2005-2007 Suzuki LT-A700X King Quad 700 Service Repair Manual (free preview)

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

🏷️ Basic Information Identification Make: Suzuki Model: LT-A700X King Quad Model Nickname: King Quad 700 Product Type: Service Repair Manual Product Format: PDF Download Applicable Years: 2005, 2006, 2007 👋...

23 people are viewing this right now

Typ: Atv

Anbieter:

Art.-Nr: 48308

Stichworte: 2005 2006 2007 ATV King Quad Models LT-A700X King Quad 700 Powersports Suzuki

Produktvarianten

Beschreibung

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

LT-A700X King Quad

Model Nickname:

King Quad 700

Product Type:

Service Repair Manual

Product Format:

PDF Download

Applicable Years:

2005, 2006, 2007

👋 Introduction

Market Position

Vehicle Category:

High-performance All-Terrain Vehicle (ATV)

Target Audience:

Off-road enthusiasts, utility users, and ATV owners seeking in-depth maintenance and repair knowledge

Competitive Analysis

Competitors:

Polaris Sportsman 700, Yamaha Grizzly 660, Can-Am Outlander 800

Key Features

Manual Value Proposition:

Provides professional, dealer-equivalent repair information, saving time and money on maintenance and repairs

Manual Content Highlight:

Comprehensive coverage for complete tear down, rebuild, and troubleshooting, mirroring dealer service procedures

📋 Manual Details

Coverage Areas

Primary Coverage:

Complete repair and maintenance of the Suzuki LT-A700X King Quad 700

Secondary Coverage:

Troubleshooting, diagnostics, rebuilding, restoration

Page Count

Total Pages:

Manual Type

Manual Type:

Dealer-level Service Manual

Language

Language:

English

Format

File Format:

Digital Delivery:

Download link provided after purchase

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Drive Train, Fuel System, FI System Diagnosis, Throttle Body

Chassis:

Chassis components, suspension, steering

Electrical:

Electrical System, Wiring Diagram

General:

General Information, Periodic Maintenance, Servicing Information

Procedures Included

Maintenance:

Routine checks, fluid changes, filter replacements, lubrication

Repair:

Complete tear down and rebuild procedures for all major components

Diagnostics:

Troubleshooting guides and procedures for common and uncommon issues

Technical Data:

Torque specifications, clearance measurements, electrical resistance values

Technical Depth

Depth:

Comprehensive, covering from basic maintenance to complete engine and transmission overhauls

Visuals:

Detailed illustrations, part diagrams, and schematics

📊 Manual Specifications

File Format

File Format:

Searchable Text:

Likely searchable, as is typical for dealer-level PDFs

Print Quality

Printability:

Printable without restriction

Print Utility:

Print specific pages for use in the garage or workshop

Binding Type

Binding Type:

N/A (Digital PDF)

Paper Type

Paper Type:

N/A (Digital PDF)

Compatibility

Operating Systems:

All Versions of Windows & Mac

Requirements

Software Requirement:

Adobe PDF Reader

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, SOHC, V-Twin, liquid-cooled

Displacement:

695 cc (42.4 cu. in.)

Bore X Stroke:

75.0 mm x 79.0 mm (2.95 in. x 3.11 in.)

Compression Ratio:

8.6:1

Performance

Horsepower Estimate:

Approx. 45-50 HP (at crankshaft, actual may vary)

Torque Estimate:

Approx. 40-45 lb-ft (at crankshaft, actual may vary)

Fuel System

Fuel Delivery:

Fuel Injection (FI)

Throttle Body Size:

46 mm

Fuel Type:

Unleaded gasoline

Engine Components

Cooling System:

Liquid-cooled with fan

Ignition System:

Electronic ignition (CDI)

🔧 Transmission

Standard

Transmission Type:

Automatic (CVT - Continuously Variable Transmission)

Drive Modes:

2WD/4WD selector with locking front differential

Features

Transmission Features:

High/Low range gearbox, Reverse

Fluid Specifications

Cvt Fluid Type:

Refer to manual for specific CVT fluid (e.g., Suzuki Super Gear Oil or equivalent)

📐 Dimensions

Exterior

Overall Length:

2,195 mm (86.4 in.)

Overall Width:

1,135 mm (44.7 in.)

Overall Height:

1,175 mm (46.3 in.)

Wheelbase:

1,430 mm (56.3 in.)

Weights

Dry Weight:

261 kg (575 lbs)

Curb Weight Estimate:

Approx. 280 kg (617 lbs) (with fluids)

Capacity

Fuel Tank Capacity:

17.0 L (4.5 US gal)

Towing Capacity:

Refer to manual (typically limited for ATVs)

Dimensions

Ground Clearance:

260 mm (10.2 in.)

🛡️ Safety Features

Ratings

Atv Safety Standards:

Designed to meet ANSI standards for recreational off-highway vehicles

Active Features

Braking System:

Hydraulic disc brakes (front and rear)

Parking Brake:

Mechanical parking brake

Passive Features

Lighting:

Dual 30W headlights, 8W taillight/brake light

Tires:

AT 25x8-12 front, AT 25x10-12 rear (common fitment)

💡 Technology Features

Infotainment

Infotainment System:

N/A (Utility ATV, focus on function over comfort features)

Driver Assistance

No ABS

Connectivity

Connectivity Features:

Engine Management

Efi Controller:

ECM (Engine Control Module) manages fuel injection and ignition timing

🔧 Maintenance

Service Intervals

Oil Change Interval:

Refer to manual (typically every 100 hours or annually)

Air Filter Cleaning:

Refer to manual (frequent checks recommended in dusty conditions)

Spark Plug Replacement:

Refer to manual (e.g., 4,000-6,000 miles or annually)

Fluid Specifications

Engine Oil Type:

Refer to manual for exact API SG or higher, JASO MA or MA2 (e.g., SAE 10W-40 or 20W-50)

Engine Oil Capacity:

Refer to manual (typically around 2.5-3.0 liters with filter)

Coolant Type:

Ethylene glycol-based antifreeze coolant, 50/50 mix with distilled water

Brake Fluid Type:

DOT 3 or DOT 4 hydraulic brake fluid

Known Issues

Common Wear Items:

CVT belt wear, wheel bearings, suspension bushings

Efi System Considerations:

Throttle body cleaning, injector maintenance may be required over time.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation

Brand Focus:

Known for motorcycles, ATVs, automobiles, and marine engines

Model Evolution

King Quad Lineage:

The King Quad line has a history of robust performance and capability in the ATV market.

Production

Production Period:

The LT-A700X was a flagship model in Suzuki's ATV lineup during its production run.

🏆 Awards & Recognition

Recognitions

Atv Industry Reputation:

The King Quad line is generally well-regarded for its power, handling, and reliability in its class.
