Positioning:
Aimed at DIY mechanics and vehicle owners seeking professional-level repair information for their 2009 Chevrolet Aveo.
Advantage Over Print:
More convenient, accessible, and often more cost-effective than traditional printed manuals.
Licensed Content:
Officially licensed and derived from OE (Original Equipment) materials, ensuring accuracy and completeness.
Overall Coverage:
Comprehensive service and repair for the 2009 Chevrolet Aveo.
Estimated Page Count:
N/A (Digital access, content dynamically available)
Type:
Service and Repair Manual Software
Format:
PDF Download (accessible via web browser)
Engine Systems:
Engine mechanical, fuel system, ignition system, cooling system, lubrication system, exhaust system.
Drivetrain Systems:
Manual transmission, automatic transmission, clutch, drive axles, differential.
Chassis Systems:
Suspension (front and rear), steering system, brake system (front and rear disc/drum).
Electrical Systems:
Wiring diagrams, lighting, power distribution, starter, alternator, battery, body electrical.
HVAC Systems:
Heating, ventilation, and air conditioning (HVAC) system.
Body And Interior:
Body panels, doors, windows, interior trim, seats.
Maintenance Procedures:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspections and replacement.
Repair Procedures:
Engine component replacement (e.g., water pump, alternator), transmission service and repair, brake pad and rotor replacement, suspension component replacement (e.g., struts, ball joints), steering component replacement (e.g., tie rods).
Diagnostic Procedures:
Troubleshooting guides for common symptoms, diagnostic trouble code (DTC) interpretation (OBD-II), electrical system diagnostics.
Depth:
Detailed, factory-derived information suitable for both DIY enthusiasts and professional technicians.
Diagnostic Focus:
Includes systematic diagnostic procedures and pinpoint tests for electrical and mechanical issues.
Torque Specifications:
Comprehensive torque specifications for all critical fasteners.
Wiring Diagrams:
Detailed electrical wiring diagrams for all vehicle systems.
Print Quality:
High-resolution, suitable for clear printing of individual pages or sections.
Binding Type:
N/A (Digital download)
Paper Type:
N/A (Digital download)
Device Compatibility:
Compatible with PC, laptop, smartphone, and tablet via web browser.
Access:
One-year access included, with discounts for renewal.
Engine Code:
1.6L LDE (DOHC, 16-valve)
Displacement:
1598 cc (97.5 cu. in.)
Bore X Stroke:
79.0 mm x 81.5 mm (3.11 in. x 3.21 in.)
Compression Ratio:
10.5:1
Horsepower:
108 hp @ 6400 rpm
Torque:
105 lb-ft @ 3800 rpm
Induction:
Multi-point Fuel Injection (MPFI)
Fuel Type:
Unleaded Gasoline (87 octane recommended)
ECM Type:
GM Electronic Control Module (ECM)
NHTSA Frontal Crash:
4/5 stars (Driver), 5/5 stars (Passenger)
NHTSA Side Crash:
4/5 stars (Front Seat Passenger)
ABS:
Available Anti-lock Braking System (ABS).
Airbags:
Driver and front passenger airbags. Available side-impact airbags.
Seatbelts:
Three-point seatbelts with pretensioners and load limiters.
Oil Change Interval:
Every 7,500 miles or 6 months, whichever comes first (using synthetic blend or full synthetic oil).
Air Filter Replacement:
Every 30,000 miles or 2 years.
Spark Plug Replacement:
Every 100,000 miles (iridium type spark plugs).
Engine Oil:
SAE 5W-30, API SN/SN PLUS or ILSAC GF-6 certified.
Coolant:
GM DEX-COOL® (Orange) Extended Life Antifreeze/Coolant.
Brake Fluid:
DOT 3 or DOT 4 Brake Fluid.
Transmission Fluid Manual:
GM Manual Transmission Fluid (MTF) or equivalent API GL-4, SAE 75W-85.
Transmission Fluid Automatic:
GM DEXRON-VI Automatic Transmission Fluid (ATF).
Common Complaints:
Potential issues include minor electrical faults, HVAC system performance degradation, and occasional suspension component wear.
Brand Focus:
Chevrolet, a division of General Motors, is known for producing a wide range of vehicles, from economy cars to heavy-duty trucks.
Generation:
The 2009 model year represents the second generation of the Chevrolet Aveo (T250 platform), introduced in 2006, with a facelift in 2009.
Manufacturing Location:
South Korea (Daewoo/GM Korea) and other GM assembly plants globally.
