Positioning:
The Suzuki LT-A700X KingQuad was positioned as a premium, high-performance utility ATV in its segment.
Competitors:
Competed with top-tier utility ATVs from brands like Yamaha (Grizzly), Honda (Rancher/Foreman), and Polaris (Sportsman).
Engine Design:
Featured an advanced liquid-cooled, fuel-injected engine for consistent power delivery and improved efficiency.
Drivetrain Technology:
Utilized advanced True All-Wheel Drive (AWD) system for superior traction.
Suspension System:
Equipped with independent front and rear suspension for enhanced comfort and handling over rough terrain.
Engine Overhaul:
Comprehensive engine disassembly, inspection, repair, and reassembly procedures.
Drive Train System:
Detailed information on gearbox, differentials, drive shafts, and axle components.
Fuel Injection System:
In-depth diagnosis and troubleshooting for the Electronic Fuel Injection (EFI) system.
Fuel System:
Coverage of fuel pump, fuel filter, fuel lines, and tank maintenance.
Throttle Body:
Inspection, cleaning, and adjustment procedures for the throttle body assembly.
Chassis Components:
Information on frame, suspension (front and rear), steering, and wheels.
Electrical System:
Complete coverage of wiring diagrams, ignition system, charging system, lighting, and starter.
Braking System:
Service and repair procedures for hydraulic brake systems, including levers, calipers, and rotors.
Cooling System:
Maintenance, fluid replacement, and troubleshooting for the liquid-cooled engine.
Body And Plastics:
Procedures for removal, installation, and maintenance of body panels and plastics.
Scheduled Maintenance:
Detailed guidance on routine inspections, lubrication, and fluid changes at specified intervals.
Troubleshooting:
Systematic diagnostic procedures and common problem identification for various systems.
Component Removal Installation:
Step-by-step instructions for removing and installing major and minor components.
Engine Rebuild:
Complete overhaul procedures, including piston, cylinder, crankshaft, and valve servicing.
Suspension Adjustment:
Guidance on adjusting and servicing front and rear suspension components.
Electrical Diagnostics:
Troubleshooting electrical faults using wiring diagrams and diagnostic charts.
Fluid Replacement:
Instructions for changing engine oil, transmission fluid, and coolant.
Torque Specifications:
Essential torque values for critical fasteners and engine components.
Tire Pressure And Maintenance:
Information on recommended tire pressures and basic tire care.
Depth:
Comprehensive, from basic maintenance to advanced engine and electrical system repair.
Diagnostic Capabilities:
Advanced diagnostic procedures, including EFI system analysis and electrical troubleshooting.
Repair Level:
Suitable for DIY enthusiasts and professional mechanics; covers full overhauls.
Illustrations:
Richly illustrated with diagrams, photographs, and schematics for part identification and assembly.
Compatibility:
Compatible with Windows, macOS, and Linux operating systems.
Readability:
Requires a PDF Reader; searchable text for efficient navigation.
Extraction Requirement:
May require a compression utility (e.g., 7-zip) if delivered within an archive.
Printability:
Designed for printing specific pages or the entire manual for hands-on use.
Digital Binding:
N/A (Digital Download)
Digital Paper Type:
N/A (Digital Download)
Engine Type:
Four-stroke, SOHC, V-twin
Cooling System:
Liquid-cooled
Bore X Stroke:
70.0 mm x 72.0 mm
Valve Configuration:
SOHC, 4 valves per cylinder
Horsepower:
Approx. 50 HP (estimated, exact figures may vary by region and tuning)
Torque:
Approx. 40 lb-ft (estimated, exact figures may vary by region and tuning)
Fuel Delivery:
Fuel Injection (EFI) - Suzuki's digital fuel injection system.
Fuel Type:
Unleaded gasoline
Ignition System:
Digital CDI with electronic advance
Spark Plug:
CR9E (or equivalent, refer to manual for specifics)
Overall Length:
Approx. 82.1 inches (2085 mm)
Overall Width:
Approx. 45.3 inches (1150 mm)
Overall Height:
Approx. 48.4 inches (1230 mm)
Wheelbase:
Approx. 50.6 inches (1285 mm)
Dry Weight:
Approx. 600 lbs (272 kg)
Fuel Capacity:
Approx. 4.6 gallons (17.5 liters)
Front Rack Capacity:
Approx. 110 lbs (50 kg)
Rear Rack Capacity:
Approx. 220 lbs (100 kg)
Ground Clearance:
Approx. 10.2 inches (260 mm)
Towing Capacity:
Approx. 1,047 lbs (475 kg)
Atv Safety Standards:
Complies with ANSI standards for recreational ATVs.
Braking System:
Hydraulic disc brakes front and rear for strong stopping power.
Drivetrain Engagement:
Electronically selectable 2WD/4WD with differential lock provides enhanced traction control.
Chassis Design:
Sturdy frame construction and independent suspension contribute to stability.
Lighting:
Dual halogen headlights and a brakelight/taillight for visibility.
Features:
As a utility ATV, infotainment features are minimal, focusing on essential instrumentation.
Instrumentation:
Digital LCD meter with speedometer, odometer, trip meter, clock, 2WD/4WD indicator, and FI warning light.
Traction Control:
Achieved through the advanced 4WD system with differential lock.
Features:
N/A (No specific connectivity features like Bluetooth or USB ports).
Engine Oil Change:
Refer to manual for specific mileage/time intervals (typically every 1000-2000 miles or annually).
Air Filter Cleaning:
Recommended for inspection and cleaning at regular intervals, especially in dusty conditions.
Spark Plug Replacement:
Recommended replacement every 6,000 miles or as indicated by the manual.
Engine Oil Type:
SAE 10W-40 API SG or higher (refer to manual for exact Suzuki recommended specification)
Engine Oil Capacity:
Approx. 2.2 liters (2.3 US qt) with filter change (refer to manual)
Coolant Type:
Suzuki Long Life Coolant or equivalent ethylene glycol-based coolant (50/50 mix with distilled water).
Brake Fluid Type:
DOT 4 hydraulic brake fluid.
Transmission Gear Oil:
Refer to manual for specific gear oil type and capacity for the final drive unit.
Common Wear Items:
Brake pads, tires, drive belts (CVT), and suspension bushings are common wear items.
Efi System Maintenance:
Regular cleaning of the throttle body and checking for sensor faults can prevent driveability issues.
Electrical Connections:
Ensuring all electrical connections are clean and secure is important for reliable operation.
Suzuki Atv Legacy:
Suzuki has a long-standing reputation for building reliable and performance-oriented ATVs.
Kingquad Lineage:
The KingQuad line has consistently been Suzuki's flagship utility ATV, known for its innovation and power.
Lt A700X Introduction:
Introduced as a significant upgrade, featuring the new V-twin engine and advanced EFI system.
Production Period:
The LT-A700X was produced primarily from 2005 to 2007 before being succeeded by the LT-A750X.
