile sportbike.
Competitive Analysis
Competitors:
Competed against other high-performance sportbikes and sport-touring machines of its era, such as Yamaha FZR1000, Kawasaki ZZR1100, Suzuki GSX-R1100, and BMW K-series models.
Key Features
Design Philosophy:
Emphasized a balance of performance, comfort, and reliability. Notable for its unique Pro-Arm single-sided swingarm (on later models), V4 engine configuration, and advanced (for its time) chassis design.
📋 Manual Details
Coverage Areas
Covered Years:
1990, 1991, 1992, 1993, 1994, 1995, 1996
Page Count
Estimated Page Count:
Extensive (Exact count not specified, but described as comprehensive and detailed, implying hundreds of pages typical for factory service manuals).
Manual Type
Manual Type:
Service and Repair Manual
Language
Language:
English
Format
Format:
Digital Download (PDF)
📖 Manual Coverage
Systems Covered
Engine:
Complete engine service, engine firing order, timing chain service, clutch removal and installation.
Fuel System:
Fuel system service, carburetor overhaul/tuning (for applicable models).
Transmission Drivetrain:
Gearbox service, removal and installation, transmission details, driveshaft service.
Cooling System:
Cooling system service, radiator, fan, hoses, thermostat.
Exhaust System:
Exhaust system service and repair.
Suspension Steering:
Front suspension, suspension service, repair, and adjustment.
Brakes:
Brake servicing procedures, front and rear brake systems, hydraulics.
Electrics Electronics:
Wiring diagrams, electrical system diagnostics, charging system, ignition system.
Bodywork Chassis:
Bodywork repair, panels, fairings, frame inspection.
Procedures Included
Maintenance:
Factory maintenance schedules, routine servicing, fluid changes, filter replacements.
Troubleshooting:
Fault finding, diagnostic procedures for common issues.
Repair Rebuild:
Factory repair procedures, complete engine rebuild, transmission overhaul, component replacement.
Installation Removal:
Component removal and installation procedures (e.g., clutch, gearbox).
Technical Depth
Depth Of Coverage:
Comprehensive, covering everything from basic maintenance to complete engine and transmission rebuilds, including detailed diagnostics and factory repair procedures.
📊 Manual Specifications
File Format
File Format:
PDF
Print Quality
Print Quality:
High-resolution, suitable for printing. Contains abundant illustrations, lots of pictures, and diagrams.
Binding Type
Binding Type:
N/A (Digital format)
Paper Type
Paper Type:
N/A (Digital format)
⚙️ Engine Specifications
Primary Engine
Engine Type:
90-degree V4, DOHC, 16-valve
Displacement:
748cc
Bore X Stroke:
70.0 mm x 48.6 mm
Compression Ratio:
10.5:1
Cooling System:
Liquid-cooled
Performance
Horsepower Peak:
Approx. 98 hp @ 10,500 rpm (varies slightly by year and market)
Torque Peak:
Approx. 52 lb-ft @ 8,000 rpm (varies slightly by year and market)
Fuel System
Fuel Delivery:
Four 36mm Keihin carburetors (CV type for most of this generation).
Fuel Capacity:
4.8 US gallons (18.2 L)
Engine Firing Order
Firing Order:
1-3-4-2
🔧 Transmission
Standard
Transmission Type:
6-speed manual constant mesh
Features
Final Drive:
O-ring sealed chain
Clutch Type:
Hydraulically operated, wet multi-plate
📐 Dimensions
Exterior
Length:
Approx. 2,150 mm (84.6 in)
Width:
Approx. 750 mm (29.5 in)
Height:
Approx. 1,160 mm (45.7 in)
Wheelbase:
Approx. 1,475 mm (58.1 in)
Weights
Dry Weight:
Approx. 207 kg (456 lbs)
Wet Weight:
Approx. 230 kg (507 lbs)
Max Load:
Typically around 400 lbs rider + passenger + luggage.
🛡️ Safety Features
Ratings
Safety Features Available:
Optional Combined Braking System (CBS) with linked front and rear brakes on some models. Anti-dive front forks designed to reduce brake dive.
Active Features
Active Safety:
Effective disc brakes front and rear, responsive chassis, good rider visibility.
Passive Features
Passive Safety:
Robust frame construction, designed for stability.
💡 Technology Features
Infotainment
Infotainment System:
Not applicable for this era of motorcycle. Focus is on mechanical and electrical systems.
Driver Assistance
Driver Assistance Features:
Optional Combined Brake System (CBS) on some international models. Anti-dive front forks.
Connectivity
Connectivity Features:
Not applicable.
Lighting
Lighting System:
Halogen headlight, incandescent tail and turn signals.
Instrumentation
Instrument Panel:
Analog speedometer and tachometer, fuel gauge, coolant temperature gauge, various warning lights.
🔧 Maintenance
Service Intervals
Oil Change:
Every 3,000 miles or 6 months (refer to specific year for exact Honda recommendation).
Major Service:
Valve clearance checks typically recommended every 12,000-16,000 miles.
Fluid Specifications
Engine Oil:
SAE 10W-40 API SE or SF, or 10W-30 API SG or SH. Capacity approx. 3.2 L (3.4 US qt) without filter, 3.4 L (3.6 US qt) with filter.
Coolant:
Honda HP Coolant or equivalent ethylene glycol-based coolant with anti-corrosion additives. 50/50 mix with distilled water. Capacity approx. 1.8 L (1.9 US qt).
Brake Fluid:
DOT 4 hydraulic brake fluid.
Clutch Fluid:
DOT 4 hydraulic clutch fluid (if applicable, as it's hydraulically operated).
Known Issues
Common Wear Items:
Cam chain tensioner (can become noisy), fuel line cracking (due to age/material), regulator/rectifier failure (common on many Hondas of this era), fork seal leaks.
Engine Reliability:
Generally very reliable, known for its robust V4 engine. Early models might experience some minor electrical issues. Cam chain noise is a common point of attention.
📚 Vehicle History
Brand Heritage
Honda Reputation:
Honda is renowned for its engineering excellence, reliability, build quality, and innovative designs across all its product lines, including motorcycles.
Model Evolution
Vfr Lineage:
The VFR line, starting with the VFR750F RC24 in 1986, established Honda's reputation for high-performance V4 sportbikes. The 1990-1996 generation (RC36) marked a significant evolution with styling updates, improved aerodynamics, and refinements to the V4 engine and chassis, including the introduction of the Pro-Arm.
Production
Production Period:
1990-1996
Manufacturing Location:
Japan
🏆 Awards & Recognition
Recognitions
Motorcycle Journal Reviews:
Consistently praised by motorcycle publications for its V4 engine character, handling, build quality, and versatility as a sport-tourer.
Ratings
Performance Ratings:
Rated highly for its blend of sportbike performance and long-distance comfort.
Certifications
Emissions Standards:
Compliant with emissions standards of the time; manual will detail specific procedures for emission control systems if applicable.
